# Messaging API reference

# Common specifications

Common specifications for Messaging API, such as the domain name of endpoints, response when a request succeeds or fails, and rate limit.

Domain name
Rate limits
Status codes
Response headers
Error responses
Other common specifications

# Domain name

In Messaging API, the domain name differs depending on the endpoint. Be careful to use the correct domain name for each endpoint.

Domain name	Endpoint
`api-data.line.me`	Get content Create audience for uploading user IDs (by file) Add user IDs or Identifiers for Advertisers (IFAs) to an audience for uploading user IDs (by file) Upload rich menu image Download rich menu image
`api.line.me`	Other API endpoints

# Rate limits

The Messaging API applies the following rate limits for each API function (endpoint) on a per-channel. For more information about the scope of rate limits apply, see Scope of rate limits.

Don't submit requests exceeding the rate limit

If you send requests exceeding the rate limit, you will receive an error message saying, 429 Too Many Requests. When developing a LINE Bot using the Messaging API, follow the Messaging API development guidelines, including the guidelines on rate limits.

Endpoint	Rate limit
Send a narrowcast message Send a broadcast message Get number of message deliveries Get number of friends Get friend demographics Get user interaction statistics Get statistics per unit Test webhook endpoint	60 requests per hour
Create audience for uploading user IDs (by JSON) Create audience for uploading user IDs (by file) Add user IDs or Identifiers for Advertisers (IFAs) to an audience for uploading user IDs (by JSON) Add user IDs or Identifiers for Advertisers (IFAs) to an audience for uploading user IDs (by file) Create message click audience Create message impression audience Rename an audience Delete audience Get audience data Get data for multiple audiences Get shared audience data in Business Manager Get a list of shared audiences in Business Manager	60 requests per minute
Set webhook endpoint URL Get webhook endpoint information	1,000 requests per minute
Create rich menu Delete rich menu Delete rich menu alias Get the status of rich menu batch control	100 requests per hour *
Replace or unlink the linked rich menus in batches	3 requests per hour
Send multicast message Get a user's membership subscription status Get membership plans being offered	200 requests per second
Display a loading animation	100 requests per second
Issue short-lived channel access token	370 requests per second
Other API endpoints	2,000 requests per second

* Creating and deleting rich menus using the LINE Official Account Manager is not subject to this restriction.

# Scope of rate limits

The Messaging API applies rate limits for each API function (endpoint) on a per-channel. Note also the following points about the scope of rate limits:

Even if the endpoint URL is the same, it is a different endpoint if the HTTP method is different.
We apply rate limits without distinguishing between the value of parameters in the URL or the contents of the request body.
We apply rate limits without distinction, even if you use the endpoint from a different IP address.
If you use endpoints for the same LINE Official Account from different channels, we'll apply rate limits independently for each channel.

# Limit on the number of concurrent operations

We have set a limit on the number of concurrent endpoint operations per audience ID (audienceGroupId), for creating an audience for uploading user IDs and adding user IDs to an audience.

The total number of requests processed concurrently by the following endpoints is counted as the number of concurrent operations.

Endpoint	Maximum number of concurrent operations
Create audience for uploading user IDs (by JSON) Create audience for uploading user IDs (by file) Add user IDs or Identifiers for Advertisers (IFAs) to an audience for uploading user IDs (by JSON) Add user IDs or Identifiers for Advertisers (IFAs) to an audience for uploading user IDs (by file)	10

Requests that exceed the limit on the number of concurrent operations will return an error with status code 429 Too Many Requests. If you've received an error, wait a while before making a request again.

You can check the number of requests being processed with the jobs property of the following endpoint response. If the status of a job (jobs[].jobStatus property) is waiting to run (QUEUED) or running (WORKING), it will be counted as an operation.

Get audience data

# Status codes

These HTTP status codes are returned after an API call. We follow the HTTP status code specification (opens new window) unless otherwise stated.

Status code	Description
200 OK	Request successful.
400 Bad Request	Problem with the request.
401 Unauthorized	Valid channel access token is not specified.
403 Forbidden	Not authorized to access the resource. Confirm that your account or plan is authorized to access the resource.
404 Not Found	Unable to get profile information. Consider these reasons: Target user ID doesn't exist. The user hasn't consented to their profile information being obtained. The user hasn't added the target LINE Official Account as a friend. The user blocked the target LINE Official Account after adding it as a friend. For more information, see Consent on getting user profile information in the Messaging API documentation.
409 Conflict	An API request with the same retry key has already been accepted. For details, see Retry failed API request.
410 Gone	Access to the resource that is no longer available.
413 Payload Too Large	Request exceeds the max size of 2MB. Make the request smaller than 2MB and try again.
415 Unsupported Media Type	Media type of the uploaded file is unsupported.
429 Too Many Requests	Exceeded the rate limit for requests. Exceeded the Limit on the number of concurrent operations for requests. Exceeded the number of free messages. Exceeded your maximum number of additional messages allowed to be sent. For more information about the number of free messages and the maximum number of additional messages allowed to be sent, see Messaging API pricing in the Messaging API documentation.
500 Internal Server Error	Error on the internal server.

# Response headers

The following HTTP headers are included in Messaging API responses:

Response headers	Description
X-Line-Request-Id	Request ID. An ID is issued for each request.
X-Line-Accepted-Request-Id Not always included	If the request has already been accepted using the same retry key, the `x-line-request-id` of the accepted request is shown. For more information, see Retrying an API request.

# Error responses

The following JSON data is returned in the response body when an error occurs.

message

String

Message containing information about the error. For more details, see Error messages.

details

Array

Not always included

An array of error details. If the array is empty, this property will not be included in the response.

details[].message

String

Not always included

Details of the error. Not included in the response under certain situations.

For more information about details of the error on the Managing Audience endpoints, see Details of the error related to audience management.

details[].property

String

Not always included

Location of where the error occurred. Returns the JSON field name or query parameter name of the request. Not included in the response under certain situations.

Example error response

# Error messages

The main error messages that are found in the message property of the JSON error responses are shown below.

Message	Description
The request body has X error(s)	An error was found in the JSON data of the request body. The number of errors is displayed for "X". Further details are shown in the `details[].message` and `details[].property` properties.
Invalid reply token	The reply token specified in `replyToken` to send reply message is invalid. Consider these reasons: Sent a reply message using an expired reply token. Sent a reply message using a used reply token.
The property, XXX, in the request body is invalid (line: XXX, column: XXX)	An invalid property was specified in the request body. The specific property is displayed for "XXX".
The request body could not be parsed as JSON (line: XXX, column: XXX)	The JSON in the request body could not be parsed. The specific line and column are displayed.
The content type, XXX, is not supported	A content type not supported by the API is requested.
Authentication failed due to the following reason: XXX	Authentication failed when the API was called. The reason is displayed for "XXX".
Access to this API is not available for your account	Appears when calling an API that you do not have permission to use.
Failed to send messages	Appears when the message fails to be sent. One reason this may appear is if the user ID specified doesn't exist.
You have reached your monthly limit.	Exceeded the number of free messages. Exceeded your maximum number of additional messages allowed to be sent. For more information about the number of free messages and the maximum number of additional messages allowed to be sent, see Messaging API pricing in the Messaging API documentation.
Not found	Unable to get profile information. Consider these reasons: Target user ID doesn't exist The user hasn't consented to their profile information being obtained The user hasn't added the target LINE Official Account as a friend The user blocked the target LINE Official Account after adding it as a friend For more information, see Consent on getting user profile information in the Messaging API documentation.

# Other common specifications

# About the encoding of a URL specified in a request body property

Domain names, paths, query parameters, and fragments in the property should be percent-encoded (opens new window) using UTF-8.

For example, if you specify a URI with the following components, it should be https://example.com/path?q=Good%20morning#Good%20afternoon.

scheme	domain name	path	query parameter		fragment
scheme	domain name	path	key	value	fragment
https	example.com	/path	q	Good morning	Good afternoon

# Webhooks

When an event occurs, such as when a user adds your LINE Official Account as a friend or sends a message, the LINE Platform sends an HTTPS POST request to the webhook URL (bot server).

The webhook URL is configured for each channel in the LINE Developers Console.

We recommend that you make the event processing asynchronous

We recommend that you make the event processing asynchronous so that the processing of HTTP POST requests does not delay the processing of subsequent events.

The IP address of the LINE Platform isn't disclosed

The IP address of the LINE Platform from which the webhook request is sent isn't disclosed. For better security, use signature validation instead of access control by IP address.

# Request headers

x-line-signature

Used for signature validation

Request header field names are case insensitive

Uppercase and lowercase letters in the Request headers field names may change without notice. The bot server that receives the webhook should handle the header field name without case distinction. *1

	Before change	After change
Header field name example	`X-Line-Signature`	`x-line-signature`

*1 https://datatracker.ietf.org/doc/html/rfc7230#section-3.2 (opens new window)

# Request body

The request body contains a JSON object with the user ID of a bot that should receive webhook events and an array of webhook event objects.

destination

String

User ID of a bot that should receive webhook events. The user ID value is a string that matches the regular expression, U[0-9a-f]{32}.

events

Array

Array of webhook event objects. The LINE Platform may send an empty array that doesn't include a webhook event object to confirm communication.

# Response

The bot server must return status code 200 after it receives the HTTP POST request sent from the LINE Platform.

Note

Even if the bot server fails to receive the HTTP POST request sent from the LINE Platform, the bot server can receive this request again. For more information, see Redeliver a webhook that failed to be received.
The LINE Platform may send an HTTP POST request that doesn't include a webhook event to confirm communication. In this case, send a 200 status code.

Example HTTP POST request without a webhook event:
```
{
  "destination": "xxxxxxxxxx",
  "events": []
}
```

# Signature validation

When the bot server receives a webhook event, verify the signature included in the request header before processing the webhook event objects. This verification step is important to confirm that the webhook came from the LINE Platform and wasn’t tampered with during transmission.

For more information, see Verify webhook signature.

Example of signature validation

# Webhook Event Objects

These are JSON objects containing events generated by the LINE Platform.

Some properties of these event objects may lack a value. Generated event objects don't contain properties without any value.

A single webhook may contain multiple webhook event objects

A webhook sent from the LINE Platform may contain multiple webhook event objects. There is not necessarily one user per webhook. A message event from person A and a follow event from person B may be in the same webhook.

Even when you receive a webhook containing multiple event objects, implement it so that the bot server can process it appropriately according to its contents. For more information, see request body under Webhook.

Example webhook event object

# Common properties

The following properties are common properties in webhook event objects.

type

String

Identifier for the type of event

mode

String

Channel state.

active: The channel is active. You can send a reply message or push message, etc. from the bot server that received this webhook event.
standby: The channel is waiting. When the channel state is standby, the webhook event won't contain a reply token to send reply message. For more information about the timing of the channel state set to standby, see Get webhook event in the module documentation.

When the channel state is standby, the bot server shouldn't send any messages

When the channel state is standby, the module may be replying or otherwise reacting to the content of the received webhook event. Sending messages from the bot while the user and the module are interacting will confuse the user. Therefore, the bot server that received a Webhook event with a mode property of standby shouldn't send any messages.

timestamp

Number

UNIX time of the event occurred (in milliseconds). Even in the case of a redelivered webhook, it represents the time the event occurred, not the time it was redelivered.

Check timestamp if webhook redelivery is enabled

If webhook redelivery is enabled, the order in which webhook events occur and the order in which they reach the bot server can be different significantly. If this is an issue, check the context by looking at the timestamp.

source

Object

Not always included

Source user, group chat, or multi-person chat object with information about the source of the event.

This property won't be included in the account link event if linking the account has failed.

webhookEventId

String

Webhook Event ID. An ID that uniquely identifies a webhook event. This is a string in ULID format.

deliveryContext.isRedelivery

Boolean

Whether the webhook event is a redelivered one or not. For more information, see Redelivered webhooks.

true: Redelivered webhook event.
false: First webhook event sent.

# Source user

type

String

user

userId

String

ID of the source user

Source user example

# Source group chat

type

String

group

groupId

String

Group ID of the source group chat

userId

String

Not always included

ID of the source user. Only included in message events. Only users of LINE for iOS and LINE for Android are included in userId. For more information, see Consent on getting user profile information.

Source group chat example

# Source multi-person chat

type

String

room

roomId

String

Room ID of the source multi-person chat

userId

String

Not always included

Source multi-person chat example

# Message event

Webhook event object which contains the sent message from a user. The message property contains a message object which corresponds with the message type. You can reply to message events.

timestamp, source, etc.

See Common Properties.

type

String

message

replyToken

String

Reply token used to send reply message to this event

message

Object

Object containing the contents of the message. Message types include:

Text
Video
Audio
File
Location
Sticker

# Text

Message object which contains the text sent from the source.

String

Message ID

type

String

text

quoteToken

String

Quote token of the message. For more information, see Get quote tokens in the Messaging API documentation.

text

String

Message text.

If the end user sends a LINE emoji, the LINE emoji will be included as a string, like (hello) or (love). You can find the LINE emoji details in the emojis property.
If the end user mentions someone, the display name of the recipient's LINE account will be included as a string, like @example. You can find the mention details in the mention property.

emojis

Array

Not always included

Array of one or more LINE emoji objects. Only included in the message event when the text property contains a LINE emoji.

Sent LINE emoji may not be included in the emojis property

The default LINE emojis sent from LINE for Android won't be included.
Unicode-defined emojis and older versions of LINE emojis may not be retrieved correctly.

emojis[].index

Number

Index position for a character in text, with the first character being at position 0.

emojis[].length

Number

The length of the LINE emoji string. For LINE emoji (hello), 7 is the length.

emojis[].productId

String

Product ID for a LINE emoji set. See LINE emoji for an example of a product ID.

emojis[].emojiId

String

ID for a LINE emoji inside a set. See LINE emoji for an example of an emoji ID.

mention

Object

Not always included

Object containing the contents of the mentioned user. Only included in the message event when the text property contains a mention.

mention.mentionees[]

Array of objects

Array of one or more mention objects.

Max: 20 mentions

mention.mentionees[].index

Number

Index position of the user mention for a character in text, with the first character being at position 0.

mention.mentionees[].length

Number

The length of the text of the mentioned user. For a mention @example, 8 is the length.

mention.mentionees[].type

String

Mentioned target.

user: User or bot.
all: Entire group.

mention.mentionees[].userId

String

Not always included

User ID of the mentioned user or bot. Only included if mention.mentions[].type is user. If the mentionee is a user, only included if the user consents to the LINE Official Account obtaining their user profile information.

mention.mentionees[].isSelf

Boolean

Not always included

Whether the mention is to the bot (destination) that received the webhook event. This is only included when the value of the mention.mentionees[].type property is user.

true: This is a mention to the bot that received the webhook event.
false: This is a mention to another user.

For more information, see Webhook when a message including a mention to a bot is sent in the Messaging API documentation.

quotedMessageId

String

Not always included

Message ID of a quoted message. Only included when the received message quotes a past message.

Text message example

# Image

Message object which contains the image content sent from the source.

String

Message ID

type

String


quoteToken

String

Quote token of the message. For more information, see Get quote tokens in the Messaging API documentation.

contentProvider.type

String

Provider of the image file.

line: The image was sent by a LINE user. The binary data of the image file can be retrieved by specifying the message ID and calling the Get content endpoint.
external: The URL of the image file is included in the contentProvider.originalContentUrl property. If the provider of the image file is external, the binary data of the image file can't be retrieved by using the Get content endpoint.

contentProvider.originalContentUrl

String

Not always included

URL of the image file. Only included when contentProvider.type is external. The server where the image file is located isn't provided by LY Corporation.

contentProvider.previewImageUrl

String

Not always included

URL of the preview image. Only included when contentProvider.type is external. The server where the preview image file is located isn't provided by LY Corporation.

imageSet.id

String

Not always included

Image set ID. Only included when multiple images are sent simultaneously.

imageSet.index

Number

Not always included

An index starting from 1, indicating the image number in a set of images sent simultaneously. Only included when multiple images are sent simultaneously. However, it won't be included if the sender is using LINE 11.15 or earlier for Android.

The order in which webhooks are delivered is undefined

If a user simultaneously sends multiple images, multiple webhook events are sent to the bot server from the LINE Platform. The webhooks are delivered in an undefined order, not in the order of the values in imageSet.index.

imageSet.total

Number

Not always included

The total number of images sent simultaneously. If two images are sent simultaneously, the number is 2. Only included when multiple images are sent simultaneously. However, it won't be included if the sender is using LINE 11.15 or earlier for Android.

Image message example

# Video

Message object which contains the video content sent from the source. The preview image is displayed in the chat and the video is played when the image is tapped.

String

Message ID

type

String

video

quoteToken

String

Quote token of the message. For more information, see Get quote tokens in the Messaging API documentation.

duration

Number

Not always included

Length of video file (milliseconds)

contentProvider.type

String

Provider of the video file.

line: The video was sent by a LINE user. The binary data of the video file can be retrieved by specifying the message ID and calling the Get content endpoint.
external: The URL of the video file is included in the contentProvider.originalContentUrl property. If the provider of the video file is external, the binary data of the video file can't be retrieved by using the Get content endpoint.

contentProvider.originalContentUrl

String

Not always included

URL of the video file. Only included when contentProvider.type is external. The server where the video file is located isn't provided by LY Corporation.

contentProvider.previewImageUrl

String

Not always included

URL of the preview image. Only included when contentProvider.type is external. The server where the preview image file is located isn't provided by LY Corporation.

Video message example

# Audio

Message object which contains the audio content sent from the source.

String

Message ID

type

String

audio

duration

Number

Not always included

Length of audio file (milliseconds)

contentProvider.type

String

Provider of the audio file:

line: The audio was sent by a LINE user. The binary data of the audio file can be retrieved by specifying the message ID and calling the Get content endpoint.
external: The URL of the audio file is included in the contentProvider.originalContentUrl property. If the provider of the audio file is external, the binary data of the audio file can't be retrieved by using the Get content endpoint.

contentProvider.originalContentUrl

String

Not always included

URL of the audio file. Only included when contentProvider.type is external. The server where the audio file is located isn't provided by LY Corporation.

Audio message example

# File

Message object which contains the file sent from the source. The binary data of the file can be retrieved by specifying the message ID and calling the API. For more information, see Get content.

String

Message ID

type

String

file

fileName

String

File name

fileSize

Number

File size in bytes

File message example

# Location

Message object which contains the location data sent from the source.

String

Message ID

type

String

location

title

String

Not always included

Title

address

String

Not always included

Address

latitude

Decimal

Latitude

longitude

Decimal

Longitude

Location message example

# Sticker

Message object which contains the sticker data sent from the source. For a list of basic LINE stickers and sticker IDs, see Stickers.

You can't retrieve the sticker image

The package ID and sticker ID of the sticker sent by the user can be retrieved by webhook, but the sticker image itself can't be retrieved.

The Sticker Arranging feature isn't supported

The Messaging API doesn't currently support the Sticker Arranging feature, so you can't get information about what kind of stickers are being combined. When a user sends a sticker message using the Sticker Arranging feature, the following sticker information is always received by the webhook.

Package ID: 30563
Sticker ID: 651698630
Sticker resource type: STATIC

String

Message ID

type

String

sticker

quoteToken

String

Quote token of the message. For more information, see Get quote tokens in the Messaging API documentation.

packageId

String

Package ID

stickerId

String

Sticker ID

stickerResourceType

String

Sticker resource type. One of:

STATIC: Still image
ANIMATION: Animated sticker
SOUND: Sticker with sound
ANIMATION_SOUND: Animated sticker with sound
POPUP: Pop-up sticker or Effect sticker
POPUP_SOUND: Pop-up sticker with sound or Effect sticker with sound
CUSTOM: Custom sticker. Text entered by user can't be retrieved.
MESSAGE: Message sticker
NAME_TEXT: Custom sticker (discontinued)
PER_STICKER_TEXT: Message sticker (discontinued)

About stickerResourceType

In the future, we may add new resource types without notice. Make sure your implementation can handle both current and future sticker resource types.

keywords

Array of strings

Not always included

Array of up to 15 keywords describing the sticker. If a sticker has 16 or more keywords, a random selection of 15 keywords will be returned. The keyword selection is random for each event, so different keywords may be returned for the same sticker.

About keywords

The keywords property is currently in an experimental phase and discontinuation or spec changes may occur in the future.

text

String

Not always included

Any text entered by the user. This property is only included for message stickers.
Max character limit: 100

You can't retrieve the text of custom stickers

In the case of custom stickers, the text entered by the user can't be retrieved.

quotedMessageId

String

Not always included

Message ID of a quoted message. Only included when the received message quotes a past message.

Sticker message example

# Unsend event

Event object for when the user unsends a message.

When a user unsends a sent message, an unsend event is sent to the bot server. When the unsend event is received, we recommend that service providers respect the user's intent to unsend a sent message and handle the message appropriately with the utmost care so that the target message can't be seen or used in the future. For more information, see Processing on receipt of unsend event in the Messaging API documentation.

timestamp, source, etc.

See Common Properties.

type

String

unsend

unsend.messageId

String

The message ID of the unsent message

Unsend event example

# Follow event

Event object for when your LINE Official Account is added as a friend (or unblocked). You can reply to follow events.

timestamp, source, etc.

See Common Properties.

type

String

follow

replyToken

String

Reply token used to send reply message to this event

follow.isUnblocked

Boolean

true: The user has unblocked the LINE Official Account.
false: The user has added the LINE Official Account as a friend.

Accuracy of follow.isUnblocked

The follow.isUnblocked property doesn't guarantee the complete accuracy of "add friend" and "unblock".

Follow event example

# Unfollow event

Event object for when your LINE Official Account is blocked.

timestamp, source, etc.

See Common Properties.

type

String

unfollow

Unfollow event example

# Join event

Event object for when your LINE Official Account joins a group chat or multi-person chat. You can reply to join events.

A join event is triggered at different times for group chats and multi-person chats.

For group chats: A join event is sent when a user invites your LINE Official Account.
For multi-person chats: A join event is sent when the first event (for example when a user sends a message or is added to the multi-person chat) occurs after your LINE Official Account is added.

timestamp, source, etc.

See Common Properties.

type

String

join

replyToken

String

Reply token used to send reply message to this event

Join event example

# Leave event

Event object for when a user removes your LINE Official Account from a group chat or when your LINE Official Account leaves a group chat or multi-person chat.

timestamp, source, etc.

See Common Properties.

type

String

leave

Leave event example

# Member join event

Event object for when a user joins a group chat or multi-person chat that the LINE Official Account is in.

timestamp, source, etc.

See Common Properties.

type

String

memberJoined

joined.members

Array

Users who joined. Array of source user objects.

replyToken

String

Reply token used to send reply message to this event

Member join event example

# Member leave event

Event object for when a user leaves a group chat or multi-person chat that the LINE Official Account is in.

timestamp, source, etc.

See Common Properties.

type

String

memberLeft

left.members

Array

Users who left. Array of source user objects.

Member leave event example

# Postback event

Event object for when a user performs a postback action which initiates a postback. You can reply to postback events.

timestamp, source, etc.

See Common Properties.

type

String

postback

replyToken

String

Reply token used to send reply message to this event

postback.data

String

Postback data

postback.params

Object

Any of these JSON objects:

postback.params object for date-time selection action.
- JSON object with date and time selected by the user via Datetime picker action.
- Returned only for postback actions by Datetime picker action.
postback.paramsobject for rich menu switch action.
- JSON object with rich menu alias ID selected by the user via Rich menu switch action.
- Returned only for postback actions by Rich menu switch action.

Postback event example

# `postback.params` object for date-time selection action

Object with the date and time selected by a user through a datetime picker action. The full-date, time-hour, and time-minute formats follow the RFC3339 protocol (opens new window).

Property	Format	Description
date	full-date	Date selected by user. Only included in the `date` mode.
time	time-hour ":" time-minute	Time selected by the user. Only included in the `time` mode.
datetime	full-date "T" time-hour ":" time-minute	Date and time selected by the user. Only included in the `datetime` mode.

postback.params object for date-time selection action example

# `postback.params`object for rich menu switch action

Object with rich menu alias ID selected by user via rich menu switch action.

Property	Format	Description
newRichMenuAliasId Not always included	String	Rich menu alias ID to switch to. This property won't be included if switching the rich menu has failed.
status	String	`SUCCESS`: Rich menu changed successfully. `RICHMENU_ALIAS_ID_NOTFOUND`: The specified rich menu alias ID wasn't found. `RICHMENU_NOTFOUND`: The rich menu ID associated with the specified rich menu alias ID wasn't found. `FAILED`: Rich menu switch failed.

postback.params object for rich menu switch action example

# Video viewing complete event

Event for when a user finishes viewing a video at least once with the specified trackingId sent by the LINE Official Account.

The number of video views

A video viewing complete event doesn't necessarily indicate the number of times a user has watched a video.

Watching a video multiple times in a single session in a chat room doesn't result in a duplicate event. However, if you close the chat room and reopen it to watch the video again, the event may reoccur.

Video in imagemap messages and flex messages is not supported by the video viewing complete event

The trackingId can't be specified for a video in imagemap messages and flex messages.

timestamp, source, etc.

See Common Properties.

type

String

videoPlayComplete

replyToken

String

Reply token used to send reply message to this event

videoPlayComplete.trackingId

String

ID used to identify a video. Returns the same value as the trackingId assigned to the video message.

Video viewing complete event example

# Beacon event

Event object for when a user enters the range of a LINE Beacon. You can reply to beacon events.

timestamp, source, etc.

See Common Properties.

type

String

beacon

replyToken

String

Reply token used to send reply message to this event

beacon.hwid

String

Hardware ID of the beacon that was detected

beacon.type

String

Type of beacon event. See Beacon event types.

beacon.dm

String

Not always included

Device message of beacon that was detected. This message consists of data generated by the beacon to send notifications to bot servers. Only included in webhook events from devices that support the "device message" property.
For more information, see the LINE Simple Beacon specification (opens new window).

Beacon event example

# Beacon event types

beacon.type	Description
`enter`	Entered beacon's reception range.
`banner`	Tapped beacon banner.
`stay`	A user is within the range of the beacon's reception. This event is sent repeatedly at a minimum interval of 10 seconds.

Registration has been suspended in Japan

As of January 2021, we are no longer accepting new applications for banner and stay events in Japan, while other regions except Japan still accept new application.

# Account link event

Event object for when a user has linked their LINE account with a provider's service account. You can reply to account link events.

If the link token has expired or has already been used, no webhook event will be sent and the user will be shown an error.

timestamp, source, etc.

See Common Properties.

The source property won't be included in the account link event if linking the account has failed.

type

String

accountLink

replyToken

String

Not always included

Reply token used to send reply message to this event. This property won't be included if linking the account has failed.

link.result

String

One of the following values to indicate whether linking the account was successful or not:

ok: Indicates linking the account was successful.
failed: Indicates linking the account failed for any reason, such as due to a user impersonation.

link.nonce

String

Specified nonce (number used once) when verifying the user ID. For more information, see Generate a nonce and redirect the user to the LINE Platform in the Messaging API documentation.

Account link event example

# Membership event

This event indicates that a user has joined, renewed, or left a membership of your LINE Official Account.

If your LINE Official Account provides multiple membership plans, and a user who is currently joined one plan changes to another plan during the same month, webhook events will be sent for both the leaving and joining. If a user hasn't consented to allow access to their profile information, no webhook event will be sent. For more information, see Consent on getting user profile information in the Messaging API documentation.

timestamp, source, etc.

See Common properties.

type

String

membership

replyToken

String

Reply token used to send a reply message to this event

membership.type

String

Type of membership event. One of the following values:

joined: User joined the membership.
left: User left the membership.
renewed: User renewed the membership.

membership.membershipId

Number

A membership ID that the user has joined, left, or renewed.

Membership event example

# Webhook settings

You can configure, test, and get information on channel webhook endpoints.

Endpoints

PUT  /v2/bot/channel/webhook/endpoint

GET  /v2/bot/channel/webhook/endpoint

POST /v2/bot/channel/webhook/test

# Set webhook endpoint URL

PUT https://api.line.me/v2/bot/channel/webhook/endpoint

Sets the webhook endpoint URL. It may take up to 1 minute for changes to take place due to caching.

Webhook URL validation rules

Ensure these webhook URL validation rules are met:

Enter a valid HTTPS URL.
Must be 500 characters or less.

Example request

# Rate limit

1,000 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Request body

endpoint

String

Required

A valid webhook URL.

# Response

Returns status code 200 and an empty JSON object.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid webhook endpoint URL is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get webhook endpoint information

GET https://api.line.me/v2/bot/channel/webhook/endpoint

Gets information on a webhook endpoint.

Example request

# Rate limit

1,000 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Response

Returns status code 200 and a JSON object with the following information.

endpoint

String

Webhook URL

active

Boolean

Webhook usage status. Send a webhook event from the LINE Platform to the webhook URL only if enabled.

true: Webhook usage is enabled.
false: Webhook usage is disabled.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`404`	The webhook URL isn't set to the channel.

For more information, see Status codes and Error responses in the Common specifications section.

Error response example

# Test webhook endpoint

POST https://api.line.me/v2/bot/channel/webhook/test

Checks if the configured webhook endpoint can receive a test webhook event.

Webhook URL validation rules

Ensure these webhook URL validation rules are met:

Enter a valid HTTPS URL.
Must be 500 characters or less.

Example request

# Rate limit

60 requests per hour

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Request body

endpoint

String

Optional

A webhook URL to be validated.

Behaviors with/without endpoint parameter

The behavior of this API endpoint will differ depending on if the endpoint parameter is included in, or excluded from, the Request body.

With endpoint parameter

Validates that the endpoint URL specified in the endpoint parameter is valid and, if valid, sends a test webhook event to the specified endpoint URL.

Without endpoint parameter

Sends a test webhook event to a webhook endpoint that is already set to the channel. 404 is returned if the channel doesn't have a webhook endpoint configured.

# Response

Returns status code 200 and a JSON object with the following information.

Return status code 200 for the communication request

The LINE Platform sends an HTTP POST request that doesn't include a webhook event to the webhook URL (bot server) to confirm communication. Design your bot server to return status code 200.

Example HTTP POST request without a webhook event:
```
{
  "destination": "xxxxxxxxxx",
  "events": []
}
```

success

Boolean

Result of the communication from the LINE Platform to the webhook URL.

true: Success
false: Failure

If false, see Check the reason for errors in the Messaging API documentation.

timestamp

String

See Common Properties.

statusCode

Number

The HTTP status code. If the webhook response isn't received, the status code is set to zero or a negative number.

reason

String

Reason for the response. See table below for more information.

detail

String

Details of the response. See table below for more information.

`reason`	`detail`	Description
OK	`200`	Successfully sent the webhook.
COULD_NOT_CONNECT	Failure to connect	Failed to connect to the webhook endpoint. For more information, see The reason is could_not_connect in the Messaging API documentation.
REQUEST_TIMEOUT	Request timeout	Request time out. For more information, see The reason is request_timeout in the Messaging API documentation.
ERROR_STATUS_CODE	HTTP status code (e.g. `400`)	HTTP status code error response. For more information, see The reason is error_status_code in the Messaging API documentation.
UNCLASSIFIED	N/A	Unknown error. For more information, see The reason is unclassified in the Messaging API documentation.

Response example (If the webhook is successfully sent)

Response example (If communication to the webhook URL fails due to the bot server's SSL/TLS settings)

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid webhook URL is specified.
`404`	The webhook URL isn't set to the channel.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Getting content

You can get the content that a user has sent to your LINE Official Account by using the message IDs received via the webhook.

Endpoints

GET /v2/bot/message/{messageId}/content

GET /v2/bot/message/{messageId}/content/transcoding

GET /v2/bot/message/{messageId}/content/preview

# Get content

GET https://api-data.line.me/v2/bot/message/{messageId}/content

This domain name is different from that of other endpoints

The domain name (api-data.line.me) of this endpoint is for sending and receiving large amounts of data in the LINE Platform for Messaging API. This domain name differs from that of other endpoints (api.line.me).

Gets images, videos, audio, and files sent by users using message IDs received via the webhook.

This endpoint is only available if the contentProvider.type property of webhook event objects is line.

When a user sends a large video or audio file, it may take some time until the preparation to get the binary data of the content is completed. If you try to get the content while the binary data is being prepared, the status code 202 will be returned and you can't get the binary data. You can use the Verify the preparation status of a video or audio for getting endpoint to verify whether or not binary data can be obtained.

Content sent by users may be transformed internally, such as shrinking.

No API for retrieving text

You can get the text sent by the user via the text message object of the webhook. There is no API to get the text sent by users again after receiving the webhook.

Example request

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

messageId

Required

Message ID

# Response

Returns status code 200 and the content in binary. The file format of the binary data is indicated in the Content-Type (opens new window) header of the response.

Content is automatically deleted after a certain period from when the message was sent. There is no guarantee for how long content is stored.

# Error response

Returns the following HTTP status code and an error response:

404 Not Found
410 Gone

For more information, see Status codes and Error responses in Common specifications section.

Example error response

# Verify the preparation status of a video or audio for getting

GET https://api-data.line.me/v2/bot/message/{messageId}/content/transcoding

This domain name is different from that of other endpoints

Gets the preparation status to get the video or audio sent by users using message IDs received via the webhook.

This endpoint is only available if the contentProvider.type property of webhook event objects is line.

Example request

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

messageId

Required

Message ID of video or audio

# Response

Returns status code 200 and a JSON object with the following information.

status

String

The preparation status. One of:

processing: Preparing to get content.
succeeded: Ready to get the content. You can get the content sent by users.
failed: Failed to prepare to get the content.

# Error response

Returns the following HTTP status code and an error response:

400 Bad Request
404 Not Found
410 Gone

For more information, see Status codes and Error responses in Common specifications section.

Example error response

# Get a preview image of the image or video

GET https://api-data.line.me/v2/bot/message/{messageId}/content/preview

This domain name is different from that of other endpoints

Gets a preview image of the image or video sent by users using message IDs received via the webhook. The preview image is image data converted to a smaller data size than the original content.

This endpoint is only available if the contentProvider.type property of webhook event objects is line.

Example request

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

messageId

Required

Message ID of image or video

# Response

Returns status code 200 and the preview image in binary.

Preview image is automatically deleted after a certain period from when the message was sent. There is no guarantee for how long preview image is stored.

# Error response

Returns the following HTTP status code and an error response:

400 Bad Request
404 Not Found
410 Gone

For more information, see Status codes and Error responses in Common specifications section.

Example error response

# Channel access token

You can issue, get, or revoke the channel access token required when calling the Messaging API from the app. For more information, see Channel access token in the LINE Platform basics.

Endpoints

POST /oauth2/v2.1/token

GET  /oauth2/v2.1/verify

GET  /oauth2/v2.1/tokens/kid

POST /oauth2/v2.1/revoke

POST /oauth2/v3/token

POST /v2/oauth/accessToken

POST /v2/oauth/verify

POST /v2/oauth/revoke

# Issue channel access token v2.1

POST https://api.line.me/oauth2/v2.1/token

Issues a channel access token that allows you to specify a desired validity period. This method lets you use JWT assertion for authentication.

You can issue up to 30 tokens per channel for channel access tokens v2.1. If you reach the maximum limit, additional requests of issuing channel access tokens are blocked. An expired channel access token isn't counted as issued.

Example request

# Request headers

Content-Type

Required

application/x-www-form-urlencoded

# Request body

grant_type

String

Required

client_credentials

client_assertion_type

String

Required

URL-encoded value of urn:ietf:params:oauth:client-assertion-type:jwt-bearer

client_assertion

String

Required

Specify a JSON Web Token assertion that must be generated by the client and signed with the private key of the assertion signing key.

JWT assertions must be set to expire within 30 minutes of generation. For more information about generating a JWT assertion, see Generate a JWT.

# Response

Returns a 200 HTTP status code and a JSON object with the following information.

access_token

String

Channel access token.

expires_in

Number

Amount of time in seconds from issue to expiration of the channel access token

token_type

String

Bearer

key_id

String

Unique key ID for identifying the channel access token.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: The JWT assertion verification failed. The JWT assertion has expired. The maximum number of channel access tokens that can be issued has been reached.
`404`	The signature key associated with the JWT assertion isn't registered in the channel.

Example error response

# Verify the validity of the channel access token v2.1

GET https://api.line.me/oauth2/v2.1/verify

You can verify whether a Channel access token with a user-specified expiration (Channel Access Token v2.1) is valid.

Request example

# Query parameter

access_token

Required

Channel access token with a user-specified expiration (Channel Access Token v2.1).

# Response

If the channel access token is valid, returns a 200 HTTP status code and a JSON object with this information.

client_id

String

The channel ID for which the channel access token was issued.

expires_in

Number

Number of seconds before the channel access token expires.

scope

String

Not always included

Permissions granted to the channel access token.

Response example

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: An invalidly formatted channel access token is specified. The channel access token has expired. A non-existent channel access token is specified.

Error response example

# Get all valid channel access token key IDs v2.1

GET https://api.line.me/oauth2/v2.1/tokens/kid

Gets all valid channel access token key IDs.

Example request

# Query parameters

client_assertion_type

String

Required

URL-encoded value of urn:ietf:params:oauth:client-assertion-type:jwt-bearer

client_assertion

String

Required

A JSON Web Token (JWT) (opens new window) the client needs to create and sign with the private key.

# Response

Returns a 200 HTTP status code and a JSON object with this information.

kids

Array of strings

Array of channel access token key IDs.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: The JWT assertion verification failed. The JWT assertion has expired.
`404`	The signature key associated with the JWT assertion isn't registered in the channel.

Example error response

# Revoke channel access token v2.1

POST https://api.line.me/oauth2/v2.1/revoke

Revokes a channel access token v2.1.

Revokes channel access token in these instances:

When old channel access tokens are no longer needed because channel access tokens have been reissued
When a channel access token is suspected to have been leaked

There is no need to revoke a channel access token that has already expired.

Example request

# Request body

client_id

String

Required

Channel ID

client_secret

String

Required

Channel Secret

access_token

String

Required

Channel access token

# Response

Returns status code 200 and an empty response body.

Note

No error occurs if an invalid channel access token is specified.

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: An invalidly formatted channel access token is specified. A non-existent channel access token is specified. A malformed channel access is specified.

Example error response

# Issue stateless channel access token

POST https://api.line.me/oauth2/v3/token

Issues channel access tokens that are only valid for 15 minutes. There is no limit to the number of tokens that can be issued. Once a stateless channel access token is issued, it can't be revoked.

Example of a request to issue from channel ID and channel secret

Example of a request to issue from JWT assertion

# Request headers

Content-Type

Required

application/x-www-form-urlencoded

# Request body

There are two ways to issue stateless channel access tokens. Regardless of which method is used, the format of the response body is the same:

Issue from channel ID and channel secret
Issue from JWT assertion

# Issue from channel ID and channel secret

grant_type

String

Required

client_credentials

client_id

String

Required

Channel ID. Found on the LINE Developers Console.

client_secret

String

Required

Channel secret. Found on the LINE Developers Console.

# Issue from JWT assertion

grant_type

String

Required

client_credentials

client_assertion_type

String

Required

URL-encoded value of urn:ietf:params:oauth:client-assertion-type:jwt-bearer

client_assertion

String

Required

Specify a JSON Web Token assertion that must be generated by the client and signed with the private key of the assertion signing key.

JWT assertions must be set to expire within 30 minutes of generation. For more information about generating a JWT assertion, see Generate a JWT.

# Response

Returns a 200 HTTP status code and a JSON object with the following information.

token_type

String

Bearer

access_token

String

Channel access token

expires_in

Number

The number of seconds between the issuance of the channel access token and its expiration

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: An invalid channel ID is specified. An invalid channel secret is specified. The JWT assertion verification failed. The JWT assertion has expired.
`404`	The signature key associated with the JWT assertion isn't registered in the channel.

Example error response

# Issue short-lived channel access token

POST https://api.line.me/v2/oauth/accessToken

Issues a short-lived channel access token that's valid for 30 days.

You can issue up to 30 tokens per channel for short-lived channel access tokens. If the maximum is exceeded, the oldest existing channel access token is revoked. An expired channel access token isn't counted as issued.

Tip

For Messaging API channels, you can issue a long-term channel access token, a channel access token with a user-specified expiration (channel access token v2.1), or a stateless channel access token. For more information, see Channel access token in the LINE Platform basics.
Channel access tokens for LINE Login channels can also be issued with this API. The channel access token for the LINE Login channel is available in the LIFF Server API.

Example request

# API Playground

Try

# Rate limit

370 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Content-Type

Required

application/x-www-form-urlencoded

# Request body

grant_type

String

Required

client_credentials

client_id

String

Required

Channel ID. Found on the LINE Developers Console.

client_secret

String

Required

Channel secret. Found on the LINE Developers Console.

# Response

Returns a 200 HTTP status code and a JSON object with the following information.

access_token

String

Short-lived channel access token. Valid for 30 days.

Note

Channel access tokens cannot be refreshed.

expires_in

Number

Time until channel access token expires in seconds from time the token is issued

token_type

String

Bearer

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: An invalid channel ID is specified. An invalid channel secret is specified. The request parameters are in the wrong format.
`429`	Exceeded the rate limit.

Example error response

# Verify the validity of short-lived and long-lived channel access tokens

POST https://api.line.me/v2/oauth/verify

You can verify whether a short-lived channel access token or a long-lived channel access token is valid.

Request example

# Request header

Content-Type

Required

application/x-www-form-urlencoded

# Request body

access_token

String

Required

A short-lived or long-lived channel access token.

# Response

If the channel access token is valid, returns a 200 HTTP status code and a JSON object with this information.

client_id

String

The channel ID for which the channel access token was issued.

expires_in

Number

Number of seconds before the channel access token expires.

scope

String

Not always included

Permissions granted to the channel access token.

Response example

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: An invalid channel access token is specified. An invalidly formatted channel access token is specified. The channel access token has expired.

Error response example

# Revoke short-lived or long-lived channel access token

POST https://api.line.me/v2/oauth/revoke

Revokes a short-lived or long-lived channel access token.

Revokes channel access token in these instances:

When old channel access tokens are no longer needed because channel access tokens have been reissued
When a channel access token is suspected to have been leaked

There is no need to revoke a channel access token that has already expired.

Example request

# API Playground

Try

# Request headers

Content-Type

Required

application/x-www-form-urlencoded

# Request body

access_token

String

Required

Channel access token

# Response

Returns status code 200 and an empty response body. No error occurs if an invalid channel access token is specified.

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalidly formatted channel access token is specified.

Example error response

# Message

You can send a message and obtain information about the sent message.

Endpoints

POST /v2/bot/message/reply

POST /v2/bot/message/push

POST /v2/bot/message/multicast

POST /v2/bot/message/narrowcast

GET  /v2/bot/message/progress/narrowcast

POST /v2/bot/message/broadcast

POST /v2/bot/chat/loading/start

GET  /v2/bot/message/quota

GET  /v2/bot/message/quota/consumption

GET  /v2/bot/message/delivery/reply

GET  /v2/bot/message/delivery/push

GET  /v2/bot/message/delivery/multicast

GET  /v2/bot/message/delivery/broadcast

POST /v2/bot/message/validate/reply

POST /v2/bot/message/validate/push

POST /v2/bot/message/validate/multicast

POST /v2/bot/message/validate/narrowcast

POST /v2/bot/message/validate/broadcast

# Send reply message

POST https://api.line.me/v2/bot/message/reply

Sends a reply message in response to an event from a user, group chat, or multi-person chat. To send reply messages, you need a reply token which is included in the webhook event object.

When an event occurs, you'll be notified by a webhook. If the event can be responded to, the reply token is issued.

You can display loading animations while preparing a reply message

After your LINE Official Account receives a message from a user, the response may takes some time due to message preparation or reservation processing. In such cases, you can visually tell the user that you want them to wait by displaying a loading animation. For more information, see Display a loading animation in the Messaging API documentation.

# Reply token

When using reply tokens, check the following:

Reply tokens can only be used once.
Reply tokens must be used within one minute after receiving the webhook. Use beyond one minute isn't guaranteed to work.
Reply tokens included in redelivered webhooks can also be used within one minute after receiving the redelivered webhook. However, the reply token can't be used in the following cases:
- The reply token included in the original webhook has already been used.
- 20 minutes have passed since the event occurred.

Reply tokens should be used as soon as possible

The time limit for reply tokens is subject to change without notice. In addition, the actual duration of use may vary due to network delays and other factors.

For this reason, don't rely on the time limit for implementation. Also, use reply tokens as soon as possible.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Content-Type

Required

application/json

Authorization

Required

Bearer {channel access token}

# Request body

replyToken

String

Required

Reply token received via webhook

messages

Array of message objects

Required

Messages to send
Max: 5

By using the Validate message objects of a reply message endpoint, you can validate the message objects.

notificationDisabled

Boolean

Optional

true: The user doesn't receive a push notification when the message is sent.
false: The user receives a push notification when the message is sent (unless they have disabled push notifications in LINE and/or their device).

Default: false

# Response

Returns status code 200 and a JSON object with the following information.

sentMessages

Array

Array of sent messages.
Max: 5

sentMessages.id

Number

ID of the sent message.

sentMessages.quoteToken

String

Not always included

Quote token of the message. Only included when a message object that can be specified as a quote target was sent as a reply message. For more information, see Get quote tokens in the Messaging API documentation.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't send the message. Consider these reasons: An invalid reply token is specified. An invalid message object is specified.

For more information, see Status codes and Error responses in Common specifications section.

The messages aren't sent if an error is returned.

Example error response

# Send push message

POST https://api.line.me/v2/bot/message/push

Sends a message to a user, group chat, or multi-person chat at any time.

# Conditions for sending push message

You can send a push message under one of the following conditions:

Users who have added your LINE Official Account as a friend
Group chats or multi-person chats which your LINE Official Account has been joined
Users who have sent a message to your LINE Official Account within 7 days in the one-to-one chat (*)

When you send a push message to these users, status code 200 will be returned, but the users won't receive the message:

Users who deleted their LINE accounts
Users who blocked the LINE Official Account from which the push message was sent
Users who haven't added your LINE Official Account as a friend (*)

*Users can also send a message to your LINE Official Account which they haven't added as a friend. If your LINE Official Account receives a message in the one-to-one chat from a user who hasn't been a friend of yours, you can send a push message to the user within 7 days of receiving the message.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Content-Type

Required

application/json

Authorization

Required

Bearer {channel access token}

X-Line-Retry-Key

Optional

Retry key. Specifies the UUID in hexadecimal format (e.g., 123e4567-e89b-12d3-a456-426614174000) generated by any method. The retry key isn't generated by LINE. Each developer must generate their own retry key. For more information, see Retry failed API requests in the Messaging API documentation.

# Request body

String

Required

ID of the target recipient. Use a userId, groupId, or roomId value returned in a webhook event object.

messages

Array of message objects

Required

Messages to send
Max: 5

By using the Validate message objects of a push message endpoint, you can validate the message objects.

notificationDisabled

Boolean

Optional

true: The user doesn't receive a push notification when the message is sent.
false: The user receives a push notification when the message is sent (unless they have disabled push notifications in LINE and/or their device).

Default: false

customAggregationUnits

Array of strings

Optional

Name of aggregation unit. Case-sensitive. For example, Promotion_a and Promotion_A are regarded as different unit names.
Max unit number: 1
Max character limit: 30
Supported character types: Half-width alphanumeric characters (a-z, A-Z, 0-9) and underscore (_)

For more information about assigning a unit name, see Assign a unit name to any aggregation unit when sending messages in the Messaging API documentation.

# Response

Returns status code 200 and a JSON object with the following information.

sentMessages

Array

Array of sent messages.
Max: 5

sentMessages.id

Number

ID of the sent message.

sentMessages.quoteToken

String

Not always included

Quote token of the message. Only included when a message object that can be specified as a quote target was sent as a push message. For more information, see Get quote tokens in the Messaging API documentation.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't send the message. Consider these reasons: A user ID that doesn't exist in this channel is specified, such as a user ID obtained from channels under other providers. A non-existent group or a group that your LINE Official Account doesn't participate in is specified. A non-existent multi-person chat or a multi-person chat that your LINE Official Account doesn't participate in is specified. An invalid message object is specified.
`409`	A request containing the same retry key has already been accepted. For more information, see Response if the request has already been accepted in the Retrying an API request.
`429`	The number of requests has exceeded the limit. Consider these reasons: Exceeded the rate limit for this endpoint. A large number of messages were sent to the same user. Exceeded the target limit for sending messages this month. For more information about the target limit for sending messages, see Messaging API pricing in the Messaging API documentation.

For more information, see Status codes and Error responses in Common specifications section.

The messages aren't sent if an error is returned.

Example error response

# Send multicast message

POST https://api.line.me/v2/bot/message/multicast

An API that efficiently sends the same message to multiple user IDs. You can't send messages to group chats or multi-person chats.

It is also possible to send a multicast message to one user. However, we recommend using push message when the recipient is only one user. Push message is suitable for sending a message for the purpose of low latency.

# Conditions for sending multicast message

You can send a multicast message to users who have added your LINE Official Account as a friend.

When you send a multicast message to these users, status code 200 will be returned, but the users won't receive the message:

Users who deleted their LINE accounts
Users who blocked your LINE Official Account from which the multicast message was sent
Users who haven't added your LINE Official Account as a friend
User IDs that don't exist in the channel such as those that were taken from another channel under a different provider

Example request

# Rate limit

200 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Content-Type

Required

application/json

Authorization

Required

Bearer {channel access token}

X-Line-Retry-Key

Optional

# Request body

Array of strings

Required

Array of user IDs. Use userId values which are returned in webhook event objects. Do not use LINE IDs found on LINE.
Max: 500 user IDs

messages

Array of message objects

Required

Messages to send
Max: 5

By using the Validate message objects of a multicast message endpoint, you can validate the message objects.

notificationDisabled

Boolean

Optional

true: The user doesn't receive a push notification when the message is sent.
false: The user receives a push notification when the message is sent (unless they have disabled push notifications in LINE and/or their device).

Default: false

customAggregationUnits

Array of strings

Optional

For more information about assigning a unit name, see Assign a unit name to any aggregation unit when sending messages in the Messaging API documentation.

# Response

Returns status code 200 and an empty JSON object.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't send the message. Consider these reasons: A user ID that doesn't exist in this channel is specified, such as a user ID obtained from channels under other providers. A non-user ID, such as a group ID, is specified. An invalid message object is specified.
`409`	A request containing the same retry key has already been accepted. For more information, see Response if the request has already been accepted in the Retrying an API request.
`429`	The number of requests has exceeded the limit. Consider these reasons: Exceeded the rate limit for this endpoint. Exceeded the target limit for sending messages this month. For more information about the target limit for sending messages, see Messaging API pricing in the Messaging API documentation.

For more information, see Status codes and Error responses in Common specifications section.

The messages aren't sent to any user if an error is returned.

Example error response

# Send narrowcast message

POST https://api.line.me/v2/bot/message/narrowcast

Sends a message to multiple users. You can specify recipients using attributes (such as age, gender, OS, and region) or by retargeting (audiences). Messages can't be sent to group chats or multi-person chats.

Narrowcast messages are sent asynchronously in the background after the LINE Platform receives the request. Therefore, even if a request to send a narrowcast message is successful, failures can occur once the message starts to be delivered. You can verify if the message was sent successfully by getting the progress of the narrowcast message.

About sending narrowcast messages to users under the age of 20 in Thailand

When you filter recipients by certain conditions, users under the age of 20 in Thailand will be excluded.

# Conditions for sending narrowcast message

You can send a narrowcast message to users who have added your LINE Official Account as a friend.

If you send a narrowcast message to the following users, status code 202 will be returned, but the users will be excluded from recipients:

Users who deleted their LINE accounts
Users who blocked your LINE Official Account
Users who haven't added your LINE Official Account as a friend
User IDs that don't exist in the channel such as those that were taken from another channel under a different provider

# Restrictions on sending messages using attributes and audiences

When using attributes or audiences, restrictions to protect the user's privacy may apply to the sent message, depending on the conditions of sending. If the sent message meets the restrictions, an error will occur when sending a request or delivering a message.

To specify attribute data as a condition of sending, your LINE Official Account's target reach number must be 100 people or more. Returns a 403 HTTP status code if your target reach is less than 100 people.
When you specify attribute data or audiences (*) as a condition of sending, the final number of recipients must be 50 or more. The 202 HTTP status code will be also returned if the final number of recipients is less than 50 people, but an error will occur when message delivery starts.
When you specify more than one audience as a condition of sending, each audience (*) must have at least 50 recipients. The 202 HTTP status code will be also returned if the audience has less than 50 recipients, but an error will occur when message delivery starts.

* The following audiences have no restrictions regarding the number of recipients. However, for audiences created by other LINE Official Account, the restrictions apply even to the following audiences:

Audiences created by uploading user IDs from LINE Official Account Manager or the Messaging API
Chat tag audiences

# Note regarding the number of remaining messages to be sent during the current month

In LINE Official Account Manager and the Messaging API, the number of messages scheduled to be sent will be reserved for the remaining messages until the number of messages to be sent is determined after the sending messages is started. If the number of messages scheduled to be sent can't be reserved at the start of the message delivery, the message will fail to deliver.

Narrowcast messages require reservations for the target reach of the LINE Official Account, regardless of the actual number of recipients. Therefore, when sending narrowcast messages, take note of the following:

If the number of remaining messages that can be sent during the current month is less than the target reach of your LINE Official Account, an error will occur when starting to deliver narrowcast messages.
Even though the actual number of recipients is sufficiently small, the number of remaining messages for the current month may be temporarily depleted, making it impossible to send other messages during the delivery of narrowcast messages.

You may be able to avoid these situations by limiting the number of messages to send when sending a narrowcast message. For more information, see Limit objects on the Request body.

Example request

# Rate limit

60 requests per hour

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

X-Line-Retry-Key

Optional

# Request body

messages

Array of message objects

Required

Messages to send
Max: 5

By using the Validate message objects of a narrowcast message endpoint, you can validate the message objects.

recipient

Object

Optional

Recipient object. You can use up to a combined total of 10 audiences and request IDs of the narrowcast messages previously sent to specify message recipients. There is no upper limit on the number of operator objects that you can specify.
If this is omitted, messages will be sent to all users who have added your LINE Official Account as a friend.

filter.demographic

Object

Optional

Demographic filter object. You can use friends' attributes to filter the list of recipients.
If this is omitted, messages are sent to everyone—including users with attribute values of "unknown".

limit

Object

Optional

Limit object. You can set a limit on the maximum number of narrowcast messages that can be sent.

notificationDisabled

Boolean

Optional

true: The user doesn't receive a push notification when the message is sent.
false: The user receives a push notification when the message is sent (unless they have disabled push notifications in LINE and/or on their device).

Default: false

# Recipient objects

Recipient objects represent audience objects or redelivery objects. You can specify recipients based on a combination of criteria using logical operator objects. You can specify up to a combined total of 10 audience objects and redelivery objects per request.

# Audience objects

type

String

Required

audience

audienceGroupId

Number

Required

The audience ID. Create audiences with the manage audience API.

# Redelivery object

type

String

Required

redelivery

requestId

String

Required

The request ID of the narrowcast message previously sent. The request IDs is an ID issued for each Messaging API request. It is included in the response header.

Conditions for specifying the request ID

The request ID specified in the requestId property must satisfy all of these conditions. If you specify the request ID that does not satisfy these conditions, a 400 HTTP status code is returned.

The request ID was issued by the delivering a narrowcast message.
The narrowcast message was delivered within less than 14 days (336 hours) from the timestamp displayed in acceptedTime of the Get narrowcast message status API endpoint.
The delivery process is completed (The value of the phase property is succeeded in the response of the Get narrowcast message status API endpoint).

# Logical operator objects

Use logical AND, OR, and NOT operators to combine multiple recipient objects together.

type

String

Required

operator

and

Array of recipient objects

Create a new recipient object by taking the logical conjunction (AND) of the specified array of recipient objects.

Audience 1 and Audience 2

Array of recipient objects

Create a new recipient object by taking the logical disjunction (OR) of the specified array of recipient objects.

Audience 1 or Audience 2

not

Recipient object

Create a new recipient object that excludes the specified recipient object.

not Audience 2

* Be sure to specify only one of these three properties (and, or, or not). You cannot specify an empty array.

Example recipient object

# Demographic filter objects

Demographic filter objects represent criteria (e.g. age, gender, OS, region, and friendship duration) on which to filter the list of recipients. You can filter recipients based on a combination of different criteria using logical operator objects.

Using attribute data

The attribute data used for demographic filters is approximately 3 days old (may be earlier or later).
If you don't specify any attributes, messages are sent to everyone—even users with attribute values of "unknown".
To use attribute data, your "Target reach" number must be 100 or more.
- Returns a 403 HTTP status code if your Target reach is less than 100.

# Gender

type

String

Required

gender

oneOf

Array of strings

Required

Send messages to users of a given gender. One of:

male
female

# Age

This lets you filter recipients with a given age range.

type

String

Required

age

gte

String

Send messages to users at least as old as the specified age.

You can specify one of the following values. However, specify a value smaller than the value specified by the lt property.

age_15
age_20
age_25
age_30
age_35
age_40
age_45
age_50
age_55
age_60
age_65
age_70

String

Send messages to users younger than the specified age.

You can specify one of the following values. However, specify a value greater than the value specified by the gte property.

age_15
age_20
age_25
age_30
age_35
age_40
age_45
age_50
age_55
age_60
age_65
age_70

* Be sure to specify either gte, lt, or both.

# Operating system

type

String

Required

appType

oneOf

Array of strings

Required

Send messages to users with the specified OS. One of:

ios
android

# Region

type

String

Required

area

oneOf

Array of strings

Required

Send messages to users in the specified region. One of:
日本 // JP (country code=392)

jp_01: 北海道 // Hokkaido
jp_02: 青森県 // Aomori
jp_03: 岩手県 // Iwate
jp_04: 宮城県 // Miyagi
jp_05: 秋田県 // Akita
jp_06: 山形県 // Yamagata
jp_07: 福島県 // Fukushima
jp_08: 茨城県 // Ibaraki
jp_09: 栃木県 // Tochigi
jp_10: 群馬県 // Gunma
jp_11: 埼玉県 // Saitama
jp_12: 千葉県 // Chiba
jp_13: 東京都 // Tokyo
jp_14: 神奈川県 // Kanagawa
jp_15: 新潟県 // Niigata
jp_16: 富山県 // Toyama
jp_17: 石川県 // Ishikawa
jp_18: 福井県 // Fukui
jp_19: 山梨県 // Yamanashi
jp_20: 長野県 // Nagano
jp_21: 岐阜県 // Gifu
jp_22: 静岡県 // Shizuoka
jp_23: 愛知県 // Aichi
jp_24: 三重県 // Mie
jp_25: 滋賀県 // Shiga
jp_26: 京都府 // Kyoto
jp_27: 大阪府 // Osaka
jp_28: 兵庫県 // Hyougo
jp_29: 奈良県 // Nara
jp_30: 和歌山県 // Wakayama
jp_31: 鳥取県 // Tottori
jp_32: 島根県 // Shimane
jp_33: 岡山県 // Okayama
jp_34: 広島県 // Hiroshima
jp_35: 山口県 // Yamaguchi
jp_36: 徳島県 // Tokushima
jp_37: 香川県 // Kagawa
jp_38: 愛媛県 // Ehime
jp_39: 高知県 // Kouchi
jp_40: 福岡県 // Fukuoka
jp_41: 佐賀県 // Saga
jp_42: 長崎県 // Nagasaki
jp_43: 熊本県 // Kumamoto
jp_44: 大分県 // Oita
jp_45: 宮崎県 // Miyazaki
jp_46: 鹿児島県 // Kagoshima
jp_47: 沖縄県 // Okinawa

台湾 // TW (country code=158)

tw_01: 台北市 // Taipei City
tw_02: 新北市 // New Taipei City
tw_03: 桃園市 // Taoyuan City
tw_04: 台中市 // Taichung City
tw_05: 台南市 // Tainan City
tw_06: 高雄市 // Kaohsiung City
tw_07: 基隆市 // Keelung City
tw_08: 新竹市 // Hsinchu City
tw_09: 嘉義市 // Chiayi City
tw_10: 新竹県 // Hsinchu County
tw_11: 苗栗県 // Miaoli County
tw_12: 彰化県 // Changhua County
tw_13: 南投県 // Nantou County
tw_14: 雲林県 // Yunlin County
tw_15: 嘉義県 // Chiayi County
tw_16: 屏東県 // Pingtung County
tw_17: 宜蘭県 // Yilan County
tw_18: 花蓮県 // Hualien County
tw_19: 台東県 // Taitung County
tw_20: 澎湖県 // Penghu County
tw_21: 金門県 // Kinmen County
tw_22: 連江県 // Lienchiang County

タイ // TH (country code=764)

th_01: バンコク // Bangkok
th_02: パタヤ // Pattaya
th_03: 北部 // Northern
th_04: 中央部 // Central
th_05: 南部 // Southern
th_06: 東部 // Eastern
th_07: 東北部 // NorthEastern
th_08: 西部 // Western

# Friendship duration

This lets you filter recipients with a given range of friendship durations.

type

String

Required

subscriptionPeriod

gte

String

Send messages to users who have been friends of yours for at least the specified number of days.
You can specify one of the following values. However, specify a value smaller than the value specified by the lt property.

day_7
day_30
day_90
day_180
day_365

String

Send messages to users who have been friends of yours for less than the specified number of days.
You can specify one of the following values. However, specify a value greater than the value specified by the gte property.

day_7
day_30
day_90
day_180
day_365

* Be sure to specify either gte, lt, or both.

# Logical operator objects

Use logical AND, OR, and NOT operators to combine multiple demographic filter objects together. You can specify up to 10 demographic filter objects per request.

type

String

Required

operator

and

Array of demographic filter objects

Create a new demographic filter object by taking the logical conjunction (AND) of the specified array of demographic filter objects.

Array of demographic filter objects

Create a new demographic filter object by taking the logical disjunction (OR) of the specified array of demographic filter objects.

not

Demographic filter object

Create a new demographic filter object that excludes the specified array of demographic filter objects.

* Be sure to specify only one of these three properties (and, or, or not). You cannot specify an empty array.

Example demographic filter object for gender

# Limit objects

You can set a limit on the maximum number of narrowcast messages that can be sent by setting limit objects.

max

Number

Optional

The maximum number of narrowcast messages to send. Use this parameter to limit the number of narrowcast messages sent. The recipients will be chosen at random.

upToRemainingQuota

Boolean

Optional

If true, the message will be sent within the maximum number of deliverable messages. The default value is false. Targets will be selected at random.

Example limit object

This table shows the relationship between the max property settings and upToRemainingQuota property settings, and the number of reservations and the maximum number of sending.

`max` property	`upToRemainingQuota` property	Number of reservation and maximum number of sending
Not set	false	Number of target reach
Any number	false	Minimum value from target reach and `max` property
Not set	true	Minimum value from target reach and estimated upper limit for the current month
Any number	true	Minimum value from target reach, estimated upper limit for the current month, and `max` property

# Response

Returns the 202 HTTP status code and an empty JSON object.

Narrowcast messages are sent asynchronously. For more information on how to check the status of a narrowcast message, see Get narrowcast message status.

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't send the message. Consider these reasons: An invalid request ID is specified in the redelivery object. An invalid audience is specified, such as a status other than `READY`. An invalid message object is specified.
`403`	Not enough recipients. For more information, see Restrictions on sending messages using attributes and audiences.
`409`	A request containing the same retry key has already been accepted. For more information, see Response if the request has already been accepted in the Retrying an API request.
`429`	The number of requests has exceeded the limit. Consider these reasons: Exceeded the rate limit for this endpoint. Exceeded the target limit for sending messages this month. For more information about the target limit for sending messages, see Messaging API pricing in the Messaging API documentation.

For more information, see Status codes and Error responses in Common specifications section.

The messages aren't sent to any user if an error is returned.

Error response example

# Get narrowcast message status

GET https://api.line.me/v2/bot/message/progress/narrowcast

Gets the status of a narrowcast message.

Narrowcast messages can't be sent if the number of recipients is less than the required amount

To prevent someone from guessing the recipients' attributes, narrowcast messages can't be sent when the number of recipients is below the required minimum amount. For more information, see Restrictions on sending messages using attributes and audiences.

Window of availability for status requests

You can't get the status of a narrowcast message anymore after 14 days (336 hours) past the timestamp displayed in acceptedTime.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

requestId

Required

The narrowcast message's request ID. Each Messaging API request has a request ID. Find it in the response headers.

# Response

Returns a 200 HTTP status code and a JSON object with the following information.

phase

String

The current status. One of:

waiting: Messages are not yet ready to be sent. They are currently being filtered or processed in some way.
sending: Messages are currently being sent.
succeeded: Messages were sent successfully. This may not mean the messages were successfully received.
failed: Messages failed to be sent. Use the failedDescription property to find the cause of the failure.

successCount

Number

Not always included

The number of users who successfully received the message. *

failureCount

Number

Not always included

The number of users who failed to send the message. *
Even if the phase is succeeded, some users may not be able to receive narrowcast messages unless the failureCount is 0. For example, if a user blocks the LINE Official Account while sending a narrowcast message, it will be added to the failureCount.

targetCount

Number

Not always included

The number of intended recipients of the message. *

failedDescription

String

Not always included

The reason the message failed to be sent. This is only included with a phase property value of failed.

errorCode

Number

Not always included

Error summary. This is only included with a phase property value of failed.
One of:

1: An internal error occurred.
2: An error occurred because there weren't enough recipients.
3: A conflict error of requests occurs because a request that has already been accepted is retried.
4: An audience of less than 50 recipients is included as a condition of sending.

acceptedTime

String

Narrowcast message request accepted time in milliseconds.

Format: ISO 8601 (opens new window) (e.g. 2020-12-03T10:15:30.121Z)
Timezone: UTC

completedTime

String

Not always included

Processing of narrowcast message request completion time in milliseconds. Returned when the phase property is succeeded or failed.

Format: ISO 8601 (opens new window) (e.g. 2020-12-03T10:15:30.121Z)
Timezone: UTC

* Not available when the phase property is waiting.

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid request ID is specified.
`404`	Unable to get the status. Consider these reasons: The period of time to get a status has expired. A request ID other than narrowcast message is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Send broadcast message

POST https://api.line.me/v2/bot/message/broadcast

Sends a message to all users who are friends with your LINE Official Account at any time.

Example request

# Rate limit

60 requests per hour

For more information on rate limits, see Rate limits.

# Request headers

Content-Type

Required

application/json

Authorization

Required

Bearer {channel access token}

X-Line-Retry-Key

Optional

# Request body

messages

Array of message objects

Required

Messages to send
Max: 5

By using the Validate message objects of a broadcast message endpoint, you can validate the message objects.

notificationDisabled

Boolean

Optional

true: The user doesn't receive a push notification when the message is sent.
false: The user receives a push notification when the message is sent (unless they have disabled push notifications in LINE and/or their device).

Default: false

# Response

Returns status code 200 and an empty JSON object.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid message object is specified.
`409`	A request containing the same retry key has already been accepted. For more information, see Response if the request has already been accepted in the Retrying an API request.
`429`	The number of requests has exceeded the limit. Consider these reasons: Exceeded the rate limit for this endpoint. Exceeded the target limit for sending messages this month. For more information about the target limit for sending messages, see Messaging API pricing in the Messaging API documentation.

For more information, see Status codes and Error responses in Common specifications section.

The messages aren't sent if an error is returned.

Example error response

# Display a loading animation

POST https://api.line.me/v2/bot/chat/loading/start

Display a loading animation in one-on-one chats between users and LINE Official Accounts.

The loading animation will automatically disappear after the specified number of seconds (5 to 60 seconds) has elapsed or when a new message arrives from your LINE Official Account.

The loading animation is only displayed when the user is viewing the chat screen with your LINE Official Account. If you request to display the loading animation when the user isn't viewing the chat screen, no notification will be displayed. Even if the user opens the chat screen later, the animation won't be displayed.

If you request to display the loading animation again while it is still visible, the animation will continue to be displayed and the time until it disappears will be overridden by the number of seconds specified in the second request.

A loading animation will be displayed on the following versions of LINE:

LINE for iOS or Android: 13.16.0 or later

For more information, see Display a loading animation in the Messaging API documentation.

Example request

# Rate limit

100 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Content-Type

Required

application/json

Authorization

Required

Bearer {channel access token}

# Request body

chatId

String

Required

User ID of the target user for whom the loading animation is to be displayed.

For more information on how to get user IDs, see Get user IDs in the Messaging API documentation.

loadingSeconds

Number

Optional

Number of seconds to display a loading animation. You can specify a any one of 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, or 60.

The default value is 20.

# Response

Returns status code 202 and an empty JSON object.

If you request to display a loading animation to the following user, the status code 202 will be returned, but the loading animation won't be displayed:

Users who aren't opening a chat screen with your LINE Official Account
Users who haven't added your LINE Official Account as a friend
Users who have blocked your LINE Official Account
Users who deleted their LINE accounts

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't display the loading animation. Consider these reasons: An invalid number of seconds is specified. An invalid user ID is specified. A group chat or a multi-person chat is specified.

For more information, see Status codes and Error responses in the Common specifications section.

No loading animation is displayed if an error is returned.

Example error response

# Get the target limit for sending messages this month

GET https://api.line.me/v2/bot/message/quota

Gets the target limit for sending messages in the current month. The total number of the free messages and the additional messages is returned.

The number of messages retrieved by this endpoint includes the number of messages sent from LINE Official Account Manager.

Set a target limit for the additional messages with LINE Official Account Manager. For more information about configuration, see Using and billing (plan changes and payment management) (opens new window) (only available in Japanese) in LINE for Business.

Example request

# API Playground

Try

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Response

Returns status code 200 and a JSON object with the following information.

type

String

One of the following values to indicate whether a target limit is set or not.

none: This indicates that a target limit is not set.
limited: This indicates that a target limit is set.

value

Number

Not always included

The target limit for sending messages in the current month. This property is returned when the type property has a value of limited.

Example response

# Error Response

For more information, see Status codes and Error responses in the Common specifications section.

# Get number of messages sent this month

GET https://api.line.me/v2/bot/message/quota/consumption

Gets the number of messages sent in the current month.

The number of messages retrieved by this operation includes the number of messages sent from LINE Official Account Manager.

The number of messages retrieved by this operation is approximate. To get the correct number of sent messages, use LINE Official Account Manager or execute API operations for getting the number of sent messages.

Example request

# API Playground

Try

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Response

Returns status code 200 and a JSON object with the following information.

totalUsage

Number

The number of sent messages in the current month

Example response

# Error Response

For more information, see Status codes and Error responses in the Common specifications section.

# Get number of sent reply messages

GET https://api.line.me/v2/bot/message/delivery/reply

Gets the number of messages sent with the /bot/message/reply endpoint.

The number of messages retrieved by this operation does not include the number of messages sent from LINE Official Account Manager.

Example request

# API Playground

Try

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

date

Required

Date the messages were sent

Format: yyyyMMdd (e.g. 20191231)
Timezone: UTC+9

# Response

Returns status code 200 and a JSON object with the following information.

status

String

Status of the counting process. One of the following values is returned:

ready: You can get the number of messages.
unready: The message counting process for the date specified in date has not been completed yet. Retry your request later. Normally, the counting process is completed within the next day.
out_of_service: The date specified in date is earlier than March 31, 2018, when the operation of the counting system started.

success

Number

Not always included

The number of messages sent with the Messaging API on the date specified in date. The response has this property only when the value of status is ready.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid date format is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get number of sent push messages

GET https://api.line.me/v2/bot/message/delivery/push

Gets the number of messages sent with the /bot/message/push endpoint.

The number of messages retrieved by this operation does not include the number of messages sent from LINE Official Account Manager.

Example request

# API Playground

Try

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

date

Required

Date the messages were sent

Format: yyyyMMdd (e.g. 20191231)
Timezone: UTC+9

# Response

Returns status code 200 and a JSON object with the following information.

status

String

Status of the counting process. One of the following values is returned:

ready: You can get the number of messages.
unready: The message counting process for the date specified in date has not been completed yet. Retry your request later. Normally, the counting process is completed within the next day.
out_of_service: The date specified in date is earlier than March 31, 2018, when the operation of the counting system started.

success

Number

Not always included

The number of messages sent with the Messaging API on the date specified in date. The response has this property only when the value of status is ready.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid date format is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get number of sent multicast messages

GET https://api.line.me/v2/bot/message/delivery/multicast

Gets the number of messages sent with the /bot/message/multicast endpoint.

The number of messages retrieved by this operation does not include the number of messages sent from LINE Official Account Manager.

Example request

# API Playground

Try

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

date

Required

Date the messages were sent

Format: yyyyMMdd (e.g. 20191231)
Timezone: UTC+9

# Response

Returns status code 200 and a JSON object with the following information.

status

String

Status of the counting process. One of the following values is returned:

ready: You can get the number of messages.
unready: The message counting process for the date specified in date has not been completed yet. Retry your request later. Normally, the counting process is completed within the next day.
out_of_service: The date specified in date is earlier than March 31, 2018, when the operation of the counting system started.

success

Number

Not always included

The number of messages sent with the Messaging API on the date specified in date. The response has this property only when the value of status is ready.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid date format is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get number of sent broadcast messages

GET https://api.line.me/v2/bot/message/delivery/broadcast

Gets the number of messages sent with the /bot/message/broadcast endpoint.

The number of messages retrieved by this operation does not include the number of messages sent from LINE Official Account Manager.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

date

Required

Date the messages were sent

Format: yyyyMMdd (e.g. 20191231)
Timezone: UTC+9

# Response

Returns status code 200 and a JSON object with the following information.

status

String

Status of the counting process. One of the following values is returned:

ready: You can get the number of messages.
unready: The message counting process for the date specified in date has not been completed yet. Retry your request later. Normally, the counting process is completed within the next day.
out_of_service: The date specified in date is earlier than March 31, 2018, when the operation of the counting system started.

success

Number

Not always included

The number of messages sent with the Messaging API on the date specified in date. The response has this property only when the value of status is ready.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid date format is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Validate message objects of a reply message

POST https://api.line.me/v2/bot/message/validate/reply

You can validate that an array of message objects is valid as a value for the messages property of the request body for the Send reply message endpoint. This endpoint doesn't validate the values of the properties other than the messages property.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Request body

messages

Array of objects

Required

Array of message objects to validate

# Response

Returns status code 200 and an empty JSON object.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid message object is specified.

For more information, see Status codes and Error responses in Common specifications section.

Error response example (If more message objects are specified than the maximum number)

Error response example (If more characters are specified in a text message than the maximum number of characters)

# Validate message objects of a push message

POST https://api.line.me/v2/bot/message/validate/push

You can validate that an array of message objects is valid as a value for the messages property of the request body for the Send push message endpoint. This endpoint doesn't validate the values of the properties other than the messages property.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Request body

messages

Array of objects

Required

Array of message objects to validate

# Response

Returns status code 200 and an empty JSON object.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid message object is specified.

For more information, see Status codes and Error responses in Common specifications section.

Error response example (If more message objects are specified than the maximum number)

Error response example (If more characters are specified in a text message than the maximum number of characters)

# Validate message objects of a multicast message

POST https://api.line.me/v2/bot/message/validate/multicast

You can validate that an array of message objects is valid as a value for the messages property of the request body for the Send multicast message endpoint. This endpoint doesn't validate the values of the properties other than the messages property.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Request body

messages

Array of objects

Required

Array of message objects to validate

# Response

Returns status code 200 and an empty JSON object.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid message object is specified.

For more information, see Status codes and Error responses in Common specifications section.

Error response example (If more message objects are specified than the maximum number)

Error response example (If more characters are specified in a text message than the maximum number of characters)

# Validate message objects of a narrowcast message

POST https://api.line.me/v2/bot/message/validate/narrowcast

You can validate that an array of message objects is valid as a value for the messages property of the request body for the Send narrowcast message endpoint. This endpoint doesn't validate the values of the properties other than the messages property.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Request body

messages

Array of objects

Required

Array of message objects to validate

# Response

Returns status code 200 and an empty JSON object.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid message object is specified.

For more information, see Status codes and Error responses in Common specifications section.

Error response example (If more message objects are specified than the maximum number)

Error response example (If more characters are specified in a text message than the maximum number of characters)

# Validate message objects of a broadcast message

POST https://api.line.me/v2/bot/message/validate/broadcast

You can validate that an array of message objects is valid as a value for the messages property of the request body for the Send broadcast message endpoint. This endpoint doesn't validate the values of the properties other than the messages property.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Request body

messages

Array of objects

Required

Array of message objects to validate

# Response

Returns status code 200 and an empty JSON object.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid message object is specified.

For more information, see Status codes and Error responses in Common specifications section.

Error response example (If more message objects are specified than the maximum number)

Error response example (If more characters are specified in a text message than the maximum number of characters)

# Retrying an API request

By including a retry key (X-Line-Retry-Key) in the HTTP header of a push message, multicast message, narrowcast message, or broadcast message, the same API request can be reattempted to prevent duplicate processing.

The retry key management period on the LINE Platform side is 24 hours. If you use the same retry key for more than 24 hours, the request will be treated as a new API request.

For more information on retrying an API request, see Retry failed API requests in the Messaging API documentation.

Don't use the same retry key for more than 24 hours

If you use the same retry key for more than 24 hours, the request will succeed as a new API request even if an API request containing the same retry key has already succeeded. As a result, duplicate messages will be sent.

Example request

# Request headers

X-Line-Retry-Key

Arbitrarily generated UUID in hexadecimal notation (e.g. 123e4567-e89b-12d3-a456-426614174000)

* Required when retrying API requests.

# Response if the request has already been accepted

If a request containing the same retry key has already been accepted, returns the 409 status code, the x-line-accepted-request-id header indicating the request ID of the request already accepted, and a JSON object containing this information.

message

String

A message informing the same request has already been accepted

sentMessages

Array

Not always included

Array of sent messages. The response has this property only when a push message was sent.
Max: 5

sentMessages.id

Number

Not always included

ID of the sent message. The response has this property only when a push message was sent.

sentMessages.quoteToken

String

Not always included

Example response

# Managing Audience

You can create, update, activate, or delete an audience. Specify the audience when sending narrowcast messages.

Endpoints

POST   /v2/bot/audienceGroup/upload

POST   /v2/bot/audienceGroup/upload/byFile

PUT    /v2/bot/audienceGroup/upload

PUT    /v2/bot/audienceGroup/upload/byFile

POST   /v2/bot/audienceGroup/click

POST   /v2/bot/audienceGroup/imp

PUT    /v2/bot/audienceGroup/{audienceGroupId}/updateDescription

DELETE /v2/bot/audienceGroup/{audienceGroupId}

GET    /v2/bot/audienceGroup/{audienceGroupId}

GET    /v2/bot/audienceGroup/list

GET    /v2/bot/audienceGroup/shared/{audienceGroupId}

GET    /v2/bot/audienceGroup/shared/list

Audiences can also be created using LINE Official Account Manager (opens new window). To learn more, see Audience (opens new window) in LINE for Business.

Audience	How to create
An audience used for uploading user IDs	Messaging API LINE Official Account Manager (opens new window) LINE Points Ads (opens new window) (Japanese only)
Message click audience	Messaging API LINE Official Account Manager (opens new window)
Message impression audience	Messaging API LINE Official Account Manager (opens new window)
Chat tag audience	LINE Official Account Manager (opens new window)
Friend path audience	LINE Official Account Manager (opens new window)
Reservation audience	LINE Official Account Manager (opens new window)
Rich menu impression audience	LINE Official Account Manager (opens new window)
Rich menu click audience	LINE Official Account Manager (opens new window)
Web traffic audience	LINE Official Account Manager (opens new window) LINE Ads (opens new window)
App event audience	LINE Ads (opens new window)
Video view audience	LINE Ads (opens new window)
Image click audience	LINE Ads (opens new window)

Note

Only Japanese (JP), Thai (TH), and Taiwanese (TW) users with LINE Official Accounts can create audiences.
You can't create the following types of audiences with the Messaging API:
- Chat tag audience
- Friend path audience
- Reservation audience
- Rich menu impression audience
- Rich menu click audience
- Web traffic audience
- App event audience
- Video view audience
- Image click audience

# Details of the error related to audience management

The details of the error that occurs on the Managing Audience endpoints are included in the details[].message property of the JSON response. The details of the main error are as follows:

Message	Description
`AUDIENCE_GROUP_CAN_NOT_UPLOAD_STATUS_EXPIRED`	This audience can't be used because it's been more than 180 days (15,552,000 seconds) since this audience was created.
`AUDIENCE_GROUP_COUNT_MAX_OVER`	You have already created the maximum number of audiences (1,000).
`AUDIENCE_GROUP_NAME_SIZE_OVER`	The audience's name is too long.
`AUDIENCE_GROUP_NAME_WRONG`	The audience's name contains an invalid character (such as `\n` or some other control character).
`AUDIENCE_GROUP_NAME_EMPTY`	The audience's name is empty or contains only spaces.
`AUDIENCE_GROUP_NOT_FOUND`	Audience not found.
`AUDIENCE_GROUP_REQUESTID_DUPLICATE`	There is already an audience with the specified request ID.
`AUDIENCE_GROUP_UPLOAD_DESCRIPTION_SIZE_OVER`	The audience's description is too long.
`REQUEST_NOT_FOUND`	The specified request ID is incorrect or LINE not ready to create an audience with the specified request ID.
`TOO_OLD_MESSAGES`	You can't create an audience for a message (request ID) that was sent over 60 days (5,184,000 seconds) ago.
`UPLOAD_AUDIENCE_GROUP_INVALID_AUDIENCE_ID_FORMAT`	`file` contains an invalid user ID or IFA. `audiences[].id` is an invalid user ID or IFA. If this message is returned, see Error-handling methods.
`UPLOAD_AUDIENCE_GROUP_NO_VALID_AUDIENCE_IDS`	`file` doesn't contain a valid user ID or IFA. `audiences[].id` isn't a valid user ID or IFA.
`UPLOAD_AUDIENCE_GROUP_TOO_MANY_AUDIENCE_IDS`	Exceeded the maximum number of user IDs or IFAs.
`WRONG_BOT_ID`	The bot ID in the specified request ID doesn't match the bot linked to the channel that issued the channel access token.
`ALREADY_ACTIVE`	The audience group is already active.

# Error-handling methods

If the audiences property contains invalid user IDs

In the case that UPLOAD_AUDIENCE_GROUP_INVALID_AUDIENCE_ID_FORMAT is returned, use the Get profile information endpoint to get profile information of all user IDs specified in JSON. After excluding all user IDs that return anything other than status code 200, execute the failed endpoint once again.

# Create audience for uploading user IDs (by JSON)

POST https://api.line.me/v2/bot/audienceGroup/upload

Creates an audience for uploading user IDs.

For this endpoint, use JSON to specify recipients. You can also use Endpoint that specifies recipients with text file.

For more information on how to get user IDs, see Get user IDs in the Messaging API documentation.

# Conditions for users that can be added to the audience

You can add users who are friends with your LINE Official Account to an audience for uploading user IDs. Even if status code 202 is returned, these users are added to the audience.

Users who deleted their LINE accounts
Users who blocked your LINE Official Account that created the audience
Users who haven't added your LINE Official Account that created the audience as a friend

If you send a message using the created audience, the message won't be sent to the users listed above.

We have set a limit on the number of concurrent endpoint operations

We have set a limit on the number of concurrent endpoint operations per audience ID (audienceGroupId), for creating an audience for uploading user IDs and adding user IDs to an audience. For more information, see Limit on the number of concurrent operations.

You must complete additional application forms to specify recipients using Identifiers for Advertisers (IFAs)

You can use IFAs to specify recipients, but this feature is only available to corporate users who have completed certain applications. To use it with your LINE Official Account, contact your sales representative or contact our Sales partners (opens new window).

Audience used for uploading user IDs

Audience specifications are as follows:

Item	Limit
The number of audiences per channel	Max limit: 1,000
Retention period of an audience	Up to 180 days (15,552,000 seconds)
The number of user IDs or IFAs you can upload to an audience per request	When using JSON: Max limit: 10,000 When using file: Max limit: 1,500,000
The number of users per audience	Audience for uploading user IDs: No limit

For information on narrowcast message restrictions, see Restrictions on sending messages using attributes and audiences.

Verifying a valid user ID

If an invalid user ID is specified in the audiences property of JSON, the error response (details[].message: UPLOAD_AUDIENCE_GROUP_INVALID_AUDIENCE_ID_FORMAT) will be returned, and adding a user ID will fail. Before you execute this endpoint, check whether all the user IDs specified in the audiences property of JSON are valid.

To confirm whether a user ID is valid, use the Get profile information endpoint. If the user ID is valid, HTTP status code 200 will be returned. If a value other than 200 is returned, the user ID is invalid and should not be included in the audiences property.

Status of an audience without a user ID

If the audiences property is omitted or an empty array is specified in the JSON when creating an audience, an empty audience will be created.

The number of users included in the audience (audienceGroup.audienceCount) of an empty audience is 0 and the audience can't accept messages. Therefore, the audienceGroup.status in the response remains IN_PROGRESS and doesn't become READY.

Only users who have agreed to the LY Corporation Privacy Policy (revised March 2022) will be added

When adding user IDs to an audience for uploading user IDs, if the user IDs include those of users who haven't agreed to the privacy policy (revised March 2022) (opens new window), users who haven't agreed will be ignored and only users who have agreed will be added.

Therefore, the number of valid recipients of the audience may be less than that of user IDs specified.

Example request

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Request body

description

String

Required

The audience's name. This is case-insensitive, meaning AUDIENCE and audience are considered identical.
Max character limit: 120

isIfaAudience

Boolean

Optional

To specify recipients by IFAs: set true.
To specify recipients by user IDs: set false or omit isIfaAudience property.

uploadDescription

String

Optional

The description to register for the job (in jobs[].description).
Max character limit: 300

audiences

Array

Optional

An array of user IDs or IFAs.
If omitted, an empty audience will be created.
Max number: 10,000

audiences[].id

String

Optional

A user ID or IFA. You can specify an empty array.
If you specify an empty array, an empty audience will be created.

# Response

Returns a 202 HTTP status code and a JSON object with the following information.

Audience is created asynchronously

Before using an audience, confirm that the audience can be used for delivery.

audienceGroupId

Number

The audience ID.

createRoute

String

How the audience was created.

MESSAGING_API: An audience created with Messaging API.

type

String

The audience type.

UPLOAD: An audience used for uploading user IDs

description

String

The audience's name.

created

Number

When the audience was created in UNIX time (in seconds).

permission

String

Update permissions for the created audience.

READ_WRITE: Can use and update the audience.

expireTimestamp

Number

Audience expiration time in UNIX time (in seconds)

isIfaAudience

Boolean

The value indicating the type of account to be sent, as specified when creating the audience for uploading user IDs. One of:

true: Accounts are specified with IFAs.
false (default): Accounts are specified with user IDs.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code Description

Code	Description
`400`	Problem with the request. Consider these reasons: You have already created the maximum number of audiences (1,000). A name longer than the maximum number of characters (120) is specified in the `description` property. An invalid character (such as `\n` or some other control character) is specified in the `description` property. The `description` property is empty or contains only spaces. A string longer than the maximum number of characters (300) is specified in the `uploadDescription` property. An invalid user ID or IFA is specified in the `audiences[].id` property. More user IDs or IFAs than the maximum number (10,000) are specified in the `audiences` property.
`429`	The limit on the number of concurrent operations has exceeded. For more information, see Limit on the number of concurrent operations.

400

Problem with the request. Consider these reasons:

You have already created the maximum number of audiences (1,000).
A name longer than the maximum number of characters (120) is specified in the description property.
An invalid character (such as \n or some other control character) is specified in the description property.
The description property is empty or contains only spaces.
A string longer than the maximum number of characters (300) is specified in the uploadDescription property.
An invalid user ID or IFA is specified in the audiences[].id property.
More user IDs or IFAs than the maximum number (10,000) are specified in the audiences property.

429 The limit on the number of concurrent operations has exceeded. For more information, see Limit on the number of concurrent operations.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Create audience for uploading user IDs (by file)

POST https://api-data.line.me/v2/bot/audienceGroup/upload/byFile

This domain name is different from that of other endpoints

Creates an audience for uploading user IDs.

For this endpoint, use a text file to specify recipients. You can also use Endpoint that specifies recipients with JSON.

For more information on how to get user IDs, see Get user IDs in the Messaging API documentation.

# Conditions for users that can be added to the audience

You can add users who are friends with your LINE Official Account to an audience for uploading user IDs. Even if status code 202 is returned, these users are added to the audience.

Users who deleted their LINE accounts
Users who blocked your LINE Official Account that created the audience
Users who haven't added your LINE Official Account that created the audience as a friend

If you send a message using the created audience, the message won't be sent to the users listed above.

We have set a limit on the number of concurrent endpoint operations

You must complete additional application forms to specify recipients using Identifiers for Advertisers (IFAs)

Audience used for uploading user IDs

Audience specifications are as follows:

Item	Limit
The number of audiences per channel	Max limit: 1,000
Retention period of an audience	Up to 180 days (15,552,000 seconds)
The number of user IDs or IFAs you can upload to an audience per request	When using JSON: Max limit: 10,000 When using file: Max limit: 1,500,000
The number of users per audience	Audience for uploading user IDs: No limit

For information on narrowcast message restrictions, see Restrictions on sending messages using attributes and audiences.

Only users who have agreed to the LY Corporation Privacy Policy (revised March 2022) will be added

Therefore, the number of valid recipients of the audience may be less than that of user IDs specified.

Example request

Text file example

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

multipart/form-data

# Request body

description

String

Required

The audience's name. This is case-insensitive, meaning AUDIENCE and audience are considered identical.
Max character limit: 120

isIfaAudience

Boolean

Optional

To specify recipients by IFAs: set true.
To specify recipients by user IDs: set false or omit isIfaAudience property.

uploadDescription

String

Optional

The description to register for the job (in jobs[].description).
Max character limit: 300

file

File

Required

A text file with one user ID or IFA entered per line. Specify text/plain as Content-Type.
Max file number: 1
Max number: 1,500,000

# Response

Returns a 202 HTTP status code and a JSON object with the following information.

Audience is created asynchronously

Before using an audience, confirm that the audience can be used for delivery.

audienceGroupId

Number

The audience ID.

createRoute

String

How the audience was created.

MESSAGING_API: An audience created with Messaging API.

type

String

The audience type.

UPLOAD: An audience used for uploading user IDs.

description

String

The audience's name.

created

Number

When the audience was created in UNIX time (in seconds).

permission

String

Update permissions for the created audience.

READ_WRITE: Can use and update the audience.

expireTimestamp

Number

Audience expiration time in UNIX time (in seconds)

isIfaAudience

Boolean

The value indicating the type of account to be sent, as specified when creating the audience for uploading user IDs. One of:

true: Accounts are specified with IFAs.
false (default): Accounts are specified with user IDs.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: The file specified in the `file` property contains an invalid user ID or IFA. A file with more user IDs or IFAs than the maximum number (1,500,000) is specified in the `file` property. The file specified in the `file` property doesn't contain a valid user ID or IFA. You have already created the maximum number of audiences (1,000). A name longer than the maximum number of characters (120) is specified in the `description` property. An invalid character (such as `\n` or some other control character) is specified in the `description` property. The `description` property is empty or contains only spaces. A string longer than the maximum number of characters (300) is specified in the `uploadDescription` property.
`415`	An unsupported media format file is specified in the `file` property.
`429`	The limit on the number of concurrent operations has exceeded. For more information, see Limit on the number of concurrent operations.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Add user IDs or Identifiers for Advertisers (IFAs) to an audience for uploading user IDs (by JSON)

PUT https://api.line.me/v2/bot/audienceGroup/upload

Adds new user IDs or IFAs to an audience for uploading user IDs.

For this endpoint, use JSON to specify recipients. You can also use Endpoint that specifies recipients with text file.

# Conditions for users that can be added to the audience

You can add users who are friends with your LINE Official Account to an audience for uploading user IDs. Even if status code 202 is returned, these users are added to the audience.

Users who deleted their LINE accounts
Users who blocked your LINE Official Account that created the audience
Users who haven't added your LINE Official Account that created the audience as a friend

If you send a message using the created audience, the message won't be sent to the users listed above.

We have set a limit on the number of concurrent endpoint operations

Request timeout values

We strongly recommend using request timeout values of 30 seconds or more.

Verifying a valid user ID

If an invalid user ID is specified in the audiences property of JSON, the error response (details[].message: UPLOAD_AUDIENCE_GROUP_INVALID_AUDIENCE_ID_FORMAT) will be returned, and audience creation will fail. Before you execute this endpoint, check whether all the user IDs specified in the audiences property of JSON are valid.

You can't switch between user IDs and IFAs

Add the same type of data (user IDs or IFAs) to an audience for uploading user IDs as you originally specified when creating that audience. For example, you can't add user IDs to an audience that originally used IFAs when it was created.

You can use an audience's isIfaAudience property to determine which type of recipient (user IDs or IFAs) was specified when the audience was created. For more details, see Get audience data.

You can't delete user IDs or IFAs

You cannot delete a user ID or IFA after adding it.

Only users who have agreed to the LY Corporation Privacy Policy (revised March 2022) will be added

Therefore, the number of valid recipients of the audience may be less than that of user IDs specified.

Example request

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Request body

audienceGroupId

Number

Required

The audience ID

uploadDescription

String

Optional

The description to register with the job (in jobs[].description).
Max character limit: 300

audiences

Array

Required

An array of user IDs or IFAs
Max number: 10,000

audiences[].id

String

Required

A user ID or IFA

# Response

Returns status code 202 and an empty JSON object.

Audience is created asynchronously

Before using an audience, confirm that the audience can be used for delivery.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code Description

Code	Description
`400`	Problem with the request. Consider these reasons: An invalid user ID or IFA is specified in the `audiences[].id` property. More user IDs or IFAs than the maximum number (10,000) are specified in the `audiences` property. A invalid user ID or IFA isn't specified in the `audiences[].id` property. The audience that has exceeded the retention period is specified. A non-existent audience is specified. A string longer than the maximum number of characters (300) is specified in the `uploadDescription` property.
`429`	The limit on the number of concurrent operations has exceeded. For more information, see Limit on the number of concurrent operations.

400

Problem with the request. Consider these reasons:

An invalid user ID or IFA is specified in the audiences[].id property.
More user IDs or IFAs than the maximum number (10,000) are specified in the audiences property.
A invalid user ID or IFA isn't specified in the audiences[].id property.
The audience that has exceeded the retention period is specified.
A non-existent audience is specified.
A string longer than the maximum number of characters (300) is specified in the uploadDescription property.

429 The limit on the number of concurrent operations has exceeded. For more information, see Limit on the number of concurrent operations.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Add user IDs or Identifiers for Advertisers (IFAs) to an audience for uploading user IDs (by file)

PUT https://api-data.line.me/v2/bot/audienceGroup/upload/byFile

This domain name is different from that of other endpoints

Adds new user IDs or IFAs to an audience for uploading user IDs.

For this endpoint, use a text file to specify recipients. You can also use Endpoint that specifies recipients with JSON.

# Conditions for users that can be added to the audience

You can add users who are friends with your LINE Official Account to an audience for uploading user IDs. Even if status code 202 is returned, these users are added to the audience.

Users who deleted their LINE accounts
Users who blocked your LINE Official Account that created the audience
Users who haven't added your LINE Official Account that created the audience as a friend

If you send a message using the created audience, the message won't be sent to the users listed above.

We have set a limit on the number of concurrent endpoint operations

Request timeout values

We strongly recommend using request timeout values of 30 seconds or more.

You can't switch between user IDs and IFAs

You can use an audience's isIfaAudience property to determine which type of recipient (user IDs or IFAs) was specified when the audience was created. For more details, see Get audience data.

You can't delete user IDs or IFAs

You cannot delete a user ID or IFA after adding it.

Only users who have agreed to the LY Corporation Privacy Policy (revised March 2022) will be added

Therefore, the number of valid recipients of the audience may be less than that of user IDs specified.

Example request

Example text

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

multipart/form-data

# Request body

audienceGroupId

Number

Required

The audience ID

uploadDescription

String

Optional

The description to register with the job (in jobs[].description)
Max character limit: 300

file

File

Required

A text file with one user ID or IFA entered per line. Specify text/plain as Content-Type.
Max file number: 1
Max number: 1,500,000

# Response

Returns status code 202 and an empty JSON object.

Audience is created asynchronously

Before using an audience, confirm that the audience can be used for delivery.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: The file specified in the `file` property contains an invalid user ID or IFA. A file with more user IDs or IFAs than the maximum number (1,500,000) is specified in the `file` property. The file specified in the `file` property doesn't contain a valid user ID or IFA. The audience that has exceeded the retention period is specified. A non-existent audience is specified. A string longer than the maximum number of characters (300) is specified in the `uploadDescription` property.
`415`	An unsupported media format file is specified in the `file` property.
`429`	The limit on the number of concurrent operations has exceeded. For more information, see Limit on the number of concurrent operations.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Create message click audience

POST https://api.line.me/v2/bot/audienceGroup/click

Creates a message click audience.

A message click audience is a collection of users who have clicked a URL contained in a broadcast or narrowcast message. The message is sent to any user who has clicked at least one link.

Use a request ID to specify the message.

Message click audience

Audience's specifications are as follows:

Item	Limit
The number of audiences per channel	Max limit: 1,000
Retention period of an audience	Up to 180 days (15,552,000 seconds)
The number of users per audience	Minimum: 50 per message click audience
The period during which the retargeting audience* can be created after the message is sent	Max limit: 60 days (5,184,000 seconds)

* Message click audience and message impression audience.

Example request

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Request body

description

String

Required

The audience's name. This is case-insensitive, meaning AUDIENCE and audience are considered identical.
Max character limit: 120

requestId

String

Required

The request ID of a broadcast or narrowcast message sent in the past 60 days. Each Messaging API request has a request ID. Find it in the response headers.

Note

The request IDs of reply messages, push messages, and multicast messages cannot be used.

clickUrl

String

Optional

The URL clicked by the user. If empty, users who clicked any URL in the message are added to the list of recipients.
Max character limit: 2,000

# Response

Returns a 202 HTTP status code and a JSON object with the following information.

Audience is created asynchronously

Before using an audience, confirm that the audience can be used for delivery.

audienceGroupId

Number

The audience ID.

createRoute

String

How the audience was created.

MESSAGING_API: An audience created with Messaging API

type

String

The audience type.

CLICK: Message click audience

description

String

The audience's name.

created

Number

When the audience was created in UNIX time (in seconds).

permission

String

Update permissions for the created audience.

READ_WRITE: Can use and update the audience.

expireTimestamp

Number

Audience expiration time in UNIX time (in seconds)

isIfaAudience

Boolean

The value indicating the type of account to be sent, as specified when creating the audience for uploading user IDs. One of:

true: Accounts are specified with IFAs.
false (default): Accounts are specified with user IDs.

requestId

String

The request ID that was specified when the audience was created.

clickUrl

String

Not always included

The URL that was specified when the audience was created. Only included if you specify a value with the clickUrl property in your request.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code Description

Code	Description
`400`	Problem with the request. Consider these reasons: You have already created the maximum number of audiences (1,000). A name longer than the maximum number of characters (120) is specified in the `description` property. An invalid character (such as `\n` or some other control character) is specified in the `description` property. The `requestID` and `clickUrl` properties have the same combination of values as the existing audience. The time limit for creating an audience has expired. A non-existent request ID is specified. The LINE Platform isn't ready to create an audience with the specified request ID.

400

Problem with the request. Consider these reasons:

You have already created the maximum number of audiences (1,000).
A name longer than the maximum number of characters (120) is specified in the description property.
An invalid character (such as \n or some other control character) is specified in the description property.
The requestID and clickUrl properties have the same combination of values as the existing audience.
The time limit for creating an audience has expired.
A non-existent request ID is specified.
The LINE Platform isn't ready to create an audience with the specified request ID.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Create message impression audience

POST https://api.line.me/v2/bot/audienceGroup/imp

Creates a message impression audience.

A message impression audience is a collection of users who have viewed a broadcast or narrowcast message. The audience will include any user who has viewed at least one message bubble.

Use a request ID to specify the message.

Message impression audience

Audience's specifications are as follows:

Item	Limit
The number of audiences per channel	Max limit: 1,000
Retention period of an audience	Up to 180 days (15,552,000 seconds)
The number of users per audience	Minimum: 50 per message impression audience
The period during which the retargeting audience* can be created after the message is sent	Max limit: 60 days (5,184,000 seconds)

* Message click audience and message impression audience.

Example request

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Request body

description

String

Required

The audience's name. This is case-insensitive, meaning AUDIENCE and audience are considered identical.
Max character limit: 120

requestId

String

Required

The request ID of a broadcast or narrowcast message sent in the past 60 days. Each Messaging API request has a request ID. Find it in the response headers.

# Response

Returns a 202 HTTP status code and a JSON object with the following information.

Audience is created asynchronously

Before using an audience, confirm that the audience can be used for delivery.

audienceGroupId

Number

The audience ID.

createRoute

String

How the audience was created.

MESSAGING_API: Audiences created with Messaging API.

type

String

The audience type.

IMP: Message impression audience.

description

String

The audience's name.

created

Number

When the audience was created in UNIX time (in seconds).

permission

String

Update permissions for the created audience.

READ_WRITE: Can use and update the audience.

expireTimestamp

Number

Audience expiration time in UNIX time (in seconds)

isIfaAudience

Boolean

The value indicating the type of account to be sent, as specified when creating the audience for uploading user IDs. One of:

true: Accounts are specified with IFAs.
false (default): Accounts are specified with user IDs.

requestId

String

The request ID that was specified when the audience was created.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code Description

400

Problem with the request. Consider these reasons:

You have already created the maximum number of audiences (1,000).
A name longer than the maximum number of characters (120) is specified in the description property.
An invalid character (such as \n or some other control character) is specified in the description property.
There is already an audience with the specified request ID.
The time limit for creating an audience has expired.
A non-existent request ID is specified.
The LINE Platform isn't ready to create an audience with the specified request ID.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Rename an audience

PUT https://api.line.me/v2/bot/audienceGroup/{audienceGroupId}/updateDescription

Renames an existing audience.

Example request

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

# Path parameters

audienceGroupId

Required

The audience ID.

# Request body

description

String

Required

The audience's name. This is case-insensitive, meaning AUDIENCE and audience are considered identical.
Max character limit: 120

# Response

Returns the 200 HTTP status code and an empty JSON object.

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: A name longer than the maximum number of characters (120) is specified in the `description` property. An invalid character (such as `\n` or some other control character) is specified in the `description` property. A non-existent audience is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Delete audience

DELETE https://api.line.me/v2/bot/audienceGroup/{audienceGroupId}

Deletes an audience.

You can't undo deleting an audience

Make sure that an audience is no longer in use before you delete it.

Example request

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

audienceGroupId

Required

The audience ID.

# Response

Returns the 202 HTTP status code and an empty JSON object.

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	A non-existent audience is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get audience data

GET https://api.line.me/v2/bot/audienceGroup/{audienceGroupId}

Gets audience data.

Example request

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

audienceGroupId

Required

The audience ID.

# Response

Returns a 200 HTTP status code and a JSON object with the following information.

audienceGroup

Object

Audience group object.

audienceGroup.audienceGroupId

Number

The audience ID.

audienceGroup.createRoute

String

How the audience was created. One of:

OA_MANAGER: Audience created with LINE Official Account Manager (opens new window)
MESSAGING_API: Audience created with Messaging API
POINT_AD: Audience created with LINE Points Ads (opens new window) (Japanese only)
AD_MANAGER: Audience created with LINE Ads (opens new window)

audienceGroup.type

String

The audience type. One of:

UPLOAD: An audience used for uploading user IDs
CLICK: Message click audience
IMP: Message impression audience
CHAT_TAG: Chat tag audience
FRIEND_PATH: Friend path audience
RESERVATION: Reservation audience
RICHMENU_IMP: Rich menu impression audience
RICHMENU_CLICK: Rich menu click audience
APP_EVENT: App event audience
VIDEO_VIEW: Video view audience
WEBTRAFFIC: Web traffic audience
IMAGE_CLICK: Image click audience

For more information, see the Audience (opens new window) page on LINE for Business. This page isn't currently available in English.

audienceGroup.description

String

The audience's name.

audienceGroup.status

String

The audience's status. One of:

IN_PROGRESS: Pending. It may take several hours for the status to change to READY. If the number of users included in the audience is insufficient (at least 50 are required) for an audience with a user count restriction, the status will remain IN_PROGRESS and won't be updated.
READY: Ready to accept messages.
FAILED: An error occurred while creating the audience.
EXPIRED: Expired. Audiences are automatically deleted a month after they expire.
INACTIVE: The audience is inactive.
ACTIVATING: The audience is activating.

audienceGroup.audienceCount

Number

The number of users included in the audience. To protect the users' privacy, 0 is returned when it is less than 20, unless the audience type is one of the following:

An audience used for uploading user IDs (in case of recipients being specified by their user IDs)
Chat tag audience

Since the audience may include users who have already blocked LINE Official Account, the value of audienceGroup.audienceCount and the number of users to whom messages will be sent will differ.

audienceGroup.created

Number

When the audience was created in UNIX time (in seconds).

audienceGroup.permission

String

Update permissions for the audience. Returns READ_WRITE if the current Messaging API channel can update the target audience, or READ if it can't.

READ: Can use, but can't update the audience.
READ_WRITE: Can use and update the audience.

audienceGroup.isIfaAudience

Boolean

The value indicating the type of account to be sent, as specified when creating the audience for uploading user IDs. One of:

true: Accounts are specified with IFAs.
false (default): Accounts are specified with user IDs.

audienceGroup.requestId

String

Not always included

The request ID that was specified when the audience was created. This is only included when audienceGroup.type is CLICK or IMP.

audienceGroup.clickUrl

String

Not always included

The URL that was specified when the audience was created. This is only included when audienceGroup.type is CLICK and link URL is specified.

audienceGroup.failedType

String

Not always included

The reason why the operation failed. This is only included when audienceGroup.status is FAILED. One of:

AUDIENCE_GROUP_AUDIENCE_INSUFFICIENT: Insufficient number of users included in the audience (at least 50 are needed)
INTERNAL_ERROR: Internal server error

audienceGroup.activated

Number

Not always included

Time the audience was activated. Only returned for audiences created with LINE Ads (opens new window) or LINE Points Ads (opens new window) (Japanese only).

audienceGroup.inactivatedTimestamp

Number

Not always included

Time of audience inactivation. Only returned for audiences created with LINE Ads (opens new window) or LINE Points Ads (opens new window) (Japanese only).

audienceGroup.expireTimestamp

Number

Not always included

Audience expiration time in UNIX time (in seconds). Only returned for specific audiences.

jobs

Array

An array of jobs. This array is used to keep track of each attempt to add new user IDs or IFAs to an audience for uploading user IDs. Empty array is returned for any other type of audience.
Max: 50

jobs[].audienceGroupJobId

Number

A job ID.

jobs[].audienceGroupId

Number

An audience ID.

jobs[].description

String

The job's description. If you don't specify a value with the uploadDescription property when adding a user ID or IFA, null will be returned.

jobs[].type

String

The job's type. One of:

DIFF_ADD: Indicates that a user ID or IFA was added via the Messaging API.

jobs[].status

String

This property is deprecated. See jobs[].jobStatus for the status of jobs.

jobs[].failedType

String

The reason why the operation failed. This is only included when jobs[].jobStatus is FAILED. One of:

AUDIENCE_GROUP_AUDIENCE_INSUFFICIENT: Insufficient number of users included in the audience (at least 50 are needed)
INTERNAL_ERROR: Internal server error

If jobs[].jobStatus isn't FAILED, null is returned.

jobs[].audienceCount

Number

The number of accounts (recipients) that were added or removed.

jobs[].created

Number

When the job was created in UNIX time (in seconds).

jobs[].jobStatus

String

The job's status. One of:

QUEUED: Waiting to run
WORKING: Running
FINISHED: Completed
FAILED: Failed

adaccount

Object

Not always included

Ad account object. Only returned for audiences created with LINE Ads (opens new window) or LINE Points Ads (opens new window) (Japanese only).

adaccount[].name

String

Name of the ad account that created the shared audience.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	A non-existent audience is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get data for multiple audiences

GET https://api.line.me/v2/bot/audienceGroup/list

Gets data for more than one audience.

Example request

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

page

Required

The page to return when getting (paginated) results. Must be 1 or higher.

description

Optional

The name of the audience(s) to return. You can search for partial matches. This is case-insensitive, meaning AUDIENCE and audience are considered identical. If omitted, the name of the audience(s) will not be used as a search criterion.

status

Optional

The status of the audience(s) to return. If omitted, the status of the audience(s) will not be used as a search criterion. One of:

IN_PROGRESS: Pending.
READY: Ready to accept messages.
FAILED: An error occurred while creating the audience.
EXPIRED: Expired. Audiences are automatically deleted a month after they expire.
INACTIVE: The audience is inactive.
ACTIVATING: The audience is activating.

size

Optional

The number of audiences per page. Default: 20
Max: 40

includesExternalPublicGroups

Optional

true (default): Get public audiences created in all channels linked to the same bot.
false: Get audiences created in the same channel.

createRoute

Optional

How the audience was created. If omitted, all audiences are included.

OA_MANAGER: Return only audiences created with LINE Official Account Manager (opens new window).
MESSAGING_API: Return only audiences created with Messaging API.
POINT_AD: Return only audiences created with LINE Points Ads (opens new window) (Japanese only).
AD_MANAGER: Return only audiences created with LINE Ads (opens new window).

If you specify multiple parameters, the OR condition is used.

# Response

Returns a 200 HTTP status code and a JSON object with the following information.

audienceGroups

Array

An array of audience data. If there are no audiences that match the specified filter, an empty array will be returned.

audienceGroups[].audienceGroupId

Number

The audience ID.

audienceGroups[].createRoute

String

How the audience was created. One of:

OA_MANAGER: Audience created with LINE Official Account Manager (opens new window)
MESSAGING_API: Audience created with Messaging API
POINT_AD: Audience created with LINE Points Ads (opens new window) (Japanese only)
AD_MANAGER: Audience created with LINE Ads (opens new window)

audienceGroups[].type

String

The audience type. One of:

UPLOAD: An audience used for uploading user IDs
CLICK: Message click audience
IMP: Message impression audience
CHAT_TAG: Chat tag audience
FRIEND_PATH: Friend path audience
RESERVATION: Reservation audience
RICHMENU_IMP: Rich menu impression audience
RICHMENU_CLICK: Rich menu click audience
APP_EVENT: App event audience
VIDEO_VIEW: Video view audience
WEBTRAFFIC: Web traffic audience
IMAGE_CLICK: Image click audience

For more information, see the Audience (opens new window) page on LINE for Business. This page isn't currently available in English.

audienceGroups[].description

String

The audience's name.

audienceGroups[].status

String

The audience's status. One of:

IN_PROGRESS: Pending. It may take several hours for the status to change to READY. If the number of users included in the audience is insufficient (at least 50 are required) for an audience with a user count restriction, the status will remain IN_PROGRESS and won't be updated.
READY: Ready to accept messages.
FAILED: An error occurred while creating the audience.
EXPIRED: Expired. Audiences are automatically deleted a month after they expire.
INACTIVE: The audience is inactive.
ACTIVATING: The audience is activating.

audienceGroups[].audienceCount

Number

The number of users included in the audience. To protect the users' privacy, 0 is returned when it is less than 20, unless the audience type is one of the following:

An audience used for uploading user IDs (in case of recipients being specified by their user IDs)
Chat tag audience

Since the audience may include users who have already blocked LINE Official Account, the value of audienceGroups[].audienceCount and the number of users to whom messages will be sent will differ.

audienceGroups[].created

Number

When the audience was created in UNIX time (in seconds).

audienceGroups[].permission

String

Update permissions for the audience. Returns READ_WRITE if the current Messaging API channel can update the target audience, or READ if it can't.

READ: Can use, but can't update the audience.
READ_WRITE: Can use and update the audience.

audienceGroups[].isIfaAudience

Boolean

The value indicating the type of account to be sent, as specified when creating the audience for uploading user IDs. One of:

true: Accounts are specified with IFAs.
false (default): Accounts are specified with user IDs.

audienceGroups[].activated

Number

Not always included

Time the audience was activated. Only returned for audiences created with LINE Ads (opens new window) or LINE Points Ads (opens new window) (Japanese only).

audienceGroups[].inactivatedTimestamp

Number

Not always included

Time of audience inactivation. Only returned for audiences created with LINE Ads (opens new window) or LINE Points Ads (opens new window) (Japanese only).

audienceGroups[].expireTimestamp

Number

Not always included

Audience expiration time in UNIX time (in seconds). Only returned for specific audiences.

audienceGroups[].requestId

String

Not always included

The request ID that was specified when the audience was created. This is only included when audienceGroups[].type is CLICK or IMP.

audienceGroups[].clickUrl

String

Not always included

The URL that was specified when the audience was created. This is only included when audienceGroups[].type is CLICK and the link URL is specified.

audienceGroups[].failedType

String

Not always included

The reason why the operation failed. This is only included when audienceGroups[].status is FAILED or EXPIRED. One of:

AUDIENCE_GROUP_AUDIENCE_INSUFFICIENT: Insufficient number of users included in the audience (at least 50 are needed)
INTERNAL_ERROR: Internal server error

hasNextPage

Boolean

true when this is not the last page.

totalCount

Number

The total number of audiences that can be returned with the specified filter.

readWriteAudienceGroupTotalCount

Number

Of the audiences you can get with the specified filter, the number of audiences with the update permission (audienceGroups[].permission) is READ_WRITE.

page

Number

The current page number.

size

Number

The maximum number of audiences on the current page.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid query parameter is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get shared audience data in Business Manager

GET https://api.line.me/v2/bot/audienceGroup/shared/{audienceGroupId}

Gets a shared audience in Business Manager (opens new window) (only available in Japanese).

About Business Manager

Business Manager allows you to share specific audiences across multiple services. By sharing audiences in Business Manager, you can better communicate with your end users.

For more information, see Business Manager (opens new window) (only available in Japanese) in LINE DATA SOLUTION.

Example request

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

audienceGroupId

Required

The audience ID of the audience you want to get information about.

# Response

Returns a 200 HTTP status code and a JSON object with the following information.

audienceGroup

Object

Audience group object.

audienceGroup.audienceGroupId

Number

The audience ID.

audienceGroup.createRoute

String

How the audience was created. One of:

OA_MANAGER: Audience created with LINE Official Account Manager (opens new window)
MESSAGING_API: Audience created with Messaging API
POINT_AD: Audience created with LINE Points Ads (opens new window) (only available in Japanese)
AD_MANAGER: Audience created with LINE Ads (opens new window)
BUSINESS_MANAGER: Audience created with Business Manager (opens new window)
YAHOO_DISPLAY_ADS: Audience created with Yahoo! JAPAN Ads Display Ads (opens new window)

audienceGroup.type

String

The audience type. One of:

UPLOAD: An audience used for uploading user IDs
CLICK: Message click audience
IMP: Message impression audience
CHAT_TAG: Chat tag audience
FRIEND_PATH: Friend path audience
RESERVATION: Reservation audience
RICHMENU_IMP: Rich menu impression audience
RICHMENU_CLICK: Rich menu click audience
APP_EVENT: App event audience
VIDEO_VIEW: Video view audience
WEBTRAFFIC: Web traffic audience
IMAGE_CLICK: Image click audience

For more information, see the Audience (opens new window) page on LINE for Business. This page isn't currently available in English.

audienceGroup.description

String

The audience's name.

audienceGroup.status

String

The audience's status. One of:

IN_PROGRESS: Pending. It may take several hours for the status to change to READY. If the number of users included in the audience is insufficient (at least 50 are required) for an audience with a user count restriction, the status will remain IN_PROGRESS and won't be updated.
READY: Ready to accept messages.
FAILED: An error occurred while creating the audience.
EXPIRED: Expired. Audiences are automatically deleted a month after they expire.
INACTIVE: The audience is inactive.
ACTIVATING: The audience is activating.

audienceGroup.audienceCount

Number

The number of users included in the audience. To protect the users' privacy, 0 is returned when it is less than 20, unless the audience type is one of the following:

An audience used for uploading user IDs (in case of recipients being specified by their user IDs)
Chat tag audience

Since the audience may include users who have already blocked LINE Official Account, the value of audienceGroup.audienceCount and the number of users to whom messages will be sent will differ.

audienceGroup.created

Number

When the audience was created in UNIX time (in seconds).

audienceGroup.permission

String

Update permissions for the audience. Returns READ_WRITE if the current Messaging API channel can update the target audience, or READ if it can't.

READ: Can use, but can't update the audience.
READ_WRITE: Can use and update the audience.

audienceGroup.isIfaAudience

Boolean

The value indicating the type of account to be sent, as specified when creating the audience for uploading user IDs. One of:

true: Accounts are specified with IFAs.
false (default): Accounts are specified with user IDs.

audienceGroups[].webtraffic

Object

Not always included

Web traffic object. This is only included when audienceGroups[].type is WEBTRAFFIC.

audienceGroup.requestId

String

Not always included

The request ID that was specified when the audience was created. This is only included when audienceGroup.type is CLICK or IMP.

audienceGroup.clickUrl

String

Not always included

The URL that was specified when the audience was created. This is only included when audienceGroup.type is CLICK and link URL is specified.

audienceGroup.failedType

String

Not always included

The reason why the operation failed. This is only included when audienceGroup.status is FAILED. One of:

AUDIENCE_GROUP_AUDIENCE_INSUFFICIENT: Insufficient number of users included in the audience (at least 50 are needed)
INTERNAL_ERROR: Internal server error

audienceGroup.activated

Number

Not always included

Time the audience was activated. Only returned for audiences created with LINE Ads (opens new window) or LINE Points Ads (opens new window) (Japanese only).

audienceGroup.inactivatedTimestamp

Number

Not always included

Time of audience inactivation. Only returned for audiences created with LINE Ads (opens new window) or LINE Points Ads (opens new window) (Japanese only).

audienceGroup.expireTimestamp

Number

Not always included

Audience expiration in UNIX time (in seconds). Only returned for specific audiences.

jobs

Array

An array of jobs. This array is used to keep track of each attempt to add new user IDs or IFAs to an audience for uploading user IDs. Empty array is returned for any other type of audience.
Max: 50

jobs[].audienceGroupJobId

Number

A job ID.

jobs[].audienceGroupId

Number

An audience ID.

jobs[].description

String

The job's description. If you don't specify a value with the uploadDescription property when adding a user ID or IFA, null will be returned.

jobs[].type

String

The job's type. One of:

DIFF_ADD: Indicates that a user ID or IFA was added via the Messaging API.

jobs[].status

String

This property is deprecated. See jobs[].jobStatus for the status of jobs.

jobs[].failedType

String

The reason why the operation failed. This is only included when jobs[].jobStatus is FAILED. One of:

AUDIENCE_GROUP_AUDIENCE_INSUFFICIENT: Insufficient number of users included in the audience (at least 50 are needed)
INTERNAL_ERROR: Internal server error

If jobs[].jobStatus isn't FAILED, null is returned.

jobs[].audienceCount

Number

The number of accounts (recipients) that were added or removed.

jobs[].created

Number

When the job was created in UNIX time (in seconds).

jobs[].jobStatus

String

The job's status. One of:

QUEUED: Waiting to run
WORKING: Running
FINISHED: Completed
FAILED: Failed

owner.serviceType

String

Name of the service that created the audience. One of:

bm: Business Manager
lap: LINE Ads
account: LINE Official Account
yda: Yahoo! JAPAN Ads

owner.id

String

ID of the account that created the audience.

owner.name

String

Name of the account that created the audience.

Example response

# Web traffic object

Web traffic object represent webtraffic audience data.

webtrafficIsMyTag

Boolean

Returns true if the LINE Tag is created by the LINE Official Account linked to your Messaging API channel.

webtrafficBmTagSharingStatus

String

The value that indicates whether the LINE Tag is shared on Business Manager.

SHARED: Shared on Business Manager
UNSHARED: Not shared on Business Manager

webtrafficIsTagDeleted

Boolean

Returns true if the LINE Tag used in this webtraffic audience has already been deleted.

webtrafficTagCreateRoute

String

Routes that created the webtraffic audience. One of the following values:

OA_MANAGER: Audience created with LINE Official Account Manager (opens new window)
AD_MANAGER: Audience created with LINE Ads (opens new window)
BUSINESS_MANAGER: Audience created with Business Manager (opens new window)

webtrafficVisitType

String

Matching method of LINE Tag. One of:

VISIT_ALL: All visiting users
URL_MATCHING: URL condition
EVENT_MATCHING: Event specification

webtrafficRetentionDays

String

Retention period for the web traffic audience.

webtrafficTagEventType

String

Not always included

Type of event code. Only included if webtrafficVisitType is EVENT_MATCHING. One of:

CONVERSION_EVENT: Conversion codes
CUSTOM_EVENT: Custom event codes

webtrafficCustomEventName

String

Not always included

Custom event name. Only included if webtrafficVisitType is EVENT_MATCHING and webtrafficTagEventType is CUSTOM_EVENT.

webtrafficMatchingType

String

Not always included

Event matching method of LINE Tag. Only included if webtrafficVisitType is EVENT_MATCHING or URL_MATCHING. Value is always NORMAL.

webtrafficConditionGroup

Array

Array of matching conditions.

webtrafficConditionGroup[].conditionType

String

Matching condition for keywords in the keywords array. One of:

CONTAIN: Contains keywords
NOT_CONTAIN: Does not contain keywords
EQUAL_TO: Matches keywords

webtrafficConditionGroup[].keywords[]

Array of strings

Array of keywords used for matching criteria.

webtrafficTagId

String

Tag ID for LINE Tag.

webtrafficTagOwnerName

String

Name of the account that issued the LINE Tag.

Example

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	A non-existent audience is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get a list of shared audiences in Business Manager

GET https://api.line.me/v2/bot/audienceGroup/shared/list

Gets a list of shared audiences in Business Manager (opens new window) (only available in Japanese).

You can get more detailed information about each audience by using the Get shared audience data in Business Manager endpoint.

About Business Manager

Business Manager allows you to share specific audiences across multiple services. By sharing audiences in Business Manager, you can better communicate with your end users.

For more information, see Business Manager (opens new window) (only available in Japanese) in LINE DATA SOLUTION.

Example request

# Rate limit

60 requests per minute

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

page

Optional

The page to return when getting (paginated) results. Must be 1 or higher. If omitted, page 1 is retrieved.

If you want to retrieve all audiences, repeat the request while incrementing the page parameter until the audienceGroups array in the response is less than the page size (size).

description

Optional

status

Optional

The status of the audience(s) to return. If omitted, the status of the audience(s) will not be used as a search criterion. One of:

IN_PROGRESS: Pending.
READY: Ready to accept messages.
FAILED: An error occurred while creating the audience.
EXPIRED: Expired. Audiences are automatically deleted a month after they expire.

size

Optional

The number of audiences per page. Default: 20
Max: 40

createRoute

Optional

How the audience was created. If omitted, all audiences are included.

OA_MANAGER: Return only audiences created with LINE Official Account Manager (opens new window).
MESSAGING_API: Return only audiences created with Messaging API.
POINT_AD: Return only audiences created with LINE Points Ads (opens new window) (only available in Japanese).
AD_MANAGER: Return only audiences created with LINE Ads (opens new window).
BUSINESS_MANAGER: Return only audiences created with Business Manager (opens new window).
YAHOO_DISPLAY_ADS: Return only audiences created with Yahoo! JAPAN Ads Display Ads (opens new window).

If you specify multiple parameters, the OR condition is used.

includesOwnedAudienceGroups

Optional

The setting that indicates whether to include the audiences created by your LINE Official Account in addition to the shared audiences in Business Manager. The default value is false.

true: Get the audiences, including those created by your LINE Official Account
false: Get only the shared audiences in Business Manager

# Response

Returns a 200 HTTP status code and a JSON object with the following information.

audienceGroups

Array

An array of audience data. If there are no audiences that match the specified filter, an empty array will be returned.

audienceGroups[].audienceGroupId

Number

The audience ID.

audienceGroups[].createRoute

String

How the audience was created. One of:

OA_MANAGER: Audience created with LINE Official Account Manager (opens new window)
MESSAGING_API: Audience created with Messaging API
POINT_AD: Audience created with LINE Points Ads (opens new window) (only available in Japanese)
AD_MANAGER: Audience created with LINE Ads (opens new window)
BUSINESS_MANAGER: Audience created with Business Manager (opens new window)
YAHOO_DISPLAY_ADS: Audience created with Yahoo! JAPAN Ads Display Ads (opens new window)

audienceGroups[].type

String

The audience type. One of:

UPLOAD: An audience used for uploading user IDs
CLICK: Message click audience
IMP: Message impression audience
CHAT_TAG: Chat tag audience
FRIEND_PATH: Friend path audience
RESERVATION: Reservation audience
RICHMENU_IMP: Rich menu impression audience
RICHMENU_CLICK: Rich menu click audience
APP_EVENT: App event audience
VIDEO_VIEW: Video view audience
WEBTRAFFIC: Web traffic audience
IMAGE_CLICK: Image click audience

For more information, see the Audience (opens new window) (only available in Japanese) in LINE for Business.

audienceGroups[].description

String

The audience's name.

audienceGroups[].status

String

The audience's status. One of:

IN_PROGRESS: Pending. It may take several hours for the status to change to READY. If the number of users included in the audience is insufficient (at least 50 are required) for an audience with a user count restriction, the status will remain IN_PROGRESS and won't be updated.
READY: Ready to accept messages.
FAILED: An error occurred while creating the audience.
EXPIRED: Expired. Audiences are automatically deleted a month after they expire.
INACTIVE: The audience is inactive.
ACTIVATING: The audience is activating.

audienceGroups[].audienceCount

Number

The number of users included in the audience. To protect the users' privacy, 0 is returned when it is less than 20, unless the audience type is one of the following:

An audience used for uploading user IDs (in case of recipients being specified by their user IDs)
Chat tag audience

Since the audience may include users who have already blocked LINE Official Account, the value of audienceGroups[].audienceCount and the number of users to whom messages will be sent will differ.

audienceGroups[].created

Number

When the audience was created in UNIX time (in seconds).

audienceGroups[].permission

String

Update permissions for the audience. Returns READ_WRITE if the current Messaging API channel can update the target audience, or READ if it can't.

READ: Can use, but can't update the audience.
READ_WRITE: Can use and update the audience.

audienceGroups[].isIfaAudience

Boolean

The value indicating the type of account to be sent, as specified when creating the audience for uploading user IDs. One of:

true: Accounts are specified with IFAs.
false (default): Accounts are specified with user IDs.

audienceGroups[].activated

Number

Not always included

Time the audience was activated. Only returned for audiences created with LINE Ads (opens new window) or LINE Points Ads (opens new window) (only available in Japanese).

audienceGroups[].inactivatedTimestamp

Number

Not always included

Time of audience inactivation. Only returned for audiences created with LINE Ads (opens new window) or LINE Points Ads (opens new window) (only available in Japanese).

audienceGroups[].expireTimestamp

Number

Not always included

Audience expiration in UNIX time (in seconds). Only returned for specific audiences.

audienceGroups[].webtraffic

Object

Not always included

Web traffic object. This is only included when audienceGroups[].type is WEBTRAFFIC.

audienceGroups[].requestId

String

Not always included

The request ID that was specified when the audience was created. This is only included when audienceGroups[].type is CLICK or IMP.

audienceGroups[].clickUrl

String

Not always included

The URL that was specified when the audience was created. This is only included when audienceGroups[].type is CLICK and the link URL is specified.

audienceGroups[].failedType

String

Not always included

The reason why the operation failed. This is only included when audienceGroups[].status is FAILED or EXPIRED. One of:

AUDIENCE_GROUP_AUDIENCE_INSUFFICIENT: Insufficient number of users included in the audience (at least 50 are needed)
INTERNAL_ERROR: Internal server error

hasNextPage

Boolean

true when this is not the last page.

totalCount

Number

The total number of audiences that can be returned with the specified filter.

readWriteAudienceGroupTotalCount

Number

Of the audiences you can get with the specified filter, the number of audiences with the update permission (audienceGroups[].permission) is READ_WRITE.

page

Number

The current page number.

size

Number

The maximum number of audiences on the current page.

Example response

# Web traffic object

Web traffic object represent webtraffic audience data.

webtrafficIsMyTag

Boolean

Returns true if the LINE Tag is created by the LINE Official Account linked to your Messaging API channel.

webtrafficBmTagSharingStatus

String

The value that indicates whether the LINE Tag is shared on Business Manager.

SHARED: Shared on Business Manager
UNSHARED: Not shared on Business Manager

webtrafficIsTagDeleted

Boolean

Returns true if the LINE Tag used in this webtraffic audience has already been deleted.

webtrafficTagCreateRoute

String

Routes that created the webtraffic audience. One of the following values:

OA_MANAGER: Audience created with LINE Official Account Manager (opens new window)
AD_MANAGER: Audience created with LINE Ads (opens new window)
BUSINESS_MANAGER: Audience created with Business Manager (opens new window)

Example

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid query parameter is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Insights

You can obtain information on the number of messages sent from the LINE Official Account, number of friends, and other statistical data.

Endpoints

GET /v2/bot/insight/message/delivery?date={date}

GET /v2/bot/insight/followers?date={date}

GET /v2/bot/insight/demographic

GET /v2/bot/insight/message/event?requestId={requestId}

GET /v2/bot/insight/message/event/aggregation?customAggregationUnit={customAggregationUnit}&from={from}&to={to}

GET /v2/bot/message/aggregation/info

GET /v2/bot/message/aggregation/list

# Get number of message deliveries

GET https://api.line.me/v2/bot/insight/message/delivery?date={date}

Returns the number of messages sent from LINE Official Account on the date specified in date.

Example request

# Rate limit

60 requests per hour

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

date

Required

Date for which to retrieve number of sent messages.

Format: yyyyMMdd (e.g. 20191231)
Timezone: UTC+9

# Response

Returns status code 200 and a JSON object with these properties:

status

String

Status of the counting process. One of:

ready: Calculation has finished; the numbers are up-to-date.
unready: We haven't finished calculating the number of sent messages for the specified date. Try again later. Calculation usually takes about a day.
out_of_service: The specified date is earlier than the date on which we first started calculating sent messages (March 1, 2017).

The properties after the broadcast property are only included if the state property is ready.

broadcast

Number

Not always included

Number of messages sent by selecting All Friends as recipients in the LINE Official Account Manager.

targeting

Number

Not always included

Number of messages sent by selecting Targeting as recipients in the LINE Official Account Manager.

stepMessage

Number

Not always included

Number of messages sent with step messages in the LINE Official Account Manager.

For more information, see Step messages (opens new window) (only available in Japanese) in LINE for Business.

autoResponse

Number

Not always included

Number of auto-response messages automatically sent when a message is received from a user.

For more information, see Auto-response messages (opens new window) (only available in Japanese) in LINE for Business.

welcomeResponse

Number

Not always included

Number of greeting messages automatically sent when a user adds the LINE Official Account as a friend.

For more information, see Set greeting messages (opens new window) (only available in Japanese) in LINE for Business.

chat

Number

Not always included

Number of messages sent from LINE Official Account Manager Chat screen (opens new window) (only available in Japanese).

apiBroadcast

Number

Not always included

Number of messages sent with the Send broadcast message endpoint.

apiPush

Number

Not always included

Number of messages sent with the Send push message endpoint.

apiMulticast

Number

Not always included

Number of messages sent with the Send multicast message endpoint.

apiNarrowcast

Number

Not always included

Number of messages sent with the Send narrowcast message endpoint.

apiReply

Number

Not always included

Number of messages sent with the Send reply message endpoint.

ccAutoReply

Number

Not always included

Number of messages sent by auto reply with LINE Chat Plus.

ccManualReply

Number

Not always included

Number of messages sent by manual chat support with LINE Chat Plus.

pnpNoticeMessage

Number

Not always included

Number of messages sent with LINE notification messages on the options for corporate customers.

pnpCallToLine

Number

Not always included

Number of messages sent with Call to LINE. *

* New registration for Call to LINE has been discontinued.

thirdPartyChatTool

Number

Not always included

Number of messages sent from third party chat tools.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid date is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get number of followers

GET https://api.line.me/v2/bot/insight/followers?date={date}

Returns the number of users who have added the LINE Official Account on or before a specified date.

Example request

# Rate limit

60 requests per hour

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

date

Required

Date for which to retrieve the number of followers.

Format: yyyyMMdd (e.g. 20191231)
Timezone: UTC+9

# Response

Returns status code 200 and a JSON object with these properties:

status

String

Calculation status. One of:

ready: Calculation has finished. The numbers are up-to-date.
unready: We haven't finished calculating followers for the specified date. Try again later. Calculation usually takes about a day.
out_of_service: The specified date is earlier than the date on which we first started calculating followers (November 1, 2016).

followers

Number

The number of times, as of the specified date, that a user added this LINE Official Account as a friend for the first time. The number doesn't decrease even if a user later blocks the account or when they delete their LINE account.

This value is null if the status property isn't ready.

targetedReaches

Number

The number of users, as of the specified date, that the LINE Official Account can reach through targeted messages based on gender, age, and/or region. This number only includes users who are active on LINE or LINE services and whose demographics have a high level of certainty.

This value is null if the status property isn't ready.

blocks

Number

The number of users blocking the account as of the specified date. The number decreases when a user unblocks the account.

This value is null if the status property isn't ready.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	No date or an invalid date is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get friend demographics

GET https://api.line.me/v2/bot/insight/demographic

Retrieves the friend demographic information of the friends of the LINE Official Account. To retrieve the friend demographic information, all of the following conditions must be met:

The target reach is 20 or more people.
The LINE Official Account was created by a user in Japan (JP), Thailand (TH) or Taiwan (TW).

Not real-time data

It takes approximately 3 days for the friend demographic information to be reflected. Therefore, the information that can be obtained will be approximately 3 days old. Note that the timing may vary.

About friend demographic information

Friend demographic information is classified as "deemed attributes" based on the gender, age, area information, and action history registered by LINE users in the LINE Family service. Mobile carriers and operating systems aren't included in the deemed attributes.

Deemed Attributes are classified based on trends such as stickers purchased and used on LINE, content of interest, and the types of LINE Official Accounts that users are friends with. Sensitive information such as phone numbers, email addresses, address books, and chat content isn't included in the information used as the basis for classification.

The estimation of friend demographic information is statistical and doesn't identify specific individuals. Information that could identify specific individuals isn't shared with third parties (e.g., advertisers).

Example request

# Rate limit

60 requests per hour

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Response

Returns status code 200 and a JSON object with these properties:

available

Boolean

true: Friend demographic information is available.
false: Friend demographic information isn't available. Consider these reasons:
- The target reach is less than 20 people.
- The LINE Official Account wasn't created by a user in Japan (JP), Thailand (TH) or Taiwan (TW).

The elements of each array in the response (genders, ages, areas, appTypes, subscriptionPeriods) are only included in the response if the value of available is true.

genders

Array

Percentage per gender. If the friend demographic information isn't available, an empty array is returned.

genders[].gender

String

Returns these values based on the users' gender:

male
female
unknown

genders[].percentage

Number

Percentage

ages

Array

Percentage per age group. If the friend demographic information isn't available, an empty array is returned.

ages[].age

String

Returns these values based on the users' age:

When you are using a Thai LINE Official Account

When you retrieve the demographic information of a Thai LINE Official Account, the percentages with ages[].age values of from0to14 and from15to19 won't be included in the response. Users under the age of 20 will be counted as unknown.

from0to14
from15to19
from20to24
from25to29
from30to34
from35to39
from40to44
from45to49
from50
- As of September 5, 2024, you can now get the percentage of friends between the ages of 50 and 70.
from50to54
from55to59
from60to64
from65to69
from70
unknown

ages[].percentage

Number

Percentage

areas

Array

Percentage per area. If the friend demographic information isn't available, an empty array is returned.

areas[].area

String

Returns these values based on the users' country and region:
JP

北海道 (Hokkaido)
青森 (Aomori)
岩手 (Iwate)
宮城 (Miyagi)
秋田 (Akita)
山形 (Yamagata)
福島 (Fukushima)
茨城 (Ibaraki)
栃木 (Tochigi)
群馬 (Gunma)
埼玉 (Saitama)
千葉 (Chiba)
東京 (Tokyo)
神奈川 (Kanagawa)
新潟 (Niigata)
富山 (Toyama)
石川 (Ishikawa)
福井 (Fukui)
山梨 (Yamanashi)
長野 (Nagano)
岐阜 (Gifu)
静岡 (Shizuoka)
愛知 (Aichi)
三重 (Mie)
滋賀 (Shiga)
京都 (Kyoto)
大阪 (Osaka)
兵庫 (Hyogo)
奈良 (Nara)
和歌山 (Wakayama)
鳥取 (Tottori)
島根 (Shimane)
岡山 (Okayama)
広島 (Hiroshima)
山口 (Yamaguchi)
徳島 (Tokushima)
香川 (Kagawa)
愛媛 (Ehime)
高知 (Kochi)
福岡 (Fukuoka)
佐賀 (Saga)
長崎 (Nagasaki)
熊本 (Kumamoto)
大分 (Oita)
宮崎 (Miyazaki)
鹿児島 (Kagoshima)
沖縄 (Okinawa)
unknown

台北市 (Taipei City)
新北市 (New Taipei City)
桃園市 (Taoyuan City)
台中市 (Taichung)
台南市 (Tainan City)
高雄市 (Kaohsiung)
基隆市 (Keelung)
新竹市 (Hsinchu City)
嘉義市 (Chiayi City)
新竹縣 (Hisnchu County)
苗栗縣 (Miaoli County)
彰化縣 (Changhua County)
南投縣 (Nantou County)
雲林縣 (Yunlin County)
嘉義縣 (Chiayi County)
屏東縣 (Pingtung County)
宜蘭縣 (Yilan County)
花蓮縣 (Hualien County)
台東縣 (Taitung County)
澎湖縣 (Penghu County)
金門縣 (Kinmen County)
連江縣 (Lianjiang County)
unknown

Bangkok
Pattaya
Northern
Central
Southern
Eastern
NorthEastern
Western
unknown

areas[].percentage

Number

Percentage

appTypes

Array

Percentage by OS. If the friend demographic information isn't available, an empty array is returned.

appTypes[].appType

String

Returns these values based on the users' OS:

ios
android
others

appTypes[].percentage

Number

Percentage

subscriptionPeriods

Array

Percentage per friendship duration. If the friend demographic information isn't available, an empty array is returned.

subscriptionPeriods[].subscriptionPeriod

String

Returns these values for friendship duration. "Friendship duration" is defined as the time period counted from the day after a user adds a LINE Official Account as a friend.

within7days: Less than 7 days
within30days: Equal to or greater than 7 days but less than 30 days
within90days: Equal to or greater than 30 days but less than 90 days
within180days: Equal to or greater than 90 days but less than 180 days
within365days: Equal to or greater than 180 days but less than 365 days
over365days: Equal to or greater than 365 days
unknown: Unknown

subscriptionPeriods[].percentage

Number

Percentage of users corresponding to the respective subscriptionPeriod values.

Example response

# Error response

For more information, see Status codes and Error responses in the Common specifications section.

# Get user interaction statistics

GET https://api.line.me/v2/bot/insight/message/event?requestId={requestId}

Returns statistics about how users interact with narrowcast messages or broadcast messages sent from your LINE Official Account.

You can get statistics per message or per bubble.

message and bubbles

On the recorded statistics recorded

Interactions are updated for only 14 days (1,209,600 seconds) from the time a message was sent. After that time, interactions aren't updated.

For example, if you send a message at 15:00 on February 1, 2021, interactions will be updated until 15:00 on February 15, 2021.

Example request

# Rate limit

60 requests per hour

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

requestId

Required

Request ID of a narrowcast message or broadcast message. Each Messaging API request has a request ID. Find it in the response headers.

# Response

Returns status code 200 and a JSON object with these properties:

Note

The statistical data may contain some errors.

To protect users' privacy, the values of some properties related to user interactions will be displayed as null in the following cases:

The property value is less than 20
Even if the property value is higher than or equal to 20, the actual number of users who generated the event is less than 20 (for example, if messages[].mediaPlayed is 30, but messages[].uniqueMediaPlayed is 15, both will be displayed as null

overview

Object

Summary of message statistics.

overview.requestId

String

Request ID.

overview.timestamp

Number

Message delivery time in UNIX time (in seconds).

overview.delivered

Number

Number of messages delivered. This property shows values of less than 20. However, if all messages have not been sent, it will be null.

overview.uniqueImpression

Number

Number of users who opened the message, meaning they displayed at least 1 bubble.

overview.uniqueClick

Number

Number of users who opened any URL in the message.

overview.uniqueMediaPlayed

Number

Number of users who started playing any video or audio in the message.

overview.uniqueMediaPlayed100Percent

Number

Number of users who played the entirety of any video or audio in the message.

messages

Array

Array of information about individual message bubbles. If the statistic isn't available, an empty array is returned.

messages[].seq

Number

Bubble's serial number.

messages[].impression

Number

Number of times the bubble was displayed.

messages[].mediaPlayed

Number

Number of times audio or video in the bubble started playing. This count also includes the number of times a video is automatically played.

messages[].mediaPlayed25Percent

Number

Number of times audio or video in the bubble started playing and was played 25% of the total time.

messages[].mediaPlayed50Percent

Number

Number of times audio or video in the bubble started playing and was played 50% of the total time.

messages[].mediaPlayed75Percent

Number

Number of times audio or video in the bubble started playing and was played 75% of the total time.

messages[].mediaPlayed100Percent

Number

Number of times audio or video in the bubble started playing and was played 100% of the total time.

messages[].uniqueMediaPlayed

Number

Number of users that started playing audio or video in the bubble.

messages[].uniqueMediaPlayed25Percent

Number

Number of users that started playing audio or video in the bubble and played 25% of the total time.

messages[].uniqueMediaPlayed50Percent

Number

Number of users that started playing audio or video in the bubble and played 50% of the total time.

messages[].uniqueMediaPlayed75Percent

Number

Number of users that started playing audio or video in the bubble and played 75% of the total time.

messages[].uniqueMediaPlayed100Percent

Number

Number of users that started playing audio or video in the bubble and played 100% of the total time.

clicks

Array

Array of information about opened URLs in the message. If the message doesn't contain any URLs or the statistic isn't available, an empty array is returned.

clicks[].seq

Number

The URL's serial number.

clicks[].url

String

URL.

clicks[].click

Number

Number of times the URL was opened.

clicks[].uniqueClick

Number

Number of users that opened the URL.

clicks[].uniqueClickOfRequest

Number

Number of users who opened this url through any link in the message. If a message contains two links to the same URL and a user opens both links, they're counted only once.

Example response

# Error response

For more information, see Status codes and Error responses in the Common specifications section.

# Get statistics per unit

GET https://api.line.me/v2/bot/insight/message/event/aggregation?customAggregationUnit={customAggregationUnit}&from={from}&to={to}

You can check the per-unit statistics of how users interact with push messages and multicast messages sent from your LINE Official Account.

You can get statistics on a per-message and per-message bubble basis for each unit.

message and bubbles

If you send messages with the same unit name, the statistics are aggregated together, regardless of message contents or the number and order of message bubbles.

On recorded statistics

Interactions are updated for only 14 days (1,209,600 seconds) from the time a message was sent. After that time, interactions aren't updated.

For example, if you send a message at 15:00 on February 1, 2021, interactions will be updated until 15:00 on February 15, 2021.

To get statistics per message

Use this endpoint to get statistics per narrowcast message or broadcast message.

Get user interaction statistics

Example request

# Rate limit

60 requests per hour

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

customAggregationUnit

String

Required

Name of aggregation unit specified when sending the message. Case-sensitive. For example, Promotion_a and Promotion_A are regarded as different unit names.

For more information about assigning a unit name, see Assign a unit name in the Messaging API documentation.

from

String

Required

Start date of aggregation period.

Format: yyyyMMdd (e.g. 20210301)
Time zone: UTC+9

String

Required

End date of aggregation period. The end date can be specified for up to 30 days later. For example, if the start date is 20210301, the latest end date is 20210331.

Format: yyyyMMdd (e.g. 20210301)
Time zone: UTC+9

# Response

Returns a 200 HTTP status code and a JSON object with this information.

Note

The statistical data may contain some errors.

To protect users' privacy, the values of some properties related to user interactions will be displayed as null in these cases:

The property value is less than 20
Even if the property value is higher than or equal to 20, the actual number of users who generated the event is less than 20 (for example, if messages[].mediaPlayed is 30, but messages[].uniqueMediaPlayed is 15, both will be displayed as null

overview

Object

Statistics related to messages.

overview.uniqueImpression

Number

Number of users who opened the message, meaning they displayed at least 1 bubble.

overview.uniqueClick

Number

Number of users who opened any URL in the message.

overview.uniqueMediaPlayed

Number

Number of users who started playing any video or audio in the message.

overview.uniqueMediaPlayed100Percent

Number

Number of users who played the entirety of any video or audio in the message.

messages

Array

Array of information about individual message bubbles. If the statistic isn't available, an empty array is returned.

messages[].seq

Number

Bubble's serial number.

messages[].impression

Number

Number of times the bubble was displayed.

messages[].uniqueImpression

Number

Number of users that displayed the bubble.

messages[].mediaPlayed

Number

Number of times audio or video in the bubble started playing. This count also includes the number of times a video is automatically played.

messages[].mediaPlayed25Percent

Number

Number of times audio or video in the bubble started playing and was played 25% of the total time.

messages[].mediaPlayed50Percent

Number

Number of times audio or video in the bubble started playing and was played 50% of the total time.

messages[].mediaPlayed75Percent

Number

Number of times audio or video in the bubble started playing and was played 75% of the total time.

messages[].mediaPlayed100Percent

Number

Number of times audio or video in the bubble started playing and was played 100% of the total time.

messages[].uniqueMediaPlayed

Number

Number of users that started playing audio or video in the bubble.

messages[].uniqueMediaPlayed25Percent

Number

Number of users that started playing audio or video in the bubble and played 25% of the total time.

messages[].uniqueMediaPlayed50Percent

Number

Number of users that started playing audio or video in the bubble and played 50% of the total time.

messages[].uniqueMediaPlayed75Percent

Number

Number of users that started playing audio or video in the bubble and played 75% of the total time.

messages[].uniqueMediaPlayed100Percent

Number

Number of users that started playing audio or video in the bubble and played 100% of the total time.

clicks

Array

Array of information about opened URLs in the message. If the message doesn't contain any URLs or the statistic isn't available, an empty array is returned.

clicks[].seq

Number

The URL's serial number.

clicks[].url

String

URL.

clicks[].click

Number

Number of times the URL in the bubble was opened.

clicks[].uniqueClick

Number

Number of users that opened the URL in the bubble.

clicks[].uniqueClickOfRequest

Number

Number of users who opened this url through any link in the message. If another message bubble contains the same URL and a user opens both links, it's counted only once.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Unable to get the statistic. Consider these reasons: No unit name specified. No aggregation period date specified. Invalid aggregation period date specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get the number of unit name types assigned during this month

GET https://api.line.me/v2/bot/message/aggregation/info

You can get the number of unit name types assigned to messages during this month. For more information about the limit on unit names assigned when sending messages, see Maximum number of unit name types in the Messaging API documentation.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Response

Returns a 200 HTTP status code and a JSON object with this information.

numOfCustomAggregationUnits

Number

Number of unit name types assigned to messages during this month.

Example response

# Error Response

For more information, see Status codes and Error responses in the Common specifications section.

# Get a list of unit names assigned during this month

GET https://api.line.me/v2/bot/message/aggregation/list

You can get a unique list of unit names assigned to messages during this month.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

limit

String

Optional

The maximum number of unit names you can get per request. The default value is 100.
Max value: 100

start

String

Optional

Value of the continuation token found in the next property of the JSON object returned in the response. If you can't get all the unit names in a single request, include this parameter to get the remaining array.

# Response

Returns a 200 HTTP status code and a JSON object with this information.

customAggregationUnits

Array of strings

An array of strings indicating the unit names. The array uniquely contains the unit names assigned to messages during this month.

String

Not always included

A continuation token to get the next array of unit names. Returned only when there are remaining unit names that weren't returned in the customAggregationUnits property in the original request.

The continuation token expires in 24 hours (86,400 seconds).

Example response

# Error Response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: An invalid continuation token is specified. An invalid value is specified for the `limit` property.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Users

You can get information of users who have added your LINE Official Account as a friend.

Accessing your own user ID

You can access your user ID under the Basic settings tab of your channel on the LINE Developers Console. For more information on permissions per role in the LINE Developers Console, see Channel roles in Managing roles. There is no API available for retrieving your own user ID.

Endpoints

GET /v2/bot/profile/{userId}

GET /v2/bot/followers/ids

# Get profile

GET https://api.line.me/v2/bot/profile/{userId}

You can get the profile information of users who meet one of two conditions:

Users who have added your LINE Official Account as a friend
Users who haven't added your LINE Official Account as a friend but have sent a message to your LINE Official Account (except users who have blocked your LINE Official Account)

You can only get the main profile information. You can't get the user's subprofile.

Note

You can't get the profile information of a user who has blocked your LINE Official Account.

Profile information of group chat members and multi-person chat members

Use these endpoints to get profile information of group chat members or multi-person chat members.

Get group chat member profile
Get multi-person chat member profile

Example request

# API Playground

Try

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

userId

Required

User ID that is returned in a webhook event object. Do not use the LINE ID found on LINE.

# Response

When the specified user ID is valid, status code 200 and a JSON object with the following information will be returned.

displayName

String

User's display name

userId

String

User ID

language

String

Not always included

User's language, as a BCP 47 (opens new window) language tag. Not included in the response if the user hasn't yet consented to the LY Corporation Privacy Policy.
e.g. en for English.

pictureUrl

String

Not always included

Profile image URL. "https" image URL. Not included in the response if the user doesn't have a profile image.

statusMessage

String

Not always included

User's status message. Not included in the response if the user doesn't have a status message.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code Description

400 An invalid user ID is specified.

404

Unable to get profile information. Consider these reasons:

Target user ID doesn't exist.
The user hasn't consented to their profile information being obtained.
The user hasn't added the target LINE Official Account as a friend.
The user blocked the target LINE Official Account after adding it as a friend.

For more information, see Consent on getting user profile information in the Messaging API documentation.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get a list of users who added your LINE Official Account as a friend

GET https://api.line.me/v2/bot/followers/ids

Note

This feature is available only for verified or premium accounts. For more information about account types, see the Account Types of LINE Official Account (opens new window) page on LINE for Business.

Gets the list of User IDs of users who have added your LINE Official Account as a friend.

To get all the user IDs, you need to repeat the request until the next property is no longer included in the response. Repeat the request by specifying the next property included in the response as start of the next request.

# Restrictions on user IDs that can be obtained

These users' IDs won't be included in the obtained list of user IDs:

Users who deleted their LINE accounts.
Users who blocked your LINE Official Account after adding it as a friend.
Users who haven't consented to their profile information being obtained. For more information, see Consent on getting user profile information in the Messaging API documentation.

Therefore, the actual number of user IDs obtained with this endpoint may not be consistent with the number of friends displayed on your LINE Official Account profile or LINE Official Account Manager (opens new window).

You may not be able to use the user IDs obtained

Even if you send messages to the user IDs obtained with this endpoint, delivery may fail depending on user action. These are the main reasons for failure:

User blocked the target LINE Official Account between the time the user ID was obtained and the time you attempted to send a message.
User deleted LINE account (opens new window) after adding the target LINE Official Account as a friend.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

limit

Number

Optional

The maximum number of user IDs to retrieve in a single request. The default value is 300.
Max value: 1000

start

String

Optional

Value of the continuation token found in the next property of the JSON object returned in the response. Include this parameter to get the next array of user IDs. If you can't get all the user IDs in a single request, specify this parameter to get the remaining user IDs.

# Response

Returns status code 200 and a JSON object with the following properties.

userIds

Array of strings

An array of strings indicating user IDs of users that have added the LINE Official Account as a friend. Due to the restrictions on user IDs that can be obtained, the number of user IDs in the userIds property may not reach the maximum number specified by limit, even if the next property is returned.
Max: The number specified by limit

String

Not always included

A continuation token to get the next user IDs. Returned only when there are remaining user IDs that weren't returned in the userIds property in the previous request.

The continuation token expires in 24 hours (86,400 seconds).

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid continuation token is specified.
`403`	Not authorized to use this endpoint. Only available for verified accounts or premium accounts.

For more information, see Status codes and Error responses in Common specifications section.

Error response example

# Membership

You can get information about the memberships of your LINE Official Accounts. For more information, see Use membership features in the Messaging API documentation.

Endpoints

GET /v2/bot/membership/subscription/{userId}

GET /v2/bot/membership/{membershipId}/users/ids

GET /v2/bot/membership/list

# Get a user's membership subscription status

GET https://api.line.me/v2/bot/membership/subscription/{userId}

You can get information about the memberships that users have subscribed to.

Example request

# Rate limit

200 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

userId

Required

User ID of the user whose membership subscription status you want to view.

For more information on how to get user IDs, see Get user IDs in the Messaging API documentation.

# Response

If the user is subscribed to membership, status code 200 and a JSON object with the following information will be returned.

subscriptions

Array

An array of memberships.

membership

Object

Object containing information about the membership plan.

membership.membershipId

Number

Membership plan ID.

membership.title

String

Membership plan name.

membership.description

String

Membership plan description.

membership.benefits

Array of strings

List of membership plan perks.
Max number of perks: 5

membership.price

Number

Monthly fee for membership plan. (e.g. 1500.00)

membership.currency

String

The currency of membership.price. One of:

JPY: Japanese Yen
TWD: Taiwan Dollar
THB: Thai Baht

user

Object

Object containing user membership subscription information.

user.membershipNo

Number

The user's member number in the membership plan.

user.joinedTime

Number

UNIX time at which the user subscribed to the membership (in seconds).

user.nextBillingDate

String

Next payment date for membership plan.

Format: yyyy-MM-dd (e.g. 2024-02-08)
Timezone: UTC+9

user.totalSubscriptionMonths

Number

The period of time in months that the user has been subscribed to a membership plan. If a user previously canceled and then re-subscribed to the same membership plan, only the period after the re-subscription will be counted.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid user ID is specified.
`404`	Unable to get information about the membership to which the user subscribes. Consider these reasons: User doesn't subscribe to membership Target user ID doesn't exist

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get a list of users who have joined the membership

GET https://api.line.me/v2/bot/membership/{membershipId}/users/ids

You can obtain a list of user IDs for users who have joined a membership of your LINE Official Account.

# Restrictions on user IDs that can be obtained

Even if a user joins a membership, if any of the following conditions are met, that user's user ID won't be included in the list:

The user has deleted their LINE account.
The user has blocked your LINE Official Account.
The user hasn't added your LINE Official Account as a friend.
The user hasn't consented to allow access to their profile information. For more information, see Consent on getting user profile information in the Messaging API documentation.

Example request

# Rate limit

200 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

membershipId

Required

Membership ID.

# Query parameters

limit

Number

Optional

The maximum number of user IDs to obtain in a single request. The default value is 300.
Max value: 1000

start

Optional

The value of the continuation token. This is included in the next property of the JSON object returned in the response. If you can't obtain all of the user IDs in a single request, you can specify this parameter to obtain the remaining array.

# Response

Returns status code 200 and a JSON object with the following properties.

userIds

Array of strings

An array of the user IDs of users who have joined the membership. The number of user IDs contained in the userIds property may not always be the same as the number specified by the limit query parameter, even when the next property is returned, because the user IDs that can be obtained depend on the users' status. For more information, see Restrictions on user IDs that can be obtained.
Max: The number specified by the limit query parameter

String

Not always included

Continuation token. Used to obtain the list of the next user IDs. This property is only returned if there are user IDs that couldn't be obtained from the previous response's userIds property.

The continuation token expires in 24 hours (86,400 seconds).

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: An invalid continuation token is specified. An invalid value is specified for the `limit` query parameter.
`404`	A membership ID that doesn't exist is specified for the `membershipId` path parameter.

For more information, see Status codes and Error responses in Common specifications section.

Example error response

# Get membership plans being offered

GET https://api.line.me/v2/bot/membership/list

You can get membership plans that are currently being offered through your LINE Official Account membership.

Plans under review or plans that have been terminated aren't included in the response.

Example request

# Rate limit

200 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Response

Returns status code 200 and a JSON object with the following properties.

memberships

Array

An array of membership plans being offered.
Max number of plans: 5

memberships[].membershipId

Number

Membership plan ID.

memberships[].title

String

Membership plan name.

memberships[].description

String

Membership plan description.

memberships[].benefits

Array of strings

List of membership plan perks.
Max number of perks: 5

memberships[].price

Number

Monthly fee for membership plan. (e.g. 1500.00)

memberships[].currency

String

The currency of memberships[].price. One of:

JPY: Japanese Yen
TWD: Taiwan Dollar
THB: Thai Baht

memberships[].memberCount

Number

Number of members subscribed to the membership plan.

memberships[].memberLimit

Number

The upper limit of members who can subscribe. If no upper limit is set, it will be null.

memberships[].isInAppPurchase

Boolean

Payment method for users who subscribe to a membership plan.

true: In-app purchases
false: Browser payments

memberships[].isPublished

Boolean

Membership plan status.

true: Public
false: Private (the plan has been discontinued and is no longer public, but still offers perks)

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`404`	No membership plans offered.

For more information, see Status codes and Error responses in Common specifications section.

Error response example

# Bot

You can obtain basic information on the LINE Official Account's bots.

Endpoints

GET /v2/bot/info

# Get bot info

GET https://api.line.me/v2/bot/info

Gets a bot's basic information.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Response

Returns status code 200 and a JSON object with the following information.

userId

String

Bot's user ID

basicId

String

Bot's basic ID

premiumId

String

Not always included

Bot's premium ID. Not included in the response if the premium ID isn't set.

displayName

String

Bot's display name

pictureUrl

String

Not always included

Profile image URL. "https" image URL. Not included in the response if the bot doesn't have a profile image.

chatMode

String

Chat settings set in the LINE Official Account Manager (opens new window). One of:

chat: Chat is set to "On".
bot: Chat is set to "Off".

markAsReadMode

String

Automatic read setting for messages. If the chat is set to "Off", auto is returned. If the chat is set to "On", manual is returned.

auto: Auto read setting is enabled.
manual: Auto read setting is disabled.

Example response

# Error response

For more information, see Status codes and Error responses in the Common specifications section.

# Group chats

You can obtain information about the group chats and their members that the LINE Official Account is a member of.

Endpoints

GET  /v2/bot/group/{groupId}/summary

GET  /v2/bot/group/{groupId}/members/count

GET  /v2/bot/group/{groupId}/members/ids

GET  /v2/bot/group/{groupId}/member/{userId}

POST /v2/bot/group/{groupId}/leave

# Get group chat summary

GET https://api.line.me/v2/bot/group/{groupId}/summary

Gets the group ID, group name, and group icon URL of a group chat where the LINE Official Account is a member.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

groupId

Required

Group ID. Found in the source object of webhook event objects.

# Response

Returns status code 200 and a JSON object with these properties.

groupId

String

Group ID

groupName

String

Group name

pictureUrl

String

Not always included

Group icon URL. Not included in the response if the user doesn't set a group profile icon.

Example response

# Error Response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid group ID is specified.
`404`	A non-existent group or a group that your LINE Official Account doesn't participate in is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get number of users in a group chat

GET https://api.line.me/v2/bot/group/{groupId}/members/count

Gets the count of users in a group chat. You can get the user in group count even if the user hasn't added the LINE Official Account as a friend or has blocked the LINE Official Account.

The number returned excludes the LINE Official Account.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

groupId

Required

Group ID. Found in the source object of webhook event objects.

# Response

Returns status code 200 and a JSON object with these properties.

count

Number

The count of members in the group chat. The number returned excludes the LINE Official Account.

Example response

# Error Response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid group ID is specified.
`404`	A non-existent group or a group that your LINE Official Account doesn't participate in is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get group chat member user IDs

GET https://api.line.me/v2/bot/group/{groupId}/members/ids

Note

This feature is available only for verified or premium accounts. For more information about account types, see the Account Types of LINE Official Account (opens new window) page on LINE for Business.

Gets the user IDs of the members of a group chat that the LINE Official Account is in. This includes user IDs of users who have not added the LINE Official Account as a friend or has blocked the LINE Official Account.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

groupId

Required

Group ID. Found in the source object of webhook event objects.

# Query parameters

start

Optional

Value of the continuation token found in the next property of the JSON object returned in the response. Include this parameter to get the next array of user IDs for the members of the group.

# Response

Returns status code 200 and a JSON object with the following properties.

memberIds

Array of strings

List of user IDs of members in the group chat. Only users of LINE for iOS and LINE for Android are included in memberIds. For more information, see Consent on getting user profile information.
Max: 100 user IDs

String

Not always included

A continuation token to get the next array of user IDs of the members in the group chat. Returned only when there are remaining user IDs that were not returned in memberIds in the original request.

The continuation token expires in 24 hours (86,400 seconds).

Example response

# Error Response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: An invalid group ID is specified. An invalid continuation token is specified for the `start` property.
`403`	Not authorized to use this endpoint. Only available for verified accounts or premium accounts.
`404`	A non-existent group or a group that your LINE Official Account doesn't participate in is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get group chat member profile

GET https://api.line.me/v2/bot/group/{groupId}/member/{userId}

Gets the profile information of a member of a group chat that the LINE Official Account is in if the user ID of the group member is known.

Tip

You can get the profile information of users in the same group chat, regardless of whether they have added your LINE Official Account as a friend, or blocked your LINE Official Account.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

groupId

Required

Group ID. Found in the source object of webhook event objects.

userId

Required

User ID. Found in the source object of webhook event objects. Do not use the LINE ID used in LINE.

# Response

Returns status code 200 and a JSON object with the following information.

displayName

String

Display name

userId

String

User ID

pictureUrl

String

Not always included

Profile image URL. Not included in the response if the user doesn't have a profile image.

Example response

# Error Response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: An invalid group ID is specified. An invalid user ID is specified.
`404`	Unable to get profile information. Consider these reasons: A non-existent group or a group that your LINE Official Account doesn't participate in is specified. A non-existent user or a user who hasn't joined a group is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Leave group chat

POST https://api.line.me/v2/bot/group/{groupId}/leave

Leaves a group chat.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

groupId

Required

Group ID. Found in the source object of webhook event objects.

# Response

Returns status code 200 and an empty JSON object.

Example response

# Error Response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid group ID is specified.
`404`	A non-existent group or a group that your LINE Official Account doesn't participate in is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Multi-person chats

You can obtain information about the multi-person chats and their members that the LINE Official Account is a member of.

Endpoints

GET  /v2/bot/room/{roomId}/members/count

GET  /v2/bot/room/{roomId}/members/ids

GET  /v2/bot/room/{roomId}/member/{userId}

POST /v2/bot/room/{roomId}/leave

# Get number of users in a multi-person chat

GET https://api.line.me/v2/bot/room/{roomId}/members/count

Gets the count of users in a multi-person chat. You can get the user in multi-person chat count even if the user hasn't added the LINE Official Account as a friend or has blocked the LINE Official Account.

The number returned excludes the LINE Official Account.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

roomId

Required

Room ID. Found in the source object of webhook event objects.

# Response

Returns status code 200 and a JSON object with these properties.

count

Number

The count of members in the multi-person chat. The number returned excludes the LINE Official Account.

Example response

# Error Response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid room ID is specified.
`404`	A non-existent multi-person chat or a multi-person chat that your LINE Official Account doesn't participate in is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Get multi-person chat member user IDs

GET https://api.line.me/v2/bot/room/{roomId}/members/ids

Note

This feature is available only for verified or premium accounts. For more information about account types, see the Account Types of LINE Official Account (opens new window) page on LINE for Business.

Gets the user IDs of the members of a multi-person chat that the LINE Official Account is in. This includes the user IDs of users who have not added the LINE Official Account as a friend or have blocked the LINE Official Account.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

roomId

Required

Room ID. Found in the source object of webhook event objects.

# Query parameters

start

Optional

Value of the continuation token found in the next property of the JSON object returned in the response. Include this parameter to get the next array of user IDs for the members of the group.

# Response

Returns status code 200 and a JSON object with the following properties.

memberIds

Array of strings

List of user IDs of the members in the multi-person chat. Only users of LINE for iOS and LINE for Android are included in memberIds. For more information, see Consent on getting user profile information.
Max: 100 user IDs

String

Not always included

A continuation token to get the next array of user IDs of the members in the multi-person chat. Returned only when there are remaining user IDs that were not returned in memberIds in the original request.

The continuation token expires in 24 hours (86,400 seconds).

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: An invalid room ID is specified. An invalid continuation token is specified for the `start` property.
`403`	Not authorized to use this endpoint. Only available for verified accounts or premium accounts.
`404`	A non-existent multi-person chat or a multi-person chat that your LINE Official Account doesn't participate in is specified.

For more information, see Status codes and Error responses in Common specifications section.

Error response example

# Get multi-person chat member profile

GET https://api.line.me/v2/bot/room/{roomId}/member/{userId}

Gets the profile information of a member of a multi-person chat that the LINE Official Account is in if the user ID of the multi-person chat member is known.

Tip

You can get the profile information of users in the same multi-person chat, regardless of whether they have added your LINE Official Account as a friend, or blocked your LINE Official Account.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

roomId

Required

Room ID. Found in the source object of webhook event objects.

userId

Required

User ID. Found in the source object of webhook event objects. Do not use the LINE ID used in LINE.

# Response

Returns status code 200 and a JSON object with the following information.

displayName

String

Display name

userId

String

User ID

pictureUrl

String

Not always included

Profile image URL. Not included in the response if the user doesn't have a profile image.

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Problem with the request. Consider these reasons: An invalid room ID is specified. An invalid user ID is specified.
`404`	Unable to get profile information. Consider these reasons: A non-existent multi-person chat or a multi-person chat that your LINE Official Account doesn't participate in is specified. A non-existent user or a user who hasn't joined a multi-person chat is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Error response example

# Leave multi-person chat

POST https://api.line.me/v2/bot/room/{roomId}/leave

Leaves a multi-person chat.

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

roomId

Required

Room ID. Found in the source object of webhook event objects.

# Response

Returns status code 200 and an empty JSON object.

If you specify a multi-person chat that your LINE Official Account doesn't participate in, the status code 200 will also be returned.

Example response

# Error Response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid room ID is specified.
`404`	A non-existent multi-person chat is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

Customizable menu that is displayed on your LINE Official Account's chat screen. For more information, see Use rich menus.

Endpoints

POST   /v2/bot/richmenu

POST   /v2/bot/richmenu/validate

POST   /v2/bot/richmenu/{richMenuId}/content

GET    /v2/bot/richmenu/{richMenuId}/content

GET    /v2/bot/richmenu/list

GET    /v2/bot/richmenu/{richMenuId}

DELETE /v2/bot/richmenu/{richMenuId}

POST   /v2/bot/user/all/richmenu/{richMenuId}

GET    /v2/bot/user/all/richmenu

DELETE /v2/bot/user/all/richmenu

POST https://api.line.me/v2/bot/richmenu

Creates a rich menu.

You must upload a rich menu image, and set the rich menu as the default rich menu or link the rich menu to a user for the rich menu to be displayed. You can create up to 1000 rich menus for one LINE Official Account with the Messaging API.

Before creating a rich menu

There is also an endpoint for validating rich menu object.

Example request

100 requests per hour

Creating and deleting rich menus using the LINE Official Account Manager isn't subject to this restriction.

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

Specify a rich menu object to be displayed as a rich menu.

Returns status code 200 and a JSON object with the following information.

richMenuId

String

ID of a rich menu. Used when uploading a rich menu image.

Example response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't create a rich menu. Consider these reasons: An invalid rich menu object is specified. The maximum number of rich menus that can be created has been reached (up to 1000).

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

POST https://api.line.me/v2/bot/richmenu/validate

Validate a rich menu object.

You can verify that a rich menu object is valid as a request body for creating rich menu.

Request example

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

Specify a rich menu object you want to validate.

If the request body is valid as a rich menu object, returns the 200 HTTP status code and an empty JSON object.

Response example

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid rich menu object is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

POST https://api-data.line.me/v2/bot/richmenu/{richMenuId}/content

This domain name is different from that of other endpoints

Uploads and sets an image to a rich menu.

You can use rich menu images with the following specifications:

Image format: JPEG or PNG
Image width: 800 to 2500 pixels
Image height: 250 pixels or more
Image aspect ratio (width / height): 1.45 or more
Max file size: 1 MB

Note

You can't replace an image set to a rich menu. To update your rich menu image, create a new rich menu object and upload another image.

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

Content-Type

Required

image/jpeg or image/png

richMenuId

Required

The ID of the rich menu to set the image to

Returns status code 200 and an empty JSON object.

Example response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't set the image to the rich menu. Consider these reasons: The image doesn't meet the requirements. An image is already set to the rich menu.
`404`	A non-existent rich menu is specified.
`415`	An unsupported media format is specified in `Content-Type` (other than `image/jpeg` and `image/png`).

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

GET https://api-data.line.me/v2/bot/richmenu/{richMenuId}/content

This domain name is different from that of other endpoints

Downloads an image associated with a rich menu.

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

richMenuId

Required

ID of the rich menu with the image to be downloaded

Returns status code 200 and the binary data of the rich menu image. The image can be downloaded as shown in the example request.

Returns the following HTTP status code and an error response:

Code	Description
`404`	Couldn't download the image. Consider these reasons: A non-existent rich menu is specified. There is no image set to the rich menu.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

GET https://api.line.me/v2/bot/richmenu/list

Gets a list of the rich menu response object of all rich menus created by Create a rich menu.

Note

You can't retrieve rich menus created with LINE Official Account Manager.

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

Returns status code 200 and a JSON object with the following information.

richmenus

Array

Array of rich menu response objects

Example response

For more information, see Status codes and Error responses in the Common specifications section.

GET https://api.line.me/v2/bot/richmenu/{richMenuId}

Gets a rich menu via a rich menu ID.

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

richMenuId

Required

ID of a rich menu

Returns status code 200 and a rich menu response object.

Example response

Returns the following HTTP status code and an error response:

Code	Description
`404`	A non-existent rich menu is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

DELETE https://api.line.me/v2/bot/richmenu/{richMenuId}

Deletes a rich menu.

Rich menu limits

If you have reached the maximum of 1,000 rich menus with the Messaging API for your LINE Official Account, you must delete a rich menu before you can create a new one.

Example request

100 requests per hour

Creating and deleting rich menus using the LINE Official Account Manager isn't subject to this restriction.

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

richMenuId

Required

ID of a rich menu

Returns status code 200 and an empty JSON object.

Example response

Returns the following HTTP status code and an error response:

Code	Description
`404`	A non-existent rich menu is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

POST https://api.line.me/v2/bot/user/all/richmenu/{richMenuId}

Sets the default rich menu. The default rich menu is displayed to all users who open the chat screen of the LINE Official Account. If a default rich menu has already been set, calling this endpoint replaces the current default rich menu with the one specified in your request.

The rich menu is displayed in the following order of priority (highest to lowest):

The per-user rich menu set with the Messaging API
The default rich menu set with the Messaging API
The default rich menu set with LINE Official Account Manager

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

richMenuId

Required

ID of a rich menu

Returns status code 200 and an empty JSON object.

Example response

Returns the following HTTP status code and an error response:

Code	Description
`400`	There is no image set to the rich menu.
`404`	A non-existent rich menu is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

GET https://api.line.me/v2/bot/user/all/richmenu

Gets the ID of the default rich menu set with the Messaging API.

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

Returns status code 200 and a JSON object with the following information.

richMenuId

String

ID of a rich menu

Example response

Returns the following HTTP status code and an error response:

Code	Description
`403`	The default rich menu is set by another channel, such as LINE Official Account Manager.
`404`	The default rich menu isn't set.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

DELETE https://api.line.me/v2/bot/user/all/richmenu

Clears the default rich menu set with the Messaging API.

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

Returns status code 200 and an empty JSON object.

Example response

For more information, see Status codes and Error responses in the Common specifications section.

You can set the rich menu on a per-user basis by specifying the user ID and the rich menu ID. For more information, see Use per-user rich menus in the Messaging API documentation.

Endpoints

POST   /v2/bot/user/{userId}/richmenu/{richMenuId}

POST   /v2/bot/richmenu/bulk/link

GET    /v2/bot/user/{userId}/richmenu

DELETE /v2/bot/user/{userId}/richmenu

POST   /v2/bot/richmenu/bulk/unlink

POST   /v2/bot/richmenu/batch

GET    /v2/bot/richmenu/progress/batch

POST   /v2/bot/richmenu/validate/batch

POST https://api.line.me/v2/bot/user/{userId}/richmenu/{richMenuId}

Links a rich menu to a user. Only one rich menu can be linked to a user at one time. If a user already has a rich menu linked, calling this endpoint replaces the existing rich menu with the one specified in your request.

The rich menu is displayed in the following order of priority (highest to lowest):

The per-user rich menu set with the Messaging API
The default rich menu set with the Messaging API
The default rich menu set with LINE Official Account Manager

You can link a rich menu to users who have added your LINE Official Account as a friend.

If you try to link a rich menu to the following users, status code 200 will be returned, but the rich menu won't be linked to the user:

Users who deleted their LINE accounts
Users who blocked your LINE Official Account
Users who haven't added your LINE Official Account as a friend
User IDs that don't exist in the channel such as those that were taken from another channel under a different provider

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

richMenuId

Required

ID of a rich menu

userId

Required

User ID. Found in the source object of webhook event objects. Do not use the LINE ID used in LINE.

Returns status code 200 and an empty JSON object.

Example response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't link the rich menu. Consider these reasons: An invalid user ID is specified. There is no image set to the rich menu.
`404`	A non-existent rich menu is specified.

For more information, see Status codes and Error responses in the Common specifications section.

The rich menu isn't unlinked if an error is returned.

Example error response

POST https://api.line.me/v2/bot/richmenu/bulk/link

Links a rich menu to multiple users.

The rich menu is displayed in the following order of priority (highest to lowest):

The per-user rich menu set with the Messaging API
The default rich menu set with the Messaging API
The default rich menu set with LINE Official Account Manager

Unlike linking a rich menu to a user, this request is processed asynchronously in the background. Normally, the process is completed within a few seconds.

Even if the status code 202 is returned, the rich menu may not be linked. To verify whether the request was processed successfully, get the rich menu ID linked to the users and check if the rich menu is actually linked to the users.

The rich menu isn't linked to any user if an error response is returned.

You can link a rich menu to users who have added your LINE Official Account as a friend. If status code 202 is returned, the rich menu is linked to the users specified in the request.

Even if status code 202 is returned, the following users may not be linked to the rich menu because they aren't friends with your LINE Official Account:

Users who deleted their LINE accounts
Users who blocked your LINE Official Account
Users who haven't added your LINE Official Account as a friend
User IDs that don't exist in the channel such as those that were taken from another channel under a different provider

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

richMenuId

String

Required

ID of a rich menu

userIds

Array of strings

Required

Array of user IDs. Found in the source object of webhook event objects. Do not use the LINE ID used in LINE.
Max: 500 user IDs

Returns status code 202 and an empty JSON object.

Example response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't link the rich menu. Consider these reasons: An invalid user ID is specified. An invalid rich menu ID is specified. There is no image set to the rich menu.
`404`	A non-existent rich menu is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

GET https://api.line.me/v2/bot/user/{userId}/richmenu

Gets the ID of the rich menu linked to a user.

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

userId

Required

User ID. Found in the source object of webhook event objects. Do not use the LINE ID used in LINE.

Returns status code 200 and a JSON object with the following information.

richMenuId

String

ID of a rich menu

Example response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid user ID is specified.
`404`	Could't get a rich menu ID. Consider these reasons: The user isn't linked to a rich menu. A non-existent user is specified. The user hasn't added the target LINE Official Account as a friend.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

DELETE https://api.line.me/v2/bot/user/{userId}/richmenu

API that removes the per-user rich menu linked to a specified user.

You can unlink a rich menu from users who have added your LINE Official Account as a friend.

If you try to unlink a rich menu from the following users, status code 200 will be returned, but the rich menu won't be unlinked from the user:

Users who deleted their LINE accounts
Users who blocked your LINE Official Account
Users who haven't added your LINE Official Account as a friend
User IDs that don't exist in the channel such as those that were taken from another channel under a different provider

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

userId

Required

User ID. Found in the source object of webhook event objects. Do not use the LINE ID used in LINE.

Returns status code 200 and an empty JSON object.

Example response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid user ID is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

POST https://api.line.me/v2/bot/richmenu/bulk/unlink

Unlinks rich menus from multiple users.

Unlike unlinking a rich menu from a user, this request is processed asynchronously in the background. Normally, the process is completed within a few seconds.

Even if status code 202 is returned, the rich menu may not be unlinked. To verify whether the request was processed successfully, get the rich menu ID linked to the users and check if the unlinked rich menus are actually not linked to the users.

The rich menu isn't unlinked from any user if an error response is returned.

You can unlink a rich menu from users who have added your LINE Official Account as a friend. If status code 202 is returned, the rich menu is unlinked from the users specified in the request.

Even if status code 202 is returned, the following users may not be unlinked from the rich menu because they aren't friends with your LINE Official Account:

Users who deleted their LINE accounts
Users who blocked your LINE Official Account
Users who haven't added your LINE Official Account as a friend
User IDs that don't exist in the channel such as those that were taken from another channel under a different provider

Example request

2,000 requests per second

For more information on rate limits, see Rate limits.

Content-Type

Required

application/json

Authorization

Required

Bearer {channel access token}

userIds

Array of strings

Required

Array of user IDs. Found in the source object of webhook event objects. Do not use the LINE ID used in LINE.
Max: 500 user IDs

Returns status code 202 and an empty JSON object.

Example response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid user ID is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Replace or unlink the linked rich menus in batches

POST https://api.line.me/v2/bot/richmenu/batch

You can use this endpoint to batch control the rich menu linked to the users using the endpoint such as Link rich menu to user. The following operations are available:

Replace a rich menu with another rich menu for all users linked to a specific rich menu.
Unlink a rich menu for all users linked to a specific rich menu.
Unlink a rich menu for all users linked the rich menu.

You can also specify multiple rich menu batch operations in the operations property of the request body. If you specify multiple rich menu batch operations, each batch operation is processed independently and in parallel for each user. The batch operations you specify don't affect each other.

For example, if you specify the following array for the operations property, the rich menu for users who were linked to rich menu A before the request will be replaced with B, and the rich menu for users who were linked to rich menu B before the request will be replaced with C. The rich menu for users who were linked to rich menu A before the request won't be replaced with C because batch operations don't affect each other.

[
  {
    "type": "link",
    "from": "{ID of rich menu A}",
    "to": "{ID of rich menu B}"
  },
  {
    "type": "link",
    "from": "{ID of rich menu B}",
    "to": "{ID of rich menu C}"
  }
]

Batch operation of the rich menu is processed asynchronously in the background. You can check the status of the process by using the Get the status of rich menu batch control endpoint.

# How to avoid unintended operations when retrying

By using the resumeRequestKey property, you can safely retry.

If you retry without using the resumeRequestKey property in the following cases, the rich menu may be replaced with an unintended one.

If you're not sure whether your request was accepted due to a timeout or an internal server error of the LINE Platform
If you get rich menu batch operation progress status and the phase property of response is failed

Even under these conditions, if you specify an arbitrary key in the resumeRequestKey property on your first request, sending the request again with the same key will only resume processing for users who haven't completed processing.

The resumeRequestKey property expires in 14 days (336 hours). If it has expired, the request will be treated as a new request.

Example of a request to replace a rich menu and unlink a rich menu

Example of a request to unlink a linked rich menu from all users

# Rate limit

3 requests per hour

For more information on rate limits, see Rate limits.

You can verify the request body in advance

There is also the Validate a request of rich menu batch control endpoint for validating the request body in advance.

By using the validation endpoint, you can verify in advance that your request will not result in an error without being subject to this endpoint's rate limit.

# Request headers

Authorization

Required

Bearer {channel access token}

# Request body

operations

Array of Rich menu operation object

Required

Specifies batch operations for rich menus.
Max: 1,000 objects

resumeRequestKey

String

Optional

Key for retry. Key value is a string matching the regular expression pattern [0-9a-zA-Z\-_]{1,100}.

# Rich menu operation object

Rich menu operation object represents the batch operation to the rich menu linked to the user.

type

String

Required

Operation to the rich menu linked to the user. One of:

link: Replace the rich menu with the rich menu specified in the to property for all users linked to the rich menu specified in the from property.
unlink: Unlink the rich menu for all users linked to the rich menu specified in the from property.
unlinkAll: Unlink the rich menu from all users linked to the rich menu.

If you specify unlinkAll, type other than unlinkAll can't be included in the operations property.

from

String

Required if type is link or unlink

ID of a rich menu.

Specify the ID of the rich menu before replacement or the ID of the rich menu to unlink.

If you specify multiple operations in the operations property, you can't specify the ID of the same rich menu in multiple from properties.

String

Required if type is link

ID of a rich menu.

Specify the ID of the rich menu to be replaced.

# Response

Returns the 200 HTTP status code and an empty JSON object.

Batch operation of the rich menu is processed asynchronously in the background. You can check the status of the process by using the Get the status of rich menu batch control endpoint.

Response example

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't control the rich menu. Consider these reasons: An invalid rich menu ID is specified. The rich menu you want to replace has no image. More than 1000 operations are specified in the `operations` property. `unlinkAll` and other types are specified to the `type` property at the same time. The ID of the same rich menu is specified in multiple `from` properties.
`404`	A non-existent rich menu is specified.

For more information, see Status codes and Error responses in the Common specifications section.

The rich menu isn't linked to any user if an error response is returned.

Error response example

# Get the status of rich menu batch control

GET https://api.line.me/v2/bot/richmenu/progress/batch

Get the status of Replace or unlink a linked rich menus in batches.

You can't get the status anymore after 14 days (336 hours) past the timestamp displayed in acceptedTime.

Example request

# Rate limit

100 requests per hour

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Query parameters

requestId

Required

A request ID used to batch control the rich menu linked to the user. Each Messaging API request has a request ID. Find it in the response headers.

# Response

Returns a 200 HTTP status code and a JSON object with the following information.

phase

String

The current status. One of:

ongoing: Rich menu batch control is in progress.
succeeded: Rich menu batch control is complete.
failed: Rich menu batch control failed. This means that the rich menu for one or more users couldn't be controlled. There may also be users whose operations have been successfully completed.

acceptedTime

String

The accepted time in milliseconds of the request of batch control the rich menu.

Format: ISO 8601 (opens new window) (e.g. 2020-12-03T10:15:30.121Z)
Timezone: UTC

completedTime

String

Not always included

The completed time in milliseconds of rich menu batch control. Returned when the phase property is succeeded or failed.

Format: ISO 8601 (opens new window) (e.g. 2020-12-03T10:15:30.121Z)
Timezone: UTC

Example response

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid request ID is specified.
`404`	Couldn't get the status. Consider these reasons: A non-existent request ID is specified. The period of time to get the status has expired.

For more information, see Status codes and Error responses in the Common specifications section.

Example error response

# Validate a request of rich menu batch control

POST https://api.line.me/v2/bot/richmenu/validate/batch

Validate a request body of the Replace or unlink the linked rich menus in batches endpoint.

You can use this endpoint to detect the following errors, as well as when you replace or unlink the linked rich menu in batch:

If you specify the non-existent rich menu
If you specify a rich menu with no images
If you specify multiple operations in the operations property and the operations are incorrect
- When more than 1,000 arrays are specified in the operations property
- When type property is unlinkAll and other type at the same time
- When the ID of the same rich menu is specified in multiple from properties
If you specify invalid string in resumeRequestKey property

Example request

# Rate limit

2,000 requests per second

For more information on rate limits, see Rate limits.

# Request headers

Authorization

Required

Bearer {channel access token}

# Request body

operations

Array of Rich menu operation object

Required

Defines the batch operation to the rich menu.
Max: 1,000 objects

resumeRequestKey

String

Optional

Key for retry. Key value is a string matching the regular expression pattern [0-9a-zA-Z\-_]{1,100}.

# Response

Returns the 200 HTTP status code and an empty JSON object.

Response example

# Error response

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't control the rich menu. Consider these reasons: An invalid rich menu ID is specified. The rich menu you want to replace has no image. More than 1000 operations are specified in the `operations` property. `unlinkAll` and other types are specified to the `type` property at the same time. The ID of the same rich menu is specified in multiple `from` properties.
`404`	A non-existent rich menu is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Error response example

You can provide users a rich menu with tab switching using rich menu aliases and rich menu switch action. For more information, see Switch between tabs on rich menus in the Messaging API documentation.

Endpoints

POST   /v2/bot/richmenu/alias

DELETE /v2/bot/richmenu/alias/{richMenuAliasId}

POST   /v2/bot/richmenu/alias/{richMenuAliasId}

GET    /v2/bot/richmenu/alias/{richMenuAliasId}

GET    /v2/bot/richmenu/alias/list

POST https://api.line.me/v2/bot/richmenu/alias

Creates a rich menu alias.

To create a rich menu alias, make sure to finish these tasks in advance. For more information, see Switch between tabs on rich menus in the Messaging API documentation.

Create a rich menu
Upload a rich menu image

Using the Messaging API, you can create up to 1000 rich menu aliases per one LINE Official Account.

Request example

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

richMenuAliasId

String

Required

Rich menu alias ID, which can be any ID, unique for each channel.

Max character limit: 32
Supported character types: Half-width alphanumeric characters (a-z, 0-9), underscore (_), and hyphen (-)

richMenuId

String

Required

The rich menu ID to be associated with the rich menu alias.

About rich menus that can be associated

Rich menu aliases can only be associated with rich menus created in the same channel.

Returns the 200 HTTP status code and an empty JSON object.

Response example

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't create the rich menu alias. Consider these reasons: A rich menu that doesn't exist or a rich menu without a set image is specified. An invalid rich menu alias ID is specified. An invalid rich menu ID is specified. Reached the maximum number of rich menu aliases you can create. The same ID as an already existing rich menu alias is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Error response example

DELETE https://api.line.me/v2/bot/richmenu/alias/{richMenuAliasId}

Deletes rich menu alias.

On rich menu alias count limit

You can create up to 1,000 rich menu aliases per LINE Official Account using the Messaging API. Once you reach this limit, you must delete existing rich menu aliases before creating new rich menu aliases.

Request example

100 requests per hour

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

richMenuAliasId

Required

Rich menu alias ID that you want to delete.

Returns the 200 HTTP status code and an empty JSON object.

Response example

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid rich menu alias ID is specified.
`404`	A non-existent rich menu alias is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Error response example

POST https://api.line.me/v2/bot/richmenu/alias/{richMenuAliasId}

Updates rich menu aliases. You can specify an existing rich menu alias to modify the associated rich menu.

When will the updates be reflected?

Rich menu alias updates may not be reflected immediately due to cache data.

Request example

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

Content-Type

Required

application/json

richMenuAliasId

Required

The rich menu alias ID you want to update.

richMenuId

String

Required

The rich menu ID to be associated with the rich menu alias

About rich menus that can be associated

Rich menu aliases can only be associated with rich menus created in the same channel.

Returns the 200 HTTP status code and an empty JSON object.

Response example

Returns the following HTTP status code and an error response:

Code	Description
`400`	Couldn't update the rich menu alias. Consider these reasons: A rich menu that doesn't exist or a rich menu without a set image is specified. An invalid rich menu alias ID is specified. An invalid rich menu ID is specified.
`404`	A non-existent rich menu alias is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Error response example

GET https://api.line.me/v2/bot/richmenu/alias/{richMenuAliasId}

Specifies rich menu alias ID to get information of the rich menu alias.

Request example

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

richMenuAliasId

Required

The rich menu alias ID whose information you want to obtain.

Returns the 200 HTTP status code and an empty JSON object.

richMenuAliasId

String

Rich menu alias ID.

richMenuId

String

The rich menu ID associated with the rich menu alias.

Response example

Returns the following HTTP status code and an error response:

Code	Description
`400`	An invalid rich menu alias ID is specified.
`404`	A non-existent rich menu alias is specified.

For more information, see Status codes and Error responses in the Common specifications section.

Error response example

GET https://api.line.me/v2/bot/richmenu/alias/list

Gets the rich menu alias list.

Request example

2,000 requests per second

For more information on rate limits, see Rate limits.

Authorization

Required

Bearer {channel access token}

Returns the 200 HTTP status code and a JSON object containing these values.

aliases[].richMenuAliasId

String

Rich menu alias ID.

aliases[].richMenuId

String

The rich menu ID associated with the rich menu alias.

Response example

For more information, see Status codes and Error responses in the Common specifications section.

# Account link

You can link the service account provided by the provider (corporate and developer) with the account of the LINE user.

Endpoints

POST /v2/bot/user/{userId}/linkToken

# Issue link token

POST https://api.line.me/v2/bot/user/{userId}/linkToken

Issues a link token used for the account link feature.

Example request

# Request headers

Authorization

Required

Bearer {channel access token}

# Path parameters

userId

Required

User ID for the LINE account to be linked. Found in the source object of account link event objects. Do not use the LINE ID used in LINE.

# Response

Returns status code 200 and a JSON object containing these values.

linkToken

String

Link token. Link tokens are valid for 10 minutes and can only be used once.

Note

The validity period may change without notice.

Example response

# Message objects

JSON object which contains the contents of the message you send.

Validating message objects

By using the following endpoints, you can validate message objects:

Validate message objects of a reply message
Validate message objects of a push message
Validate message objects of a multicast message
Validate message objects of a narrowcast message
Validate message objects of a broadcast message

# Common properties for messages

The following properties can be specified in all the message objects.

# Quick reply

These properties are used for the quick reply feature. For more information, see Use quick replies.

quickReply

Object

Optional

items object

If the user receives multiple message objects, the quickReply property of the last message object is displayed.

# items object

This is a container that contains quick reply buttons.

items

Array of objects

Required

Quick reply button objects.
Max: 13 objects

Example items object

# Quick reply button object

This is a quick reply option that is displayed as a button.

type

String

Required

action

imageUrl

String

Optional

URL of the icon that is displayed at the beginning of the button (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: PNG
Aspect ratio: 1:1 (width : height)
Max file size: 1 MB

There is no limit on the image size.
If the action property has a camera action, camera roll action, or location action, and the imageUrl property is not set, the default icon is displayed.

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

action

Object

Required

Action performed when this button is tapped. Specify an action object. The following is a list of the available actions:

Postback action
Message action
URI action
Datetime picker action
Camera action
Camera roll action
Location action
Clipboard action

If a version of LINE that doesn't support the quick reply feature receives a message that contains quick reply buttons, only the message is displayed.

# Customize icon and display name

When sending a message from the LINE Official Account, you can specify the sender.name and the sender.iconUrl properties in Message objects.

sender.name

String

Optional

Display name. Certain words such as LINE may not be used.
Max character limit: 20

sender.iconUrl

String

Optional

URL of the image to display as an icon when sending a message (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: PNG
Aspect ratio: 1:1 (width : height)
Max file size: 1 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

Text message example of customized icon and display name

# Text message

Number of characters and index position of emojis

The number of characters and index position of emojis in text set to the property must be the number and position of the code unit when encoded in UTF-16. For some characters, such as those that use surrogate pairs and emojis that can be expressed in UTF-16, count them as multiple characters instead of one.

For more information, see Character counting in a text in the Messaging API documentation.

type

String

Required

text

text

String

Required

Message text. You can include the following emoji:

LINE emojis. Use a $ character as a placeholder and specify the product ID and emoji ID of the LINE emoji you want to use in the emojis property. For more information, see LINE emoji.
Unicode emojis

Max character limit: 5000

"LINE original unicode emojis" has been discontinued as of March 31, 2022

Use "LINE Emoji" with the emojis property instead of "LINE original unicode emojis".

For more information, see the news from April 1, 2022, "LINE original unicode emojis" of the Messaging API has been discontinued as of March 31, 2022 and LINE emoji.

emojis

Array of LINE emoji objects

Optional

One or more LINE emoji.
Max: 20 LINE emoji

emojis.index

Number

Optional

The index position for $ indicating the placeholder for LINE emojis in text, with the first character being at position 0. See the text message example for details.

Note

If you specify a position that doesn't match the position of $, the API returns HTTP 400 Bad request.

emojis.productId

String

Optional

Product ID for a set of LINE emoji. For more information on product IDs, see LINE emoji.

emojis.emojiId

String

Optional

Emoji ID. For more information on emoji IDs for LINE emojis that are sendable with the Messaging API, see LINE emoji.

quoteToken

String

Optional

Quote token of the message you want to quote. For more information, see Get quote tokens in the Messaging API documentation.

Text message example

Text message example with LINE emoji

Example of a text message quoting a past message

# Text message (v2)

Unlike text message, text message (v2) can substitute strings enclosed in { and } with mentions and emojis.

type

String

Required

textV2

text

String

Required

Message text.

You can use the substitution property to substitute strings enclosed in { and } with mentions or emojis. If you want to use { and } as strings, escape them with {{ and }}. Also, note the following when using { and }:

{ and } must be used in pairs.
The substitution content of the string enclosed in { and } must be specified using the substitution property.

Max character limit: 5000

substitution

Object

Optional

An object that specifies the substitution content for the part enclosed in { and } of the text property.

Characters that can be used for object keys are half-width alphanumeric characters (0-9a-zA-Z) and underscore (_). In addition, the maximum length of the key is 20 characters.

You can specify mention objects or emoji objects for object values.

Max number of objects: 100

quoteToken

String

Optional

Quote token of the message you want to quote. For more information, see Get quote tokens in the Messaging API documentation.

Example of a text message (v2) with mentions and an emoji

# Mention object

Specify the content of the mention to be substituted within the text. Note the following when using mention objects:

Mention objects can only be used in reply message or push message.
The destination of the message must be a group chat or multi-person chat.
Your LINE Official Account that sends messages must be a member of the group chat or multi-person chat to which the message is being sent.
All mentioned users must be members of the group chat or multi-person chat to which the message is being sent.
Up to 20 mentions can be substituted in a single message.

Items 2 to 4 above can't be verified using the Validate message objects of a reply message or Validate message objects of a push message endpoints.

type

String

Required

mention

mentionee

Object

Required

The object to be mentioned. Specify either the user object or the all-mention object.

# User object

type

String

Required

user

userId

String

Required

Use ID of the user to be mentioned. You can't specify the user ID of a LINE Bot.

# All-mention object

type

String

Required

all

# Emoji object

Specify the emoji content to be substituted within the text. Up to 20 emoji can be substituted in a single message.

type

String

Required

emoji

productId

String

Required

Product ID for a set of LINE emoji. For more information on product IDs, see LINE emoji in the Messaging API documentation.

emojiId

String

Required

Emoji ID. For more information on emoji IDs for LINE emojis that are sendable with the Messaging API, see LINE emoji in the Messaging API documentation.

# Sticker message

type

String

Required

sticker

packageId

String

Required

Package ID for a set of stickers. For information on package IDs, see the Stickers.

stickerId

String

Required

Sticker ID. For a list of sticker IDs for stickers that can be sent with the Messaging API, see the Stickers.

quoteToken

String

Optional

Quote token of the message you want to quote. For more information, see Get quote tokens in the Messaging API documentation.

Sticker message example

Example of a sticker message quoting a past message

# Image message

type

String

Required


originalContentUrl

String

Required

Image file URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: JPEG or PNG
Max file size: 10 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

previewImageUrl

String

Required

Preview image URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: JPEG or PNG
Max file size: 1 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

Depending on the situation of a user device, the image of the originalContentUrl property may be used as the preview image.

Image message example

# Video message

If the video doesn't play properly

Even if a message that contains a video is successfully sent, the video may not play properly on the user's device. For more information, see Why can't I play a video that I sent as a message? in the FAQ.

Video aspect ratio

A very wide or tall video may be cropped when played in some environments.
The aspect ratio of the video specified in originalContentUrl and the preview image specified in previewImageUrl should be the same. If the aspect ratio is different, a preview image will appear behind the video.

A video message in the LINE chat room. A preview image with a 1:1 aspect ratio is displayed behind the video that has an aspect ratio of 16:9.

type

String

Required

video

originalContentUrl

String

Required

Video file URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Video format: mp4
Max file size: 200 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

previewImageUrl

String

Required

Preview image URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: JPEG or PNG
Max file size: 1 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

trackingId

String

Optional

ID used to identify the video when Video viewing complete event occurs. If you send a video message with trackingId added, the video viewing complete event occurs when the user finishes watching the video.

You can use the same ID in multiple messages.

Max character limit: 100
Supported character types: Half-width alphanumeric characters (a-z, A-Z, 0-9) and symbols (-.=,+*()%$&;:@{}!?<>[])

Note

You can't use the trackingId property in messages addressed to group chats or multi-person chats.

Video message example

# Audio message

type

String

Required

audio

originalContentUrl

String

Required

Audio file URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Audio format: mp3 or m4a
Max file size: 200 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

duration

Number

Required

Length of audio file (milliseconds)

Audio message example

# Location message

type

String

Required

location

title

String

Required

Title
Max character limit: 100

address

String

Required

Address
Max character limit: 100

latitude

Decimal

Required

Latitude

longitude

Decimal

Required

Longitude

Location message example

# Imagemap message

Imagemap messages are messages configured with an image that has multiple tappable areas. You can assign one tappable area for the entire image or different tappable areas on divided areas of the image.

You can also play a video on the image and display a label with a hyperlink after the video is finished.

If the video doesn't play properly

Video aspect ratio

The aspect ratio of the video specified in originalContentUrl and the preview image specified in previewImageUrl should be the same. If the aspect ratio is different, a preview image will appear behind the video.

A video message in the LINE chat room. A preview image with a 1:1 aspect ratio is displayed behind the video that has an aspect ratio of 16:9.

type

String

Required

imagemap

baseUrl

String

Required

Image base URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
For more information about supported images in imagemap messages, see How to configure an image.

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

altText

String

Required

Alternative text. When a user receives a message, it will appear as an alternative to the image in the notification or chat list of their device.
Max character limit: 400

baseSize.width

Number

Required

Width of base image in pixels. Set to 1040.

baseSize.height

Number

Required

Height of base image. Set to the height that corresponds to a width of 1040 pixels.

video.originalContentUrl

String

Video file URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Video format: mp4
Max file size: 200 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

Note

A very wide or tall video may be cropped when played in some environments.

video.previewImageUrl

String

Preview image URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: JPEG or PNG
Max file size: 1 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

video.area.x

Number

Horizontal position of the video area relative to the left edge of the imagemap area. Value must be 0 or higher.

video.area.y

Number

Vertical position of the video area relative to the top of the imagemap area. Value must be 0 or higher.

video.area.width

Number

Width of the video area

video.area.height

Number

Height of the video area

video.externalLink.linkUri

String

Webpage URL. Called when the label displayed after the video is tapped.
Max character limit: 1000
The available schemes are http, https, line, and tel. For more information about the LINE URL scheme, see Use LINE features with the LINE URL scheme.

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

video.externalLink.label

String

Label. Displayed after the video is finished.
Max character limit: 30

actions

Array of imagemap action objects

Required

Action when tapped
Max: 50

*1 This property is required if you set a video to play on the imagemap.
*2 This property is required if you set a video to play and a label to display after the video on the imagemap.

Imagemap message example with two tappable areas

# How to configure an image

Images used in imagemap messages must meet the following requirements:

Image format: JPEG or PNG
Image width: 240px, 300px, 460px, 700px, 1040px
Max file size: 10 MB

Using transparent PNG

It is possible to use transparent PNG in your imagemap messages.

Make it possible to access images of 5 different sizes using the baseUrl/{image width} URL format. LINE will then download an image at the appropriate resolution based on the device.

For example, if we had a base URL of https://example.com/images/cats, the URL for the image with a width of 700px would be https://example.com/images/cats/700. To confirm all images display properly, access the image URLs.

Image width	Example URL
240px	`https://example.com/bot/images/rm001/240`
300px	`https://example.com/bot/images/rm001/300`
460px	`https://example.com/bot/images/rm001/460`
700px	`https://example.com/bot/images/rm001/700`
1040px	`https://example.com/bot/images/rm001/1040`

Exclude image extension from URL

Don't include the extension in the image filename. The image will not display in the imagemap message if the URL contains the image file extension (e.g. https://example.com/bot/images/rm001/700.png).

# Imagemap action objects

Object which specifies the actions and tappable areas of an imagemap. When an area is tapped, the following actions are triggered for each type of action:

uri: The user is redirected to the specified URI.
message: The specified message is sent.
clipboard: The specified string is copied to the user's device clipboard.

# Imagemap URI action object

type

String

Required

uri

label

String

Optional

Label for the action. Spoken when the accessibility feature is enabled on the client device.
Max character limit: 100

linkUri

String

Required

Webpage URL
Max character limit: 1000
The available schemes are http, https, line, and tel. For more information about the LINE URL scheme, see Use LINE features with the LINE URL scheme.

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

area

Imagemap area object

Required

Defined tappable area

Example imagemap URI action object

# Imagemap message action object

type

String

Required

message

label

String

Optional

Label for the action. Spoken when the accessibility feature is enabled on the client device.
Max character limit: 100

text

String

Required

Message to send
Max character limit: 400

area

Imagemap area object

Required

Defined tappable area

Example imagemap message action object

# Imagemap clipboard action object

This feature is available on LINE version 14.0.0 or later for iOS or Android.

type

String

Required

clipboard

label

String

Optional

Label for the action. Spoken when the accessibility feature is enabled on the client device.
Max character limit: 100

clipboardText

String

Required

Text that is copied to the clipboard

Max character limit: 1000

area

Imagemap area object

Required

Defined tappable area

Example imagemap clipboard action object

# Imagemap area object

Defines the size of a tappable area. The top left is used as the origin of the area. Set these properties based on the baseSize.width property and the baseSize.height property.

Number

Required

Horizontal position relative to the left edge of the area. Value must be 0 or higher.

Number

Required

Vertical position relative to the top of the area. Value must be 0 or higher.

width

Number

Required

Width of the tappable area

height

Number

Required

Height of the tappable area

Example imagemap area object

# Template messages

Template messages are messages with predefined layouts which you can customize. For more information, see Template messages.

The following template types are available:

Buttons
Confirm
Carousel
Image carousel

# Common properties of template message objects

The following properties are common to all template message objects.

type

String

Required

template

altText

String

Required

Alternative text. When a user receives a message, it will appear in the device's notifications, chat list, and quote messages as an alternative to the template message.
Max character limit: 400

template

Object

Required

A Buttons, Confirm, Carousel, or Image Carousel object.

# Buttons template

Template with an image, title, text, and multiple action buttons.

type

String

Required

buttons

thumbnailImageUrl

String

Optional

Image URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: JPEG or PNG
Max width: 1024px
Max file size: 10 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

Recommended file size

To avoid delays in displaying messages, keep the size of individual image files small (1 MB or less recommended).

imageAspectRatio

String

Optional

Aspect ratio of the image. One of:

rectangle: 1.51:1
square: 1:1

Default: rectangle

imageSize

String

Optional

Size of the image. One of:

cover: The image fills the entire image area. Parts of the image that do not fit in the area are not displayed.
contain: The entire image is displayed in the image area. A background is displayed in the unused areas to the left and right of vertical images and in the areas above and below horizontal images.

Default: cover

imageBackgroundColor

String

Optional

Background color of the image. Specify a RGB color value. Default: #FFFFFF (white)

title

String

Optional

Title
Max character limit: 40

text

String

Required

Message text
Max character limit: 160 (no image or title)
Max character limit: 60 (message with an image or title)

defaultAction

Action object

Optional

Action when image, title or text area is tapped.

actions

Array of action objects

Required

Action when tapped
Max objects: 4

Buttons template message example

# Confirm template

Template with two action buttons.

type

String

Required

confirm

text

String

Required

Message text
Max character limit: 240

actions

Array of action objects

Required

Action when tapped
Set 2 actions for the 2 buttons

Confirm template message example

# Carousel template

Template with multiple columns which can be cycled like a carousel. The columns are shown in order when scrolling horizontally.

type

String

Required

carousel

columns

Array of column objects

Required

Array of columns
Max columns: 10

imageAspectRatio

String

Optional

Aspect ratio of the image. One of:

rectangle: 1.51:1
square: 1:1

Applies to all columns. Default: rectangle

imageSize

String

Optional

Size of the image. One of:

cover: The image fills the entire image area. Parts of the image that do not fit in the area are not displayed.
contain: The entire image is displayed in the image area. A background is displayed in the unused areas to the left and right of vertical images and in the areas above and below horizontal images.

Applies to all columns. Default: cover.

Carousel template message example

# Column object for carousel

thumbnailImageUrl

String

Optional

Image URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: JPEG or PNG
Aspect ratio: 1.51:1 (width : height)
Max width: 1024px
Max file size: 10 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

Recommended file size

To avoid delays in displaying messages, keep the size of individual image files small (1 MB or less recommended).

imageBackgroundColor

String

Optional

Background color of the image. Specify a RGB color value. The default value is #FFFFFF (white).

title

String

Optional

Title
Max character limit: 40

text

String

Required

Message text
Max character limit: 120 (no image or title)
Max character limit: 60 (message with an image or title)

defaultAction

Action object

Optional

Action when image, title or text area is tapped.

actions

Array of action objects

Required

Action when tapped
Max objects: 3

Note

Keep the number of actions consistent for all columns. If you use an image or title for a column, make sure to do the same for all other columns.

# Image carousel template

Template with multiple images which can be cycled like a carousel. The images are shown in order when scrolling horizontally.

type

String

Required

image_carousel

columns

Array of column objects

Required

Array of columns
Max columns: 10

Image carousel template message example

# Column object for image carousel

imageUrl

String

Required

Image URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: JPEG or PNG
Aspect ratio: 1:1 (width : height)
Max width: 1024px
Max file size: 10 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

Recommended file size

To avoid delays in displaying messages, keep the size of individual image files small (1 MB or less recommended).

action

Action object

Required

Action when image is tapped

# Flex Message

Flex Messages are messages with a customizable layout. You can customize the layout freely based on the specification for CSS Flexible Box (CSS Flexbox) (opens new window). For more information, see Send Flex Messages in the Messaging API documentation.

Container
- Bubble
- Carousel
Component
- Box
- Button
- Image
- Video
- Icon
- Text
- Span
- Separator
- Filler (deprecated)

type

String

Required

flex

altText

String

Required

Alternative text. When a user receives a message, it will appear in the device's notifications, talk list, and quote messages as an alternative to the Flex Message.
Max character limit: 400

contents

Object

Required

Flex Message container

Flex Message example

# Operating environment

Flex Messages are supported in all LINE versions. The features listed below aren't supported in all LINE versions:

Feature	LINE for iOS LINE for Android	LINE for PC (macOS, Windows)
`maxWidth` property of box `maxHeight` property of box `lineSpacing` property of text Video *1	11.22.0 or later	7.7.0 or later
The `deca` and `hecto` values in the `size` property of bubble *2 `scaling` property of button, text, and icon	13.6.0 or later	7.17.0 or later

*1 To make the video component in Flex Messages rendered properly on versions that don't support the video component, specify the altContent property. The image you specify in this property gets displayed instead.

*2 If the version of LINE is lower than the version that supports deca and hecto, the size of the bubble will be displayed as kilo.

# Container

Container is the top-level building block of Flex Messages. Available container types are:

Bubble
Carousel

For JSON samples and usage of containers, see Flex Message elements in the API documentation.

# Bubble

Bubble is a container that contains only one instance of a message bubble. It can contain four blocks: header, hero, body, and footer. For more information about using each block, see Block in the API documentation.

The maximum size of JSON data that defines a bubble is 30 KB.

type

String

Required

bubble

size

String

Optional

The size of the bubble. You can specify one of the following values: nano, micro, deca, hecto, kilo, mega, or giga. The default value is mega.

deca and hecto are supported on the following version of LINE:

LINE for iOS and Android: 13.6.0 or later
LINE for macOS and Windows: 7.17.0 or later

If the version of LINE is lower than the version that supports deca and hecto, the size of the bubble will be displayed as kilo.

direction

String

Optional

Text directionality and the direction of placement of components in horizontal boxes. Specify one of the following values:

ltr: The text is left-to-right horizontal writing, and the components are placed from left to right
rtl: The text is right-to-left horizontal writing, and the components are placed from right to left

The default value is ltr.

header

Object

Optional

Header block. Specify a Box.

hero

Object

Optional

Hero block. Specify a box, an image or a video.

body

Object

Optional

Body block. Specify a Box.

footer

Object

Optional

Footer block. Specify a Box.

styles

Object

Optional

Style of each block. Specify a bubble style.

action

Object

Optional

Action performed when this image is tapped. Specify an action object.

Bubble example

# Objects for the block style

Use the following two objects to define the style of blocks in a bubble.

Example of a bubble style and block style

# Bubble style

header

Object

Optional

Header block. Specify a block style.

hero

Object

Optional

Hero block. Specify a block style.

body

Object

Optional

Body block. Specify a block style.

footer

Object

Optional

Footer block. Specify a block style.

# Block style

backgroundColor

String

Optional

Background color of the block. Use a hexadecimal color code.

separator

Boolean

Optional

true to place a separator above the block. The default value is false.

separatorColor

String

Optional

Color of the separator. Use a hexadecimal color code.

Note

You cannot place a separator above the first block.

# Carousel

Carousel is a container that contains multiple bubbles. You can browse the bubbles in a carousel by scrolling sideways.

The maximum size of JSON data that defines a carousel is 50 KB.

type

String

Required

carousel

contents

Array of objects

Required

Bubbles within a carousel. Max: 12 bubbles

Bubble width

A carousel can't contain bubbles of different widths (size property). Each bubble in a carousel should have the same width.

Bubble height

The body of each bubble will stretch to match the tallest bubble in the carousel. However, bubbles with no body will not change height.

Carousel example

# Component

Component is a unit that composes a block. Available components are:

Box
Button
Video
Icon
Text
Span
Separator
Filler (deprecated)

For JSON samples and usage of each component, see Flex Message elements and Flex Message layout in the Messaging API documentation.

# Box

This component defines a horizontal or vertical layout orientation and holds components together. Any component can be contained, including a box. You can also include a box in a box.

type

String

Required

box

layout

String

Required

The layout style of components in this box. For more information, see Box component orientation in the API documentation.

contents

Array of objects

Required

Components in this box. Here are the types of components available:

When the layout property is horizontal or vertical: box, button, image, text, separator, and filler
When the layout property is baseline: icon, text, and filler

Components are rendered in the same order specified in the array. You may also specify an empty array.

backgroundColor

String

Optional

Background color of the block. In addition to the RGB color, an alpha channel (transparency) can also be set. Use a hexadecimal color code. (e.g. #RRGGBBAA) The default value is #00000000.

borderColor

String

Optional

Color of box border. Use a hexadecimal color code.

borderWidth

String

Optional

Width of box border. You can specify a value in pixels or any one of none, light, normal, medium, semi-bold, or bold. A value of none means that borders are not rendered; the other values are listed in order of increasing width.

cornerRadius

String

Optional

Radius at the time of rounding the corners of the border. You can specify a value in pixels or any one of none, xs, sm, md, lg, xl, or xxl. none doesn't round the corner while the others increase in radius in the order of listing. The default value is none.

width

String

Optional

Box width. The value should be given in pixels or as a percentage of the width of the parent element. For more information, see Box width in the Messaging API documentation.

maxWidth

String

Optional

Max width of the box. The value should be given in pixels or as a percentage of the width of the parent element. For more information, see Max width of a box in the Messaging API documentation.

This property is supported on the following version of LINE:

LINE for iOS and Android: 11.22.0 or later
LINE for macOS and Windows: 7.7.0 or later

height

String

Optional

Box height. The value should be given in pixels or as a percentage of the height of the parent element. For more information, see Box height in the Messaging API documentation.

maxHeight

String

Optional

Max height of the box. The value should be given in pixels or as a percentage of the height of the parent element. For more information, see Max height of a box in the Messaging API documentation.

This property is supported on the following version of LINE:

LINE for iOS and Android: 11.22.0 or later
LINE for macOS and Windows: 7.7.0 or later

flex

Number

Optional

The ratio of the width or height of this component within the parent box. For more information, see Component size in the Messaging API documentation.

spacing

String

Optional

Minimum space between components in this box. The default value is none. For more information, see spacing property for boxes in the Messaging API documentation.

margin

String

Optional

The minimum amount of space to include before this component in its parent container. For more information, see margin property of components in the Messaging API documentation.

paddingAll

String

Optional

Free space between the borders of this box and the child element. For more information, see Position child component with box padding in the Messaging API documentation.

paddingTop

String

Optional

Free space between the border at the upper end of this box and the upper end of the child element. For more information, see Position child component with box padding in the Messaging API documentation.

paddingBottom

String

Optional

Free space between the border at the lower end of this box and the lower end of the child element. For more information, see Position child component with box padding in the Messaging API documentation.

paddingStart

String

Optional

If the text directionality in the bubble is LTR: Free space between the border at the left end of this box and the left end of the child element.
If the text directionality in the bubble is RTL: Free space between the border at the right end of this box and the right end of the child element.

For more information, see Position child component with box padding in the Messaging API documentation.

paddingEnd

String

Optional

If the text directionality in the bubble is LTR: Free space between the border at the right end of this box and the right end of the child element.
If the text directionality in the bubble is RTL: Free space between the border at the left end of this box and the left end of the child element.

For more information, see Position child component with box padding in the Messaging API documentation.

position

String

Optional

Reference position for placing this box. Specify one of the following values:

relative: Use the previous box as reference.
absolute: Use the top left of parent element as reference.

The default value is relative. For more information, see Offset in the Messaging API documentation.

offsetTop

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetBottom

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetStart

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetEnd

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

action

Object

Optional

Action performed when this image is tapped. Specify an action object.

justifyContent

String

Optional

How child elements are aligned along the main axis of the parent element. If the parent element is a horizontal box, this only takes effect when its child elements have their flex property set equal to 0. For more information, see Child component arrangement with free space in the Messaging API documentation.

alignItems

String

Optional

How child elements are aligned along the cross axis of the parent element. For more information, see Child component arrangement with free space in the Messaging API documentation.

background.type

String

Optional

The type of background used. Specify these values:

linearGradient: Linear gradient. For more information, see Linear gradient backgrounds in the Messaging API documentation.

background.angle

String

Optional

The angle at which a linear gradient moves. Specify the angle using an integer value like 90deg (90 degrees) or a decimal number like 23.5deg (23.5 degrees) in the half-open interval [0, 360). The direction of the linear gradient rotates clockwise as the angle increases. Given a value of 0deg, the gradient starts at the bottom and ends at the top; given a value of 45deg, the gradient starts at the bottom-left corner and ends at the top-right corner; given a value of 90deg, the gradient starts at the left and ends at the right; and given a value of 180deg, the gradient starts at the top and ends at the bottom. For more information, see Angle of linear gradient in the Messaging API documentation.

This is required when background.type is linearGradient.

background.startColor

String

Optional

The color at the gradient's starting point. Use a hexadecimal color code in the #RRGGBB or #RRGGBBAA format.

This is required when background.type is linearGradient.

background.endColor

String

Optional

The color at the gradient's ending point. Use a hexadecimal color code in the #RRGGBB or #RRGGBBAA format.

This is required when background.type is linearGradient.

background.centerColor

String

Optional

The color in the middle of the gradient. Use a hexadecimal color code in the #RRGGBB or #RRGGBBAA format. Specify a value for the background.centerColor property to create a gradient that has three colors. For more information, see Intermediate color stops for linear gradients in the Messaging API documentation.

background.centerPosition

String

Optional

The position of the intermediate color stop. Specify an integer or decimal value between 0% (the starting point) and 100% (the ending point). This is 50% by default. For more information, see Intermediate color stops for linear gradients in the Messaging API documentation.

Box example

# Button

This component renders a button. You can set an action to be executed when a user taps the button.

type

String

Required

button

action

Object

Required

Action performed when this button is tapped. Specify an action object.

flex

Number

Optional

The ratio to use for the width or height of this component within the parent element. By default, a horizontal box's components have their flex property set equal to 1. By default, a vertical box's components have their flex property set equal to 0. For more information, see Component size in the Messaging API documentation.

margin

String

Optional

The minimum amount of space to include before this component in its parent container. For more information, see margin property for components in the Messaging API documentation.

position

String

Optional

Reference for offsetTop, offsetBottom, offsetStart, and offsetEnd. Specify one of the following values:

relative: Use the previous box as reference.
absolute: Use the top left of parent element as reference.

The default value is relative. For more information, see Offset in the API documentation.

offsetTop

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetBottom

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetStart

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetEnd

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

height

String

Optional

Height of the button. You can specify sm or md. The default value is md.

style

String

Optional

Style of the button. Specify one of the following values:

primary: Style for dark color buttons
secondary: Style for light color buttons
link: HTML link style

The default value is link.

color

String

Optional

Character color when the style property is link. Background color when the style property is primary or secondary. Use a hexadecimal color code.

gravity

String

Optional

Alignment style in vertical direction. For more information, see Vertically align text, images, or button in the Messaging API documentation.

adjustMode

String

Optional

The method by which to adjust the text font size. Specify this value:

shrink-to-fit: Automatically shrink the font size to fit the width of the component. This property takes a "best-effort" approach that may work differently—or not at all!—on some platforms. For more information, see Automatically shrink fonts to fit in the Messaging API documentation.

scaling

Boolean

Optional

If you set the scaling property to true, the font size of the text will be automatically scaled according to the font size setting of the LINE app. The default value is false. For more information, see Scaling to size according to the font size setting in the Messaging API documentation.

This property is supported on the following version of LINE:

LINE for iOS and Android: 13.6.0 or later
LINE for macOS and Windows: 7.17.0 or later

Button example

# Image

This component renders an image.

type

String

Required


url

String

Required

Image URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: JPEG or PNG
Max image size: 1024 x 1024 pixels
Max file size: 10 MB (300 KB when the animated property is true)

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

Recommended file size

To avoid delays in displaying messages, keep the size of individual image files small (1 MB or less recommended).

flex

Number

Optional

The ratio of the width or height of this component within the parent box. For more information, see Component size in the Messaging API documentation.

margin

String

Optional

The minimum amount of space to include before this component in its parent container. For more information, see margin property of components in the Messaging API documentation.

position

String

Optional

Reference for offsetTop, offsetBottom, offsetStart, and offsetEnd. Specify one of the following values:

relative: Use the previous box as reference.
absolute: Use the top left of parent element as reference.

The default value is relative. For more information, see Offset in the Messaging API documentation.

offsetTop

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetBottom

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetStart

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetEnd

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

align

String

Optional

Alignment style in horizontal direction. For more information, see Horizontally align text or images in the Messaging API documentation.

gravity

String

Optional

Alignment style in vertical direction. For more information, see Alignment in vertical direction in the Messaging API documentation.

size

String

Optional

The maximum image width. This is md by default. For more information, see Image size in the Messaging API documentation.

aspectRatio

String

Optional

Aspect ratio of the image. {width}:{height} format. Specify the value of {width} and {height} in the range from 1 to 100000. However, you cannot set {height} to a value that is more than three times the value of {width}. The default value is 1:1.

aspectMode

String

Optional

The display style of the image if the aspect ratio of the image and that specified by the aspectRatio property do not match. For more information, see About the drawing area.

backgroundColor

String

Optional

Background color of the image. Use a hexadecimal color code.

action

Object

Optional

Action performed when this image is tapped. Specify an action object.

animated

Boolean

Optional

When this is true, an animated image (APNG) plays. You can specify a value of true up to 10 images in a single message. You can't send messages that exceed this limit. This is false by default. Animated images larger than 300 KB aren't played back.

How to create animated images

Create animated images using an APNG editor. Refer to information related to creating animated stickers as you create your APNG files. For more information, see the Creation Guidelines (opens new window) for Animated Stickers in the LINE Creators Market.

What if my animated image doesn't play?

If your image appears but no animation plays, check the following:

Did you set the value of the animated property to true?
Is the image file size less than or equal to 300 KB?

In some cases, animations may not be played due to the settings of the LINE app that received the message. Also check the following:

Is Auto-play GIFs enabled in the LINE app settings?

The animation repeats for the number of times specified by the num_plays field in the acTL chunk of an APNG. You can also specify a value of 0 to repeat the animation indefinitely.

Image example

# About the drawing area

Specify the max width of the image with the size property and the aspect ratio (width-to-height ratio) of the image with the aspectRatio property. The rectangular area determined by the size and aspectRatio properties is called the drawing area. The image is rendered in this drawing area.

If the image width specified by the flex property is larger than that calculated from the size property, the width of the drawing area is scaled down to the width of the component.
If the aspect ratio of the image and that specified by the aspectRatio property do not match, the image is displayed according to the aspectMode property. The default value is fit.
- If the value of aspectMode is cover: The image fills the entire drawing area. Parts of the image that do not fit in the drawing area are not displayed.
- If the value of aspectMode is fit: The entire image is displayed in the drawing area. A background is displayed in the unused areas to the left and right of vertical images and in the areas above and below horizontal images.

# Video

This component renders a video.

Video component is supported on the following version of LINE:

LINE for iOS and Android: 11.22.0 or later
LINE for macOS and Windows: 7.7.0 or later

If the version of LINE is lower than the version that supports the video, the component specified as the value of the altContent property will be displayed.

If the video doesn't play properly

Video aspect ratio

A very wide or tall video may be cropped when played in some environments.

Also, the aspect ratio of the video specified in the url property and the following two aspect ratios should be the same. If these aspect ratios are different, the layout may result in an unexpected layout:

The aspect ratio specified by the aspectRatio property
The aspect ratio of the preview image specified by the previewUrl property

A video in a LINE chat room. A preview image with a 1:1 aspect ratio is displayed behind the video that has an aspect ratio of 16:9.

Use conditions of the video component

The following conditions must be met to use the video component:

The video component is specified directly under the hero block
kilo, mega or giga is specified as the value of the size property of the bubble
The bubble is not the child element of a carousel

type

String

Required

video

url

String

Required

Video file URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Video format: mp4
Max file size: 200 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

previewUrl

String

Required

Preview image URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: JPEG or PNG
Max file size: 1 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

altContent

component

Required

Alternative content. The alternative content will be displayed on the screen of a user device that is using a version of LINE that doesn't support the video component. Specify a box or an image.

aspectRatio

String

Optional

Aspect ratio of the video. {width}:{height} format. Specify the value of {width} and {height} in the range from 1 to 100000. However, you can't set {height} to a value that is more than three times the value of {width}. The default value is 1:1.

action

Object

Optional

URI action. For more information, see URI action in the Messaging API documentation.

Video example

# Icon

This component renders an icon for decorating the adjacent text. You can use this component only in a baseline box.

type

String

Required

icon

url

String

Required

Image URL (Max character limit: 2000)
Protocol: HTTPS (TLS 1.2 or later)
Image format: JPEG or PNG
Max image size: 1024 x 1024 pixels
Max file size: 1 MB

The URL should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

margin

String

Optional

The minimum amount of space to include before this component in its parent container. For more information, see margin property of components in the Messaging API documentation.

position

String

Optional

Reference for offsetTop, offsetBottom, offsetStart, and offsetEnd. Specify one of the following values:

relative: Use the previous box as reference.
absolute: Use the top left of parent element as reference.

The default value is relative. For more information, see Offset in the Messaging API documentation.

offsetTop

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetBottom

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetStart

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetEnd

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

size

String

Optional

Maximum size of the icon width. This is md by default. For more information, see Icon, text, and span size in the Messaging API documentation.

scaling

Boolean

Optional

If you set the scaling property to true, the icon size will be automatically scaled according to the font size setting of the LINE app. The default value is false. For more information, see Scaling to size according to the font size setting in the Messaging API documentation.

This property is supported on the following version of LINE:

LINE for iOS and Android: 13.6.0 or later
LINE for macOS and Windows: 7.17.0 or later

aspectRatio

String

Optional

Aspect ratio of the icon. {width}:{height} format. The values of {width} and {height} must be in the range 1–100000. {height} can't be more than three times the value of {width}. The default value is 1:1.

The icon's flex property is fixed to 0.

Icon example

# Text

This component renders a text string. You can specify the font color, size, and weight.

type

String

Required

text

text

String

Optional

Text. Be sure to set either one of the text property or contents property. If you set the contents property, text is ignored.

contents

Array of objects

Optional

Array of spans. Be sure to set either one of the text property or contents property. If you set the contents property, text is ignored.

adjustMode

String

Optional

The method by which to adjust the text's font size. Specify this value:

shrink-to-fit: Automatically shrink the font size to fit the width of the component. This property takes a "best-effort" approach that may work differently—or not at all!—on some platforms. For more information, see Automatically shrink fonts to fit in the Messaging API documentation.

flex

Number

Optional

The ratio of the width or height of this component within the parent box. For more information, see Component size in the Messaging API documentation.

margin

String

Optional

The minimum amount of space to include before this component in its parent container. For more information, see margin property of components in the Messaging API documentation.

position

String

Optional

Reference for offsetTop, offsetBottom, offsetStart, and offsetEnd. Specify one of the following values:

relative: Use the previous box as reference.
absolute: Use the top left of parent element as reference.

The default value is relative. For more information, see Offset in the Messaging API documentation.

offsetTop

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetBottom

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetStart

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

offsetEnd

String

Optional

Offset. For more information, see Offset in the Messaging API documentation.

size

String

Optional

Font size. This is md by default. For more information, see Icon, text, and span size in the Messaging API documentation.

scaling

Boolean

Optional

If this property is true, the text in span set by the contents property is also automatically scaled in font size.

This property is supported on the following version of LINE:

LINE for iOS and Android: 13.6.0 or later
LINE for macOS and Windows: 7.17.0 or later

align

String

Optional

Alignment style in horizontal direction. For more information, see Horizontally align text or images in the Messaging API documentation.

gravity

String

Optional

Alignment style in vertical direction. The default value is top. For more information, see Alignment in vertical direction in the Messaging API documentation.

wrap

Boolean

Optional

true to wrap text. The default value is false. If set to true, you can use a new line character (\n) to begin on a new line. For more information, see Wrapping text in the Messaging API documentation.

lineSpacing

String

Optional

Line spacing in a wrapping text. Specify a positive integer or decimal number that ends in px. The lineSpacing property doesn't apply to the top of the start line and the bottom of the last line. For more information, see Increase the line spacing in a text in the Messaging API documentation.

This property is supported on the following version of LINE:

LINE for iOS and Android: 11.22.0 or later
LINE for macOS and Windows: 7.7.0 or later

maxLines

Number

Optional

Max number of lines. If the text exceeds the specified number of lines, the last line will end in an ellipsis (…). If set to 0, entire text is displayed. The default value is 0.

weight

String

Optional

Font weight. You can specify one of the following values: regular or bold. Specifying bold makes the font bold. The default value is regular.

color

String

Optional

Font color. Use a hexadecimal color code.

action

Object

Optional

Action performed when this image is tapped. Specify an action object.

style

String

Optional

Style of the text. Specify one of these values:

normal: Normal
italic: Italic

The default value is normal.

decoration

String

Optional

Decoration of the text. Specify one of these values:

none: No decoration
underline: Underline
line-through: Strikethrough

The default value is none.

Text example

# Span

This component renders multiple text strings in different styles. You can specify the color, size, weight, and decoration of each text. Span is set to contents property of texts.

type

String

Required

span

text

String

Optional

Text. If the wrap property of the parent text is set to true, you can use a new line character (\n) to begin on a new line.

color

String

Optional

Font color. Use a hexadecimal color code.

size

String

Optional

Font size. For more information, see Icon, text, and span size in the Messaging API documentation.

weight

String

Optional

Font weight. You can specify one of the following values: regular or bold. Specifying bold makes the font bold. The default value is regular.

style

String

Optional

Style of the text. Specify one of these values:

normal: Normal
italic: Italic

The default value is normal.

decoration

String

Optional

Decoration of the text. Specify one of these values:

none: No decoration
underline: Underline
line-through: Strikethrough

The default value is none.

Note

The decoration set in the decoration property of the text cannot be overwritten by the decoration property of the span.

Span example

# Separator

This component renders a separating line inside a box. A vertical line is drawn if included in a box with the horizontal layout. Similarly, a horizontal line is drawn if included in a box with the vertical layout.

type

String

Required

separator

margin

String

Optional

The minimum amount of space to include before this component in its parent container. For more information, see margin property of components in the Messaging API documentation.

color

String

Optional

Color of the separator. Use a hexadecimal color code.

Separator example

# Filler

Filler is deprecated

To add a space, use the properties of each component instead of adding fillers. For more information, see Component position in the Messaging API documentation.

This component renders an empty space. You can put a space in between, before, or after components within a box.

type

String

Required

filler

flex

Number

Optional

The ratio of the width or height of this component within the parent box. For more information, see Component size in the Messaging API documentation.

The spacing property of the parent element will be ignored for fillers.

Filler example

# Action objects

These are types of actions for your bot to take when a user taps a button or an image in a message.

Postback action
Message action
URI action
Datetime picker action
Camera action
Camera roll action
Location action
Richmenu Switch Action
Clipboard action

# Postback action

When a control associated with this action is tapped, a postback event is returned via webhook with the specified string in the data property.

type

String

Required

postback

label

String

See description

Label for the action. The specification depends on which object the action is set to. For more information, see Specifications of the label.

data

String

Required

String returned via webhook in the postback.data property of the postback event
Max character limit: 300

displayText

String

Optional

Text displayed on the LINE chat screen as a message sent by the user when the action is performed.
Max character limit: 300
The displayText and text properties can't both be used at the same time.

text

String

Optional

【Deprecated】 Text displayed on the LINE chat screen as a message sent by the user when the action is performed. Returned from the server through a webhook. This property shouldn't be used with quick reply buttons.
Max character limit: 300
The displayText and text properties cannot both be used at the same time.

inputOption

String

Optional

The display method of such as rich menu based on user action. Specify one of the following values:

closeRichMenu: Close rich menu
openRichMenu: Open rich menu
openKeyboard: Open keyboard
openVoice: Open voice message input mode

This property is available on LINE version 12.6.0 or later for iOS or Android.

fillInText

String

See description

String to be pre-filled in the input field when the keyboard is opened. Valid only when the inputOption property is set to openKeyboard. The string can be broken by a newline character (\n).
Max character limit: 300

This property is available on LINE version 12.6.0 or later for iOS or Android.

# Specifications of the label

The label property of the following actions has different specifications for each object on which the action is set:

Postback action
Message action
URI action
Datetime picker action
Clipboard action

The label specifications for the actions listed above are as follows. For label specifications for actions other than those listed above, see the specifications for each action.

Object		Required	Max character limit
Template messages	Image carousel	Optional	12
Template messages	Other than image carousel	Required	20
Rich menu *1		Optional	20
Quick reply button		Required	20
Flex Message	Button	Required	40
Flex Message	Other than button *2	Optional	40

*1 Spoken when the accessibility feature is enabled on the client device.

*2 The specified label isn't displayed.

Example postback action object

# Message action

When a control associated with this action is tapped, the string in the text property is sent as a message from the user.

type

String

Required

message

label

String

See description

Label for the action. The specification depends on which object the action is set to. For more information, see Specifications of the label.

text

String

Required

Text sent when the action is performed
Max character limit: 300

Example message action object

# URI action

When a control associated with this action is tapped, the URI specified in the uri property is opened in LINE's in-app browser.

type

String

Required

uri

label

String

See description

Label for the action. The specification depends on which object the action is set to. For more information, see Specifications of the label.

uri

String

Required

URI opened when the action is performed (Max character limit: 1000)
The available schemes are http, https, line, and tel. For more information about the LINE URL scheme, see Use LINE features with the LINE URL scheme.

The URI should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

altUri.desktop

String

Optional

URI opened on LINE for macOS and Windows when the action is performed (Max character limit: 1000)
If the altUri.desktop property is set, the uri property is ignored on LINE for macOS and Windows.
The available schemes are http, https, line, and tel. For more information about the LINE URL scheme, see Use LINE features with the LINE URL scheme.

The URI should be percent-encoded using UTF-8. For more information, see About the encoding of a URL specified in a request body property.

Note

The altUri.desktop is supported when you set URI actions in Flex Messages, but it doesn't work in quick reply.

Example URI action object

# Datetime picker action

When a control associated with this action is tapped, a postback event is returned via webhook with the date and time selected by the user from the date and time selection dialog. The datetime picker action does not support time zones.

type

String

Required

datetimepicker

label

String

See description

Label for the action. The specification depends on which object the action is set to. For more information, see Specifications of the label.

data

String

Required

String returned via webhook in the postback.data property of the postback event
Max character limit: 300

mode

String

Required

Action mode
date: Pick date
time: Pick time
datetime: Pick date and time

initial

String

Optional

Initial value of date or time

max

String

Optional

Largest date or time value that can be selected. Must be greater than the min value.

min

String

Optional

Smallest date or time value that can be selected. Must be less than the max value.

Example datetime picker action object

# Date and time format

The date and time formats for the initial, max, and min values are shown below. The full-date, time-hour, and time-minute formats follow the RFC3339 (opens new window) protocol.

Mode	Format	Example
date	`full-date` Max: 2100-12-31 Min: 1900-01-01	2017-06-18
time	`time-hour`:`time-minute` Max: 23:59 Min: 00:00	00:00 06:15 23:59
datetime	`full-date`T`time-hour`:`time-minute` or `full-date`t`time-hour`:`time-minute` Max: 2100-12-31T23:59 Min: 1900-01-01T00:00	2017-06-18T06:15 2017-06-18t06:15

# Camera action

This action can be configured only with quick reply buttons. When a button associated with this action is tapped, the camera screen in LINE is opened.

type

String

Required

camera

label

String

Required

Label for the action
Max character limit: 20

Example camera action object

# Camera roll action

This action can be configured only with quick reply buttons. When a button associated with this action is tapped, the camera roll screen in LINE is opened.

type

String

Required

cameraRoll

label

String

Required

Label for the action
Max character limit: 20

Example camera roll action object

# Location action

This action can be configured only with quick reply buttons. When a button associated with this action is tapped, the location screen in LINE is opened.

type

String

Required

location

label

String

Required

Label for the action
Max character limit: 20

Example location action object

# Rich menu switch action

This action can be configured only with rich menus. It can't be used for Flex Messages or quick replies. When you tap a rich menu associated with this action, you can switch between rich menus, and a postback event including the rich menu alias ID selected by the user is returned via a webhook. For more information, see Switch between tabs on rich menus in the Messaging API documentation.

type

String

Required

richmenuswitch

label

String

Optional

Action label. Optional for rich menus. Read when the user's device accessibility feature is enabled.

Max character limit: 20

richMenuAliasId

String

Required

Rich menu alias ID to switch to.

data

String

Required

String returned by the postback.data property of the postback event via a webhook

Max character limit: 300

Rich menu switch action object example

# Clipboard action

When a user taps a control associated with this action, the text specified in the clipboardText property is copied to the device clipboard.

This feature is available on LINE version 14.0.0 or later for iOS or Android.

type

String

Required

clipboard

label

String

See description

Label for the action. The specification depends on which object the action is set to. For more information, see Specifications of the label.

clipboardText

String

Required

Text that is copied to the clipboard

Max character limit: 1000

Example clipboard action object

Rich menus consist of either of these objects.

Rich menu object without the rich menu ID. Use this object when you create a rich menu.
Rich menu response object with the rich menu ID. This object is returned when you get a rich menu or get a list of rich menus.

Area objects and action objects are included in these objects.

Checking a rich menu object is valid

If you want to check that a rich menu object is valid, you can use the Validate rich menu object endpoint.

size

Object

Required

size object which contains the width and height of the rich menu displayed in the chat. The width of the rich menu image must be between 800px and 2500px. The height must be at least 250px. However, the aspect ratio (width / height) must be at least 1.45.

selected

Boolean

Required

true to display the rich menu by default. Otherwise, false.

name

String

Required

Name of the rich menu. This value can be used to help manage your rich menus and is not displayed to users.
Max character limit: 300

chatBarText

String

Required

Text displayed in the chat bar
Max character limit: 14

areas

Array

Required

Array of area objects which define the coordinates and size of tappable areas
Max: 20 area objects

Example rich menu object

richMenuId

String

ID of a rich menu

size

Object

selected

Boolean

true to display the rich menu by default. Otherwise, false.

name

String

Name of the rich menu. This value can be used to help manage your rich menus and is not displayed to users.
Max character limit: 300

chatBarText

String

Text displayed in the chat bar
Max character limit: 14

areas

Array

Array of area objects which define the coordinates and size of tappable areas
Max: 20 area objects

Example rich menu response object

# `size` object

width

Number

Required

Width of the rich menu. The width of the rich menu image must be between 800 and 2500. However, the aspect ratio (width / height) must be at least 1.45.

height

Number

Required

Height of the rich menu. The height must be at least 250. However, the aspect ratio (width / height) must be at least 1.45.

Example size object

# Area object

bounds

Object

Required

Object describing the boundaries of the area in pixels. See bounds object.

action

Object

Required

Action performed when the area is tapped. See action objects.

Example area object

# `bounds` object

Number

Required

Horizontal position of the top-left corner of the tappable area relative to the left edge of the image. Value must be 0 or higher.

Number

Required

Vertical position of the top-left corner of the tappable area relative to the left edge of the image. Value must be 0 or higher.

width

Number

Required

Width of the tappable area.

height

Number

Required

Height of the tappable area.

Example bounds object

Common specifications

Domain name Rate limits Status codes Response headers Error responses Other common specifications

Webhooks

Request headers Request body Response Signature validation

Webhook Event Objects

Common properties Message event Unsend event Follow event Unfollow event Join event Leave event Member join event Member leave event Postback event Video viewing complete event Beacon event Account link event Membership event

Webhook settings

Set webhook endpoint URL Get webhook endpoint information Test webhook endpoint

Getting content

Get content Verify the preparation status of a video or audio for getting Get a preview image of the image or video

Channel access token

Issue channel access token v2.1 Verify the validity of the channel access token v2.1 Get all valid channel access token key IDs v2.1 Revoke channel access token v2.1 Issue stateless channel access token Issue short-lived channel access token Verify the validity of short-lived and long-lived channel access tokens Revoke short-lived or long-lived channel access token

Message

Send reply message Send push message Send multicast message Send narrowcast message Get narrowcast message status Send broadcast message Display a loading animation Get the target limit for sending messages this month Get number of messages sent this month Get number of sent reply messages Get number of sent push messages Get number of sent multicast messages Get number of sent broadcast messages Validate message objects of a reply message Validate message objects of a push message Validate message objects of a multicast message Validate message objects of a narrowcast message Validate message objects of a broadcast message Retrying an API request

Managing Audience

Details of the error related to audience management Create audience for uploading user IDs (by JSON) Create audience for uploading user IDs (by file) Add user IDs or Identifiers for Advertisers (IFAs) to an audience for uploading user IDs (by JSON) Add user IDs or Identifiers for Advertisers (IFAs) to an audience for uploading user IDs (by file) Create message click audience Create message impression audience Rename an audience Delete audience Get audience data Get data for multiple audiences Get shared audience data in Business Manager Get a list of shared audiences in Business Manager

Insights

Get number of message deliveries Get number of followers Get friend demographics Get user interaction statistics Get statistics per unit Get the number of unit name types assigned during this month Get a list of unit names assigned during this month

Users

Get profile Get a list of users who added your LINE Official Account as a friend

Membership

Get a user's membership subscription status Get a list of users who have joined the membership Get membership plans being offered

Bot

Get bot info

Group chats

Get group chat summary Get number of users in a group chat Get group chat member user IDs Get group chat member profile Leave group chat

Multi-person chats

Get number of users in a multi-person chat Get multi-person chat member user IDs Get multi-person chat member profile Leave multi-person chat

Rich menu

Create rich menu Validate rich menu object Upload rich menu image Download rich menu image Get rich menu list Get rich menu Delete rich menu Set default rich menu Get default rich menu ID Clear default rich menu

Per-user rich menu

Link rich menu to user Link rich menu to multiple users Get rich menu ID of user Unlink rich menu from user Unlink rich menus from multiple users Replace or unlink the linked rich menus in batches Get the status of rich menu batch control Validate a request of rich menu batch control

Rich menu alias

Create rich menu alias Delete rich menu alias Update rich menu alias Get rich menu alias information Get list of rich menu alias

Account link

Issue link token

Message objects

Common properties for messages Text message Text message (v2) Sticker message Image message Video message Audio message Location message Imagemap message Template messages Flex Message

Action objects

Postback action Message action URI action Datetime picker action Camera action Camera roll action Location action Rich menu switch action Clipboard action

Rich menu structure

Rich menu object Rich menu response object

# Messaging API reference

# Common specifications

# Domain name

# Rate limits

# Scope of rate limits

# Limit on the number of concurrent operations

# Status codes

# Response headers

# Error responses

# Error messages

# Other common specifications

# About the encoding of a URL specified in a request body property

# Webhooks

# Request headers

# Request body

# Response

# Signature validation

# Webhook Event Objects

# Common properties

# Source user

# Source group chat

# Source multi-person chat

# Message event

# Text

# Image

# Video

# Audio

# File

# Location

# Sticker

# Unsend event

# Follow event

# Unfollow event

# Join event

# Leave event

# Member join event

# Member leave event

# Postback event

# postback.params object for date-time selection action

# postback.paramsobject for rich menu switch action

# Video viewing complete event

# Beacon event

# Beacon event types

# Account link event

# Membership event

# Webhook settings

# Set webhook endpoint URL

# Rate limit

# Request headers

# Request body

# Response

# Error response

# Get webhook endpoint information

# Rate limit

# Request headers

# Response

# Error response

# Test webhook endpoint

# Rate limit

# Request headers

# Request body

# Response

# Error response

# Getting content

# Get content

# Request headers

# Path parameters

# Response

# Error response

# Verify the preparation status of a video or audio for getting

# Request headers

# Path parameters

# Response

# Error response

# Get a preview image of the image or video

# Request headers

# Path parameters

# Response

# Error response

# Channel access token

# `postback.params` object for date-time selection action

# `postback.params`object for rich menu switch action
